Folding Hood Assembly (Volante)

Aston Martin DBS V12

Find Your Part

Aston Martin DBS V12 - Folding Hood Assembly (Volante)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
9G4370351DA CANOPY COVER CG WESTMINSTER GREEN KIT $7,873.90 To Order
9G4370351CA CANOPY COVER CG JAVA KIT $7,873.90 To Order
9G4370351BA Canopy Cover Kit, Atlantic Blue $7,873.88 To Order
...and 3 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
9G4370352AB Inner Lining, Obsidian Black $2,464.00 To Order
9G4370352EB Inner Lining, New Light Tan $2,464.00 To Order
9G4370352DB INNER LINING CG TAILORS GREY $2,464.00 To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
4G43L51210AB FRT SL SPR PRT ASY K $1,078.05 To Order
Photo Part No Description Price (each) Stock
4G43L51221AA MIDDLE SEAL SPARE PART RH ASSY KID $575.56 To Order
Photo Part No Description Price (each) Stock
4G43L51220AA MIDDLE SEAL SPARE PART LH ASSY KIT $575.56 To Order
Photo Part No Description Price (each) Stock
4G43L51230AB RR SL SPR PRT ASY KT $945.14 To Order
Photo Part No Description Price (each) Stock
9G439G803AA Hydraulic Pump Assy, Includes All Cylinders & Hoses $4,065.35 IN STOCK
Photo Part No Description Price (each) Stock
9G43L31123AA Enclosure, pump assy Enquire To Order
Photo Part No Description Price (each) Stock
4G433710686 Harness, Roof Hydraulics, RH $180.24 To Order
4G433710685 Harness, Roof Hydraulics, LH $154.68 To Order
Photo Part No Description Price (each) Stock
4G43L51240AA CONVERTIBLE ROOF LATCH MOTOR KIT $333.41 IN STOCK
Photo Part No Description Price (each) Stock
4G43L51270AA FULLY AUTOMOTIVE LATCHING RH KIT $757.72 To Order
4G43L51260AA FULLY AUTOMATIC LATCHING LH KIT $749.12 To Order
Photo Part No Description Price (each) Stock
4G43765010BA STRIKER HEADER RH $97.62 To Order
4G43765011BA STRIKER HEADER LH $97.62 To Order
Photo Part No Description Price (each) Stock
4G43765013AF LATCH BRKT HARNESS $112.81 To Order
Photo Part No Description Price (each) Stock
9G3380899AA Screw, M4x5mm Enquire To Order
Photo Part No Description Price (each) Stock
4G431012524AA Flex Shaft, RH $86.67 To Order
Photo Part No Description Price (each) Stock
4G431012525AA Flex Shaft, LH $86.67 To Order
Photo Part No Description Price (each) Stock
4G439310617 HEADER TRIM KIT DB9 VOLANTE-BLACK $1,431.28 To Order
4G439310616 HEADER TRIM KIT DB9 VOLANTE TAILORS GREY $1,431.28 To Order
4G439310615 HEADER TRIM KIT DB9 VOLANTE MOONSHADOW $1,431.28 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
9G43L53085AE Bracket - Convertible Roof Module $1,570.92 To Order
View All
Folding Hood Assembly (Volante) of Aston Martin Aston Martin DBS V12 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 9G4376501B00BF
Top Assembly Folding, Complete 		$21,532.99 1
1 9G4370351DA
CANOPY COVER CG WESTMINSTER GREEN KIT
Westminster Green 		$7,873.90 1
1 9G4370351CA
CANOPY COVER CG JAVA KIT
Java/ Sandstone 		$7,873.90 1
1 9G4370351BA
Canopy Cover Kit, Atlantic Blue
Atlantic Blue 		$7,873.88 1
1 9G4370351EA
CANOPY COVER CG TITAN GREY KIT
Titan Grey 		$7,873.91 1
1 9G4370351FA
CANOPY COVER CG BURGUNDY KIT
Burgundy 		$13,282.85 1
1 9G4370351AA
CANOPY COVER CG BLACK KIT
Black 		$7,873.88 1
2 9G4370352AB
Inner Lining, Obsidian Black
Obsidian Black 		$2,464.00 1
2 9G4370352EB
Inner Lining, New Light Tan
New Light Tan 		$2,464.00 1
2 9G4370352DB
INNER LINING CG TAILORS GREY
Tailors Grey 		$2,464.00 1
2 9G4370352CB
INNER LINING CG MOON SHADOW
Moon Shadow 		$2,464.00 1
2 9G4370352BB
INNER LINING CG IVORY
Ivory 		$2,464.00 1
3 4G43L51210AB
FRT SL SPR PRT ASY K 		$1,078.05 1
4 4G43L51221AA
MIDDLE SEAL SPARE PART RH ASSY KID 		$575.56 1
5 4G43L51220AA
MIDDLE SEAL SPARE PART LH ASSY KIT 		$575.56 1
6 4G43L51230AB
RR SL SPR PRT ASY KT 		$945.14 1
7 9G439G803AA
Hydraulic Pump Assy, Includes All Cylinders & Hoses
IN STOCK 		$4,065.35 1
8 9G43L31123AA
Enclosure, pump assy 		- 1 Enquire
9 4G433710686
Harness, Roof Hydraulics, RH 		$180.24 1
9 4G433710685
Harness, Roof Hydraulics, LH 		$154.68 1
10 4G43L51240AA
CONVERTIBLE ROOF LATCH MOTOR KIT
IN STOCK 		$333.41 1
12 4G43L51270AA
FULLY AUTOMOTIVE LATCHING RH KIT 		$757.72 1
12 4G43L51260AA
FULLY AUTOMATIC LATCHING LH KIT 		$749.12 1
15 4G43765010BA
STRIKER HEADER RH
attached to BIW 		$97.62 1
15 4G43765011BA
STRIKER HEADER LH
attached to BIW 		$97.62 1
16 4G43765013AF
LATCH BRKT HARNESS 		$112.81 1
17 9G3380899AA
Screw, M4x5mm 		- 1 Enquire
18 4G431012524AA
Flex Shaft, RH 		$86.67 1
19 4G431012525AA
Flex Shaft, LH 		$86.67 1
20 4G439310617
HEADER TRIM KIT DB9 VOLANTE-BLACK
Obsidian Black 		$1,431.28 1
20 4G439310616
HEADER TRIM KIT DB9 VOLANTE TAILORS GREY
Tailors Grey 		$1,431.28 1
20 4G439310615
HEADER TRIM KIT DB9 VOLANTE MOONSHADOW
Moon Shadow 		$1,431.28 1
20 4G439310614
HEADER TRIM KIT DB9 VOLANTE-IVORY
Ivory 		$1,431.28 1
21 9G43L53085AE
Bracket - Convertible Roof Module
Incl Bracket 		$1,570.92 1
