Lamborghini Murcielago LP670 - Frame Elements 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	418817299	ROOF	418817299 ROOF	$13,239.35	1
002	418809201	LH OUTER PILLAR FRONT	418809201 LH OUTER PILLAR FRONT	$917.58	1
003	418809202	RH OUTER PILLAR FRONT	418809202 RH OUTER PILLAR FRONT	$917.58	1
004	418813891	LH ANGLE IRON UPPER	418813891 LH ANGLE IRON UPPER	$144.18	1
005	418813892	RH ANGLE IRON UPPER	418813892 RH ANGLE IRON UPPER	$144.18	1
006	418845502	REAR WINDOW CROSSMEMBER	418845502 REAR WINDOW CROSSMEMBER	$262.79	1
007	418817369	ROOF EXTENSION PANEL BRACKET	418817369 ROOF EXTENSION PANEL BRACKET	$91.04	2
008	418845501	REAR WINDOW CROSSMEMBER INNER	418845501 REAR WINDOW CROSSMEMBER INNER	$627.94	1
009	418817201	REAR WINDOW SURROUND	418817201 REAR WINDOW SURROUND	$734.06	1
013	410802599	LH - SHEET B INNER LOWER	410802599 LH - SHEET B INNER LOWER	$845.19	1
014	410802600	RH - SHEET B INNER LOWER	410802600 RH - SHEET B INNER LOWER	$845.19	1
015	418867285	LH - B PILLAR INNER UPPER	418867285 LH - B PILLAR INNER UPPER	$966.26	1
016	418867286	RH - B PILLAR INNER UPPER	418867286 RH - B PILLAR INNER UPPER	$966.26	1
017	418809607	LH B PILLAR REINFORCEMENT	418809607 LH B PILLAR REINFORCEMENT	$845.19	1
018	418809608	RH B PILLAR REINFORCEMENT	418809608 RH B PILLAR REINFORCEMENT	$797.92	1
019	418853171	LH A PILLAR INNER UPPER	418853171 LH A PILLAR INNER UPPER	$3,046.11	1
020	418853172	RH A PILLAR INNER UPPER	418853172 RH A PILLAR INNER UPPER	$3,046.11	1
021	418809193	LH A PILLAR RENFORCEMENT	418809193 LH A PILLAR RENFORCEMENT	$1,329.57	1
022	418809194	RH A PILLAR RENFORCEMENT	418809194 RH A PILLAR RENFORCEMENT	$1,329.57	1
023	418810207	LH REINFORCEMENT ON A PILLAR INNER UPPER	418810207 LH REINFORCEMENT ON A PILLAR INNER UPPER	$220.35	1
024	418810208	RH REINFORCEMENT ON A PILLAR INNER UPPER	418810208 RH REINFORCEMENT ON A PILLAR INNER UPPER	$220.35	1
037	418805573	WINDSCREEN CROSSMEMBER	418805573 WINDSCREEN CROSSMEMBER	$1,947.52	1
038	418845425	WINDSCREEN CROSSMEMBER INNER	418845425 WINDSCREEN CROSSMEMBER INNER	$604.24	1
