RADIATOR FAN of Lamborghini Lamborghini Urus (2018-2019)

View All

Lamborghini Urus (2018-2019) - RADIATOR FAN

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4M0121207A	TWIN FAN RING IN STOCK	4M0121207A TWIN FAN RING WITHOUT ADDITIONAL FRONT UNDERBODY GUARD-800W IN STOCK	$260.60	1
1	4M0121207	TWIN FAN RING IN STOCK	4M0121207 TWIN FAN RING ADDITIONAL FRONT UNDERBODY GUARD IN STOCK	$244.80	1
2	4M0121251M	COOLER FOR COOLANT IN STOCK	4M0121251M COOLER FOR COOLANT IN STOCK	$521.21	2
3	-	A/C CONDENSER WITH DRYER	A/C CONDENSER WITH DRYER SEE ILLUSTRATION :- 260-020	-	-	Enquire
4	7P0121276	GROMMET	7P0121276 GROMMET UPPER	$4.50	2
5	7P0121365	SLEEVE	7P0121365 SLEEVE UPPER	$6.94	2
6	4M0121095	SECURING PIN IN STOCK	4M0121095 SECURING PIN IN STOCK	$2.20	2
7	8K0805399B	HEXAGON SOCKET HEAD PANEL BOLT IN STOCK	8K0805399B HEXAGON SOCKET HEAD PANEL BOLT 7X22 IN STOCK	$3.20	2
8	4M0121268A	RUBBER BUSH	4M0121268A RUBBER BUSH LOWER	$9.49	2
9	4M0121275A	RUBBER BUSH	4M0121275A RUBBER BUSH LOWER	$6.75	2
10	8W0959455K	RADIATOR FAN WITH CONTROL UNIT	8W0959455K RADIATOR FAN WITH CONTROL UNIT WITHOUT ADDITIONAL FRONT UNDERBODY GUARD-400W 370MM LEFT	$749.42	1
10	8W0959455AA	RADIATOR FAN WITH CONTROL UNIT	8W0959455AA RADIATOR FAN WITH CONTROL UNIT ADDITIONAL FRONT UNDERBODY GUARD-600W 390MM LEFT	$1,057.91	1
11	8W0959455L	RADIATOR FAN WITH CONTROL UNIT	8W0959455L RADIATOR FAN WITH CONTROL UNIT WITHOUT ADDITIONAL FRONT UNDERBODY GUARD-400W 370MM RIGHT	$749.42	1
11	8W0959455N	RADIATOR FAN WITH CONTROL UNIT	8W0959455N RADIATOR FAN WITH CONTROL UNIT ADDITIONAL FRONT UNDERBODY GUARD-600W 390MM RIGHT	$940.51	1
12	WHT007235	HEXAGON SOCKET FLAT HEAD BOLT	WHT007235 HEXAGON SOCKET FLAT HEAD BOLT 5X19	$3.77	8
13	4ML121557	PROTECTION	4ML121557 PROTECTION	$56.95	-
14	8K0867646	CLIP	8K0867646 CLIP	$3.20	-
