16 - Suspension - Front - 16.1 - Damper & Actuator Assemblies Front

McLaren P1 Coupe

Find Your Part

McLaren P1 Coupe - 16 - SUSPENSION - FRONT - 16.1 - DAMPER & ACTUATOR ASSEMBLIES FRONT

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
12B0621CP Control Unit - Chassis $4,419.11 To Order
Photo Part No Description Price (each) Stock
00RA083 SCREW - M6X20 - FLANGE HEX Enquire To Order
Photo Part No Description Price (each) Stock
11M0253CP Sensor - Displacement $144.72 To Order
Photo Part No Description Price (each) Stock
00RA087 SCREW - M5X10 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
12B0269CP LINK ROD - SENSOR - DISPLACEMENT - 92MM $212.27 To Order
Photo Part No Description Price (each) Stock
00RA055 NUT - M6 - LOCKING - HEX Enquire To Order
Photo Part No Description Price (each) Stock
12B0606CP Bracket - MAPMU - K-Damper - Bump - Front $164.00 To Order
Photo Part No Description Price (each) Stock
12B0389CP Plate - Support - MAPMU - LH $62.70 To Order
Photo Part No Description Price (each) Stock
00RA061 Screw - M6x16 - Flange Hex Enquire To Order
Photo Part No Description Price (each) Stock
00RA068 SCREW-HEX HEAD-FLA24E-M8X12 Enquire To Order
Photo Part No Description Price (each) Stock
11D0124CP MOUNT - AV - RUBBER $33.77 To Order
Photo Part No Description Price (each) Stock
12B0518CP Bracket - MAPMU - K-Damper - Rebound - Front $154.37 To Order
Photo Part No Description Price (each) Stock
12B0630CP Plate - Support - MAPMU - RH $62.70 To Order
Photo Part No Description Price (each) Stock
12B0073CP Suspension Unit - Tenneco - Front - LH $10,864.50 To Order
Photo Part No Description Price (each) Stock
12B0761CP BOLT - M10X72 - HEX - FLANGE $135.06 To Order
Photo Part No Description Price (each) Stock
11B0802CP Bolt - M10x85 - Damper Mounting - Front $125.41 To Order
Photo Part No Description Price (each) Stock
00RA053 Nut - M10 - Lock Hex Enquire To Order
Photo Part No Description Price (each) Stock
12B0212CP Suspension Unit - Tenneco - Front - RH $10,864.50 To Order
Photo Part No Description Price (each) Stock
12B0610CP Accumulator - Suspension $8,666.20 To Order
Photo Part No Description Price (each) Stock
12B0132CP Micro Automatic - Pressure Monitoring Unit $2,585.85 To Order
Photo Part No Description Price (each) Stock
00RA065 SCREW - M6X12-8.8 - FLANGE HEX Enquire To Order
Photo Part No Description Price (each) Stock
12B0463CP Bracket - Support - Front Pipes - Kinetic Damper Enquire To Order
Photo Part No Description Price (each) Stock
12B0127CP Hose Assy - Kinetic Damper - Bump - Front - LH $1,061.35 To Order
Photo Part No Description Price (each) Stock
00RA011 NUT-HEX HEAD-FLANGE-M6-8 Enquire To Order
Photo Part No Description Price (each) Stock
00RA099 SCREW - M4X25 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RB003 P Clip - DIA 14 Enquire To Order
Photo Part No Description Price (each) Stock
00RB131 HOSE SEPERATOR PHS6 Enquire To Order
Photo Part No Description Price (each) Stock
12B0129CP Hose Assy - Kinetic Damper - Rebound - Front - LH $2,257.78 To Order
Photo Part No Description Price (each) Stock
12B0534CP Pipe - Feed - Kinetic Damper - Front - LH $443.82 To Order
Photo Part No Description Price (each) Stock
00RB098 P-CLIP - DIA 10 - SILICONE Enquire To Order
Photo Part No Description Price (each) Stock
12B0535CP Pipe Assy - Kinetic Damper - Feed - Front - RH $2,566.56 To Order
Photo Part No Description Price (each) Stock
12B0130CP Hose Assy - Kinetic Damper - Rebound - Front - RH $1,042.04 To Order
Photo Part No Description Price (each) Stock
12B0459CP Hose Assy - Kinetic Damper - Bump - Front - RH $2,373.60 To Order
Photo Part No Description Price (each) Stock
00RA357 PIPE PROTECTOR Enquire To Order
Photo Part No Description Price (each) Stock
12B0742CP Bango Bolt - Pipe - Kenectic Damper $192.95 To Order
Photo Part No Description Price (each) Stock
12B0743CP WASHER - PIPE - KENECTIC DAMPER $38.32 To Order
View All
16 - SUSPENSION - FRONT - 16.1 - DAMPER & ACTUATOR ASSEMBLIES FRONT of McLaren McLaren P1 Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
000 11B0814CP
Harness - Tenneco - Damper 		$81.47 1
010 12B0621CP
Control Unit - Chassis 		$4,419.11 1
011 00RA083
SCREW - M6X20 - FLANGE HEX 		- 6 Enquire
012 11M0253CP
Sensor - Displacement 		$144.72 2
013 00RA087
SCREW - M5X10 - HEX 		- 4 Enquire
014 12B0269CP
LINK ROD - SENSOR - DISPLACEMENT - 92MM 		$212.27 2
015 00RA055
NUT - M6 - LOCKING - HEX 		- 16 Enquire
016 12B0606CP
Bracket - MAPMU - K-Damper - Bump - Front 		$164.00 1
017 12B0389CP
Plate - Support - MAPMU - LH 		$62.70 1
018 00RA061
Screw - M6x16 - Flange Hex 		- 6 Enquire
019 00RA068
SCREW-HEX HEAD-FLA24E-M8X12 		- 4 Enquire
020 11D0124CP
MOUNT - AV - RUBBER 		$33.77 6
021 12B0518CP
Bracket - MAPMU - K-Damper - Rebound - Front 		$154.37 1
022 12B0630CP
Plate - Support - MAPMU - RH 		$62.70 1
023 12B0073CP
Suspension Unit - Tenneco - Front - LH 		$10,864.50 1
024 12B0761CP
BOLT - M10X72 - HEX - FLANGE 		$135.06 2
025 11B0802CP
Bolt - M10x85 - Damper Mounting - Front 		$125.41 2
026 00RA053
Nut - M10 - Lock Hex 		- 2 Enquire
027 12B0212CP
Suspension Unit - Tenneco - Front - RH 		$10,864.50 1
028 12B0610CP
Accumulator - Suspension 		$8,666.20 2
029 12B0132CP
Micro Automatic - Pressure Monitoring Unit 		$2,585.85 2
030 00RA065
SCREW - M6X12-8.8 - FLANGE HEX 		- 7 Enquire
031 12B0463CP
Bracket - Support - Front Pipes - Kinetic Damper
Superseded parts: 12B0463CP; 		- 2 Enquire
032 12B0127CP
Hose Assy - Kinetic Damper - Bump - Front - LH 		$1,061.35 1
033 00RA011
NUT-HEX HEAD-FLANGE-M6-8 		- 10 Enquire
034 00RA099
SCREW - M4X25 - HEX 		- 8 Enquire
035 00RB003
P Clip - DIA 14 		- 14 Enquire
036 00RB131
HOSE SEPERATOR PHS6 		- 2 Enquire
037 12B0129CP
Hose Assy - Kinetic Damper - Rebound - Front - LH 		$2,257.78 1
038 12B0534CP
Pipe - Feed - Kinetic Damper - Front - LH 		$443.82 1
039 00RB098
P-CLIP - DIA 10 - SILICONE 		- 3 Enquire
040 12B0535CP
Pipe Assy - Kinetic Damper - Feed - Front - RH 		$2,566.56 1
041 12B0130CP
Hose Assy - Kinetic Damper - Rebound - Front - RH 		$1,042.04 1
042 12B0459CP
Hose Assy - Kinetic Damper - Bump - Front - RH 		$2,373.60 1
043 00RA357
PIPE PROTECTOR 		- 1 Enquire
045 12B0742CP
Bango Bolt - Pipe - Kenectic Damper 		$192.95 4
046 12B0743CP
WASHER - PIPE - KENECTIC DAMPER 		$38.32 8
