Front Coque Elements

Lamborghini Diablo VT Roadster (1998-2000)

Find Your Part

Lamborghini Diablo VT Roadster (1998-2000) - Front Coque Elements

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Front Coque Elements of Lamborghini Lamborghini Diablo VT Roadster (1998-2000) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 8740685
SCREW
VITE
IN STOCK 		$19.97 14
002 8400629
WASHER
RONDELLA 		$1.34 (81.2% off) 14
003 9453002
RIGHT AIR INTAKE
PRESA D'ARIA DX 		$419.72 (10.3% off) 1
004 9430122
RIGHT NET
RETE DX 		$92.60 (11% off) 1
005 9453129
RIGHT PIPE
TUBO DX 		$257.84 (7.9% off) 1
006 9490111
GASKET
GUARNIZIONE 		$41.69 1
007 9490112
UNION
ELEMENTO COLLEGAMENTO 		$21.90 (8% off) 1
008 9453130
LEFT PIPE
TUBO SX 		$279.82 (7.7% off) 1
009 9453003
LEFT AIR INTAKE
PRESA D'ARIA SX 		$850.99 (10.9% off) 1
010 9430123
LEFT NET
RETESX 		$90.08 (11.3% off) 1
011 8100601
SCREW
VITE 		$0.25 10
012 N01152427
WASHER
RONDELLA
IN STOCK 		$0.28 10
013 9410000A
REPAIR PANEL
RIGHT 		- 1 Enquire
013 9410000
RIGHT FR.MUDGU./FEN.
PARAFANGO ANT. DX 		$6,671.52 1
013 9410000
RIGHT FR.MUDGU./FEN.
(Valid for U.S.A. 1998) PARAFANGO ANT. DX 		$6,671.52 1
013 9410000
RIGHT FR.MUDGU./FEN.
(Valid for CANADA 1998) PARAFANGO ANT. DX 		$6,671.52 1
014 9410109
RIGHT BRACKET
STAFFA DX 		$241.49 1
015 9411410
GASKET
GUARNIZIONE 		$84.54 (7.6% off) 2
016 9411402
RIGHT FR. WHEELBOX
PASSARUOTA ANT. DX POST. 		$342.57 1
017 9411417
GASKET
GUARNIZIONE 		$74.19 2
018 9411401
FR. WHEELBOX
PASSARUOTA ANT. DX SUP. 		$1,773.86 1
019 9411425
RIGHT PANEL
PANNELLO DX 		$79.45 (10.9% off) 1
020 9411427
GASKET
GUARNIZIONE 		$57.36 (7.6% off) 2
021 N91049601
OVAL HEAD PANEL SCREW (COMBI)
VITE
IN STOCK 		$0.96 (86.9% off) 6
022 9411416
GASKET
GUARNIZIONE 		$36.19 2
023 WHT000916A
CLIP
MOLLETTA 		$14.48 8
024 9411412
RIGHT LID INSPECTION
SPORTELLO ISPEZIONE DX 		$84.05 1
025 9411408
GASKET
GUARNIZIONE 		$15.44 (8.1% off) 2
026 8700659
SCREW
VITE 		$0.30 16
027 N91115501
WASHER
RONDELLA 		$1.16 (84.2% off) 18
028 9411423
RIGHT FR. WHEELBOX
PASSARUOTA ANT. DX 		$183.27 1
029 9411418
GASKET
GUARNIZIONE 		$31.71 2
030 8830306
CLAMP
FASCETTA 		$3.12 2
031 410805890
RIGHT SUPPORT
CAVALLOTTO DX 		$305.02 1
032 9411422
LEFT RETAINER
CAVALLOTTO SX 		- 1 Enquire
033 9411424
LEFT FR. WHEELBOX
PASSARUOTA ANT. SX 		$183.27 1
034 9411413
INSPECTION LID
SPORTELLO ISPEZIONE SX 		$84.05 1
035 9411426
LEFT PANEL
PANNELLO SX 		$81.21 1
036 9411404
LEFT FR. WHEELBOX
PASSARUOTA ANT. SX SUP. 		$1,773.86 1
037 9411405
LEFT FR. WHEELBOX
PASSARUOTA ANT. SX POST. 		$828.26 1
038 9410110
LEFT BRACKET
STAFFA SX 		$241.49 1
039 9410001
LEFT FR.MUDGU./FEN.
PARAFANGO ANT. SX 		$6,671.52 1
039 9410001
LEFT FR.MUDGU./FEN.
(Valid for U.S.A.1998) PARAFANGO ANT. SX 		$6,671.52 1
039 9410001
LEFT FR.MUDGU./FEN.
(Valid for CANADA.1998) PARAFANGO ANT. SX 		$6,671.52 1
039 9410001A
REPAIR PANEL
LEFT 		- 1 Enquire
