Main Shaft Gears

Ferrari 288 GTO

Find Your Part

Ferrari 288 GTO - Main Shaft Gears

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
122721 Input shaft $1,877.24 To Order
Photo Part No Description Price (each) Stock
122722 Shaft for reverse idlergear $139.89 To Order
Photo Part No Description Price (each) Stock
10275550 THREADED PLUG $0.80 To Order
Photo Part No Description Price (each) Stock
122727 Reverse idlergear Enquire To Order
Photo Part No Description Price (each) Stock
122723 Gear, 2nd speed Enquire To Order
Photo Part No Description Price (each) Stock
122724 Gear, 3rd speed Enquire To Order
Photo Part No Description Price (each) Stock
70000623 4th gear complete series $4,721.02 To Order
Photo Part No Description Price (each) Stock
122726 Gear, 5th speed Enquire To Order
Photo Part No Description Price (each) Stock
121821 Bearing $32.60 To Order
Photo Part No Description Price (each) Stock
121819 BALL BEARING WITH CIRCLIP $484.24 IN STOCK
Photo Part No Description Price (each) Stock
121820 Roller Bearing $161.98 IN STOCK
Photo Part No Description Price (each) Stock
122113 Stop ring $0.56 To Order
Photo Part No Description Price (each) Stock
104734 REVERSE IDLE GEAR ROLLER CAGE $9.58 To Order
Photo Part No Description Price (each) Stock
122128 Spacer $15.84 To Order
Photo Part No Description Price (each) Stock
100703 Spacer $22.68 To Order
Photo Part No Description Price (each) Stock
123870 Spacer $3.21 To Order
Photo Part No Description Price (each) Stock
121991 Bush for bearing $97.25 To Order
Photo Part No Description Price (each) Stock
10903224 SCREW $0.26 IN STOCK
Photo Part No Description Price (each) Stock
12035671 Washer Enquire To Order
Photo Part No Description Price (each) Stock
10297760 GASKET $0.34 IN STOCK
Photo Part No Description Price (each) Stock
106095 Drop Gear Ring Nut $43.50 To Order
Photo Part No Description Price (each) Stock
153059 Ring nut $292.22 To Order
Photo Part No Description Price (each) Stock
13907710 Pin Enquire To Order
Photo Part No Description Price (each) Stock
125701 WASHER mm. 0,3 $3.75 To Order
Photo Part No Description Price (each) Stock
125767 WASHER mm. 0,5 $3.75 To Order
View All
Main Shaft Gears of Ferrari Ferrari 288 GTO Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 122721
Input shaft 		$1,877.24 1
2 122722
Shaft for reverse idlergear 		$139.89 1
3 10275550
THREADED PLUG 		$0.80 1
4 122727
Reverse idlergear 		- 1 Enquire
5 122723
Gear, 2nd speed 		- 1 Enquire
6 122724
Gear, 3rd speed 		- 1 Enquire
7 70000623
4th gear complete series 		$4,721.02 1
8 122726
Gear, 5th speed 		- 1 Enquire
9 121821
Bearing 		$32.60 (39.5% off) 2
10 121819
BALL BEARING WITH CIRCLIP
IN STOCK 		$484.24 1
11 121820
Roller Bearing
IN STOCK 		$161.98 (60% off) 1
12 122113
Stop ring 		$0.56 1
13 104734
REVERSE IDLE GEAR ROLLER CAGE 		$9.58 (18.4% off) 2
14 122128
Spacer 		$15.84 1
15 100703
Spacer 		$22.68 (37.8% off) 1
16 123870
Spacer 		$3.21 1
17 121991
Bush for bearing 		$97.25 1
18 10903224
SCREW
IN STOCK 		$0.26 (35% off) 6
19 12035671
Washer 		- 6 Enquire
20 10519424
WASHER D.6.4 X 11.95 X 1.6
IN STOCK 		$0.02 (92% off) 6
21 123877
Screw 		$7.57 1
22 10297760
GASKET
IN STOCK 		$0.34 (66% off) 1
23 106095
Drop Gear Ring Nut 		$43.50 (54.3% off) 1
24 153059
Ring nut 		$292.22 1
25 13907710
Pin 		- 1 Enquire
26 125701
WASHER mm. 0,3 		$3.75 1
27 125767
WASHER mm. 0,5 		$3.75 1
