Front Seats: Mechanics And Electronics

Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP

Illustration Number: 09413

Find Your Part

Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP - FRONT SEATS: MECHANICS AND ELECTRONICS (09413)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670009999 LH SEAT WIRING HARNESS $258.72 To Order
670009998 LH SEAT WIRING HARNESS $237.57 IN STOCK
670009998 LH SEAT WIRING HARNESS $237.57 IN STOCK
...and 7 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
673000294 PUSH-BUTTON SWITCH $40.91 To Order
Photo Part No Description Price (each) Stock
670173854 8-WAY SWITCH $79.77 To Order
670186720 8-WAY SWITCH $73.65 To Order
670173853 8-WAY SWITCH $73.65 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
670173855 LUMBAR SUPPORT ADJUSTMENT JOYSTICK $69.40 To Order
Photo Part No Description Price (each) Stock
673000320 FRONT SEAT BACK FAN $283.66 To Order
Photo Part No Description Price (each) Stock
673000321 SEAT FAN $234.58 To Order
Photo Part No Description Price (each) Stock
670221098 FRONT SEAT SETTING ECU $58.00 To Order
670221098 FRONT SEAT SETTING ECU $58.00 To Order
Photo Part No Description Price (each) Stock
673000318 LH SUPPORT $19.32 To Order
673000319 RH SUPPORT $19.32 To Order
Photo Part No Description Price (each) Stock
673007413 FRONT SEAT BACK FRAME $405.91 To Order
673007414 FRONT SEAT BACK FRAME $357.45 To Order
Photo Part No Description Price (each) Stock
673000229 FRONT CUSHION FRAME $636.31 To Order
673000230 FRONT CUSHION FRAME $635.23 To Order
673000232 FRONT CUSHION FRAME $553.40 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
673000233 SCREW $5.16 To Order
Photo Part No Description Price (each) Stock
670006705 SEATBACK REAR PANEL LED LIGHT $40.01 To Order
Photo Part No Description Price (each) Stock
673000234 BRACKET $14.11 To Order
Photo Part No Description Price (each) Stock
670006649 TRIM PLATE $6.24 To Order
Photo Part No Description Price (each) Stock
673000325 SCREW $2.15 To Order
Photo Part No Description Price (each) Stock
670006150 SUPPORT $10.57 To Order
Photo Part No Description Price (each) Stock
670007533 FRONT BRACKET $22.66 To Order
Photo Part No Description Price (each) Stock
673000291 LH SIDE CASING MOUNTING BRACKET $28.87 To Order
673000292 RH SIDE CASING MOUNTING BRACKET $28.87 To Order
Photo Part No Description Price (each) Stock
670035027 HEATER-FAN ECU $176.74 To Order
Photo Part No Description Price (each) Stock
673000299 CONTROL UNIT BRACKET $8.35 To Order
Photo Part No Description Price (each) Stock
670006706 AIR VENT $40.42 To Order
Photo Part No Description Price (each) Stock
673007373 CPL. FRONT SEAT BACK HEATER $195.95 To Order
Photo Part No Description Price (each) Stock
673006942 CPL. FRONT SEAT BACK HEATER $97.15 To Order
Photo Part No Description Price (each) Stock
670006155 SBR SENSOR $50.18 To Order
Photo Part No Description Price (each) Stock
673006941 CPL. FRONT SEAT CUSHION HEATER $621.33 To Order
Photo Part No Description Price (each) Stock
673006939 CPL. FRONT SEAT CUSHION HEATER $207.79 To Order
Photo Part No Description Price (each) Stock
673000326 RIVET $1.76 To Order
Photo Part No Description Price (each) Stock
673007405 PLASTIC FRONT BACK SHELL $12.65 To Order
Photo Part No Description Price (each) Stock
673007406 PLASTIC REAR BACK SHELL $11.98 To Order
View All
FRONT SEATS: MECHANICS AND ELECTRONICS of Maserati Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670009999
LH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS, FRONT SEAT VENTILATION Not available with: SEAT TRACK POSITION; EU CN US CD JP ME KO; 		$258.72 1
1 670009998
LH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS Not available with: SEAT TRACK POSITION, FRONT SEAT VENTILATION; EU CN US CD JP ME KO;
IN STOCK 		$237.57 1
1 670009998
LH SEAT WIRING HARNESS
Not available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS, SEAT TRACK POSITION, FRONT SEAT VENTILATION; EU CN US CD JP ME KO;
IN STOCK 		$237.57 1
1 670031343
RH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS, FRONT SEAT VENTILATION Not available with: SEAT TRACK POSITION; EU CN US CD JP ME KO; 		$296.25 1
1 670031342
RH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS Not available with: SEAT TRACK POSITION, FRONT SEAT VENTILATION; EU CN US CD JP ME KO; 		$237.57 1
1 670031341
RH SEAT WIRING HARNESS
Not available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS, SEAT TRACK POSITION, FRONT SEAT VENTILATION; EU CN US CD JP ME KO; 		$202.94 1
1 670007820
LH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS, FRONT SEAT VENTILATION Not available with: SEAT TRACK POSITION; AU UK JRH IN SA; 		$343.36 1
1 670007823
RH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS, FRONT SEAT VENTILATION Not available with: SEAT TRACK POSITION; AU UK JRH IN SA; 		$336.63 1
1 670007819
LH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS Not available with: SEAT TRACK POSITION, FRONT SEAT VENTILATION; AU UK JRH IN SA; 		$309.71 1
1 670007822
RH SEAT WIRING HARNESS
Available with: ELECTRICALLY HEATED ADJUSTABLE FRONT SEATS Not available with: SEAT TRACK POSITION, FRONT SEAT VENTILATION; AU UK JRH IN SA; 		$305.86 1
2 673000294
PUSH-BUTTON SWITCH
EU CN US CD JP ME KO; 		$40.91 1
3 670173854
8-WAY SWITCH
Driver side; Bespoke Assembly Number 6079467 - 99999999; EU CN US CD JP ME KO; 		$79.77 1
3 670186720
8-WAY SWITCH
Passenger side; Bespoke Assembly Number 6079467 - 99999999; EU CN US CD JP ME KO; 		$73.65 1
3 670173853
8-WAY SWITCH
Driver side; Bespoke Assembly Number 6079467 - 99999999; AU UK JRH IN SA; 		$73.65 1
3 670186721
8-WAY SWITCH
Passenger side; Bespoke Assembly Number 6079467 - 99999999; AU UK JRH IN SA; 		$79.77 1
4 670173855
LUMBAR SUPPORT ADJUSTMENT JOYSTICK
Bespoke Assembly Number 6079467 - 99999999; 		$69.40 1
5 673000320
FRONT SEAT BACK FAN
Available with: FRONT SEAT VENTILATION ; 		$283.66 1
6 673000321
SEAT FAN
Available with: FRONT SEAT VENTILATION ; 		$234.58 2
7 670221098
FRONT SEAT SETTING ECU
Bespoke Assembly Number 0 - 6112335; 		$58.00 1
7 670221098
FRONT SEAT SETTING ECU
Bespoke Assembly Number 6112336 - 99999999; 		$58.00 1
8 673000318
LH SUPPORT 		$19.32 1
8 673000319
RH SUPPORT 		$19.32 1
9 673007413
FRONT SEAT BACK FRAME
Without memory; 		$405.91 1
9 673007414
FRONT SEAT BACK FRAME
With memory; 		$357.45 1
10 673000229
FRONT CUSHION FRAME
Driver side; Not available with: ELECTRICALLY ADJUSTABLE FRONT SEATS ON DRIVER'S SIDE, ELECTRICALLY ADJUSTABLE FRONT SEATS; EU CN US CD JP ME KO; 		$636.31 1
10 673000230
FRONT CUSHION FRAME
Passenger side; Not available with: ELECTRICALLY ADJUSTABLE FRONT SEATS ON DRIVER'S SIDE, ELECTRICALLY ADJUSTABLE FRONT SEATS; EU CN US CD JP ME KO; 		$635.23 1
10 673000232
FRONT CUSHION FRAME
Driver side; Not available with: ELECTRICALLY ADJUSTABLE FRONT SEATS ON DRIVER'S SIDE, ELECTRICALLY ADJUSTABLE FRONT SEATS; AU UK JRH IN SA; 		$553.40 1
10 673000231
FRONT CUSHION FRAME
Passenger side; Not available with: ELECTRICALLY ADJUSTABLE FRONT SEATS ON DRIVER'S SIDE, ELECTRICALLY ADJUSTABLE FRONT SEATS; AU UK JRH IN SA; 		$569.55 1
11 673000233
SCREW 		$5.16 4
12 670006705
SEATBACK REAR PANEL LED LIGHT 		$40.01 1
13 673000234
BRACKET 		$14.11 1
14 670006649
TRIM PLATE 		$6.24 2
15 673000325
SCREW 		$2.15 2
16 670006150
SUPPORT 		$10.57 1
17 670007533
FRONT BRACKET 		$22.66 1
18 673000291
LH SIDE CASING MOUNTING BRACKET 		$28.87 1
18 673000292
RH SIDE CASING MOUNTING BRACKET 		$28.87 1
19 670035027
HEATER-FAN ECU 		$176.74 1
20 673000299
CONTROL UNIT BRACKET 		$8.35 1
21 670006706
AIR VENT
Available with: FRONT SEAT VENTILATION ; 		$40.42 1
23 673007373
CPL. FRONT SEAT BACK HEATER
Available with: FRONT SEAT VENTILATION ; 		$195.95 1
24 673006942
CPL. FRONT SEAT BACK HEATER
Not available with: FRONT SEAT VENTILATION; 		$97.15 1
25 670006155
SBR SENSOR
Passenger side; 		$50.18 1
26 673006941
CPL. FRONT SEAT CUSHION HEATER
Not available with: FRONT SEAT VENTILATION; 		$621.33 1
27 673006939
CPL. FRONT SEAT CUSHION HEATER
Available with: FRONT SEAT VENTILATION ; 		$207.79 1
28 673000326
RIVET 		$1.76 3
29 673007405
PLASTIC FRONT BACK SHELL 		$12.65 1
30 673007406
PLASTIC REAR BACK SHELL 		$11.98 1
