Lamborghini Diablo (1990-1998) - Rear Body Elements (Valid for June 1992 Version)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	9430132	SHIELD	9430132 SHIELD PARATIA ANTICALORE	$227.80	1
002	9410210	REAR FRAME	9410210 REAR FRAME CORNICE POSTERIORE	$2,522.55	1
003	9430008	GRILLE	9430008 GRILLE	$844.07	1
004	9430136	GRILLE	9430136 GRILLE (Valid for June 1992 version) GRIGLIA DESTRA	$356.14	1
005	WHT003383	CLIP	WHT003383 CLIP (Valid for June 1992 version) PIASTRINA FILETTATA	$14.54	4
006	N10247302	OVAL HEAD PANEL SCREW IN STOCK	N10247302 OVAL HEAD PANEL SCREW (Valid for June 1992 version) VITE IN STOCK	$0.72 MSRP: ~~7.35~~ (90.2% off)	4
007	9430103	RIGHT GRILLE	9430103 RIGHT GRILLE (Valid for June 1992 version) GRIGLIA INFERIORE DESTRA	$3,325.17	1
008	9410205	SPACER	9410205 SPACER (Valid for June 1992 version) DISTANZIALE	$11.60	2
009	9410200	REAR PANEL	9410200 REAR PANEL (Valid for June 1992 version) ELEMENTO SCOCCA POSTERIORE	$1,797.97 MSRP: ~~1,950.00~~ (7.8% off)	1
010	9430135	NET	9430135 NET (Valid for June 1992 version) RETE METALLICA	$241.67	1
011	9410206	SPACER	9410206 SPACER (Valid for June 1992 version) DISTANZIALE	$46.68	2
012	9430121	NET	9430121 NET (Valid for June 1992 version) GRIGLIA (fino 12710)	-	1	Enquire
012	9430138	GRILLE	9430138 GRILLE (Valid for June 1992 version) GRIGLIA (dalla 12711) (Particolare intercambiabile solamente se accoppiato con i terminal! di scarico 004432725 e 004432726)	$783.94	1
013	9430104	LEFT GRILLE	9430104 LEFT GRILLE (Valid for June 1992 version) GRIGLIA INFERIORE SINISTRA	$3,460.06	1
014	8200301	NUT	8200301 NUT (Valid for June 1992 version) DADO	$0.07 MSRP: ~~7.38~~ (99.1% off)	8
015	8700328	SCREW	8700328 SCREW (Valid for June 1992 version) VITE	$0.15	8
016	8200301	NUT	8200301 NUT (Valid for June 1992 version) DADO	$0.07 MSRP: ~~7.38~~ (99.1% off)	4
017	9430134	GRILLE	9430134 GRILLE (Valid for June 1992 version) GRIGLIA LATERALE SINISTRA	$292.53	1
018	8700328	SCREW	8700328 SCREW (Valid for June 1992 version) VITE	$0.15	4
019	8200302	NUT IN STOCK	8200302 NUT (Valid for June 1992 version) DADO IN STOCK	$0.15	2
020	8400303	WASHER IN STOCK	8400303 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.04	4
021	9466101	ORNAMENT	9466101 ORNAMENT (Valid for June 1992 version) FREGIO DIABLO	$690.28	1
022	9410211	SUPPORT - SUPPORTO	9410211 SUPPORT - SUPPORTO (Valid for June 1992 version) O FANALE DESTRO	$50.30	1
023	9410212	SUPPORT - SUPPORTO	9410212 SUPPORT - SUPPORTO (Valid for June 1992 version) O FANALE SINISTRO	$234.73	1
024	9455246	LINING	9455246 LINING (Valid for June 1992 version) ISOLAMENTO	$38.52	1
025	9455245	INSULATOR	9455245 INSULATOR (Valid for June 1992 version) ISOLAMENTO GALORE CORNICE	$163.90	1
