Lamborghini Diablo (1990-1998) - Differential (Valid for June 1992 Version)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Differential (Valid for June 1992 Version) of Lamborghini Lamborghini Diablo (1990-1998) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 8575501
RETAINING RING
(Valid for June 1992 version) ANELLO RITEGNO 		$1.23 (82.7% off) 2
002 410103520
BEARING
(Valid for June 1992 version) CUSCINETTO 		$65.11 1
003 2331406
PROPELLER SHAFT
(Valid for June 1992 version) ALBERO DI TRASMISSIONE 		$3,066.64 1
004 8613508
SEAL
(Valid for June 1992 version) ANELLO TENUTA 		$165.80 1
005 8503010
BEARING
(Valid for June 1992 version) CUSCINETTO 		$20.35 (10.7% off) 1
006 2324939
SHIM
(Valid for June 1992 version)SPESSORE DI REGISTRO 		$40.76 1
007 2324938
FLANGE
(Valid for June 1992 version) FLANGIA PORTACUSCINETTI 		$750.83 (10.1% off) 1
008 8410815
WASHER
(Valid for June 1992 version) RONDELLA 		$0.21 (97.2% off) 4
009 2330696
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 0.2 MM 		$38.02 1
009 2330697
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 0.15 MM 		$22.93 (10.6% off) 1
009 2330695
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 0.25 MM 		$38.02 1
009 2330693
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 0.5 MM 		$22.93 (10.6% off) 1
009 2330694
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 0.3 MM 		$38.02 1
010 2328764
SPACER
(Valid for June 1992 version) DISTANZIALE 		$57.90 (7.8% off) 1
011 8100803
SCREW M8X1,25X25
(Valid for June 1992 version) VITE 		$0.47 (93.6% off) 4
012 8545004
BEARING
(Valid for June 1992 version) CUSCINETTO 		$145.58 2
013 2333371
PINION
(Valid for June 1992 version) PIGNONE (dalla 12728 intercambiabile) (Per esigenze di lavorazione questo particolare e fornito assieme alia corona 002324937) 		- 1 Enquire
013 2326586
PINION
(Valid for June 1992 version) PIGNONE CON GIUNZIONE (fino 12727) 		- 1 Enquire
014 2325117
THRUST PLATE
(Valid for June 1992 version) RALLA 		$77.21 2
015 8545002
BEARING
(Valid for June 1992 version) CUSCINETTO 		$555.75 2
016 2324942
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 		$51.36 1
017 2324452
FLANGE
(Valid for June 1992 version) FLANGIA PORTA CUSCINETTO 		$236.29 (8.1% off) 1
018 8301032
STUD
(Valid for June 1992 version) PRIGIONIERO 		$9.82 6
019 8614507
SEAL
(Valid for June 1992 version) ANELLO TENUTA 		$46.34 2
020 WHT000768
WASHER
IN STOCK 		$1.83 (74.9% off) 6
021 N10155210
NUT
(Valid for June 1992 version) DADO
IN STOCK 		$2.01 (72.2% off) 6
022 2331911
HUB
(Valid for June 1992 version) MOZZO PORTA SEMIASSE 		- 2 Enquire
023 2332653
WASHER
(Valid for June 1992 version) RONDELLA 		$114.04 2
024 2332652
WASHER
(Valid for June 1992 version) RONDELLA 		$9.01 (8.5% off) 2
025 2332651
SCREW
(Valid for June 1992 version) VITE 		$20.92 (10.4% off) 1
026 8583502
RETAINER RING
(Valid for June 1992 version) ANELLO RITEGNO 		$3.02 1
027 8523514
BEARING
(Valid for June 1992 version) CUSCINETTO A RULLINI 		$56.62 1
028 8575000
RETAINER RING
(Valid for June 1992 version) ANELLO RITEGNO 		$0.75 1
029 8254503
PLUG
(Valid for June 1992 version) GHIERA 		$181.31 1
030 2331921
SHIM
(Valid for June 1992 version) SPESSORE Dl REGISTRO 		$22.93 (10.6% off) 1
030 2331920
SHIM
(Valid for June 1992 version) SPESSORE Dl REGISTRO 		$22.93 (10.6% off) 1
030 2331919
SHIM
(Valid for June 1992 version) SPESSORE Dl REGISTRO 		$22.93 (10.6% off) 1
030 2331918
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 		$22.93 (10.6% off) 1
030 2331917
SHIM
(Valid for June 1992 version) SPESSORE DI REGISTRO 		$26.76 1
031 2324940
BEARING CASE
(Valid for June 1992 version) ANELLO PORTACUSCINETTO 		$1,218.32 1
032 2332650
SCREW
(Valid for June 1992 version) VITE 		$25.42 (7.7% off) 1
033 8900503
PIN - SPINA
(Valid for June 1992 version) SA 		$0.95 1
034 2324937
CROWN
(Valid for June 1992 version) CORONA (Per esigenze di lavorazione questo particolare e fornito assieme al pignone 002333371) 		- 1 Enquire
035 2332210
KIT DIFFERENTIAL
(Valid for June 1992 version) COMPLESSIVO DIFFERENZIALE 		- 1 Enquire
036 2324935
RIGID SLEEVE
(Valid for June 1992 version) GIUNZIONE (particolare fornito ora singolarmente) 		$359.92 1
