Gearbox Control Tower of Lamborghini Lamborghini Diablo VT 6.0 (2000-2001)

View All

Lamborghini Diablo VT 6.0 (2000-2001) - Gearbox Control Tower

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	24004603	KNOB	24004603 KNOB	$1,497.62	1
002	2433043	BOOT	2433043 BOOT	$111.05	1
003	2434091	BALL SOCKFT	2434091 BALL SOCKFT	$224.35 MSRP: ~~243.50~~ (7.9% off)	1
004	2427202	CYLINDER	2427202 CYLINDER	$79.23	1
005	2432167	SPRING	2432167 SPRING	$11.34 MSRP: ~~12.70~~ (10.7% off)	1
006	2427204	PLUG	2427204 PLUG	$9.61 MSRP: ~~10.40~~ (7.6% off)	1
007	8572201	RETAINER RING IN STOCK	8572201 RETAINER RING IN STOCK	$0.07 MSRP: ~~7.38~~ (99.1% off)	1
008	2433020	BUSHING	2433020 BUSHING	$73.15	2
009	2437666	LEVER	2437666 LEVER	$1,162.26 MSRP: ~~1,300.00~~ (10.6% off)	1
010	8700644	SCREW	8700644 SCREW	$0.35 MSRP: ~~7.34~~ (95.2% off)	4
011	8410602	WASHER IN STOCK	8410602 WASHER IN STOCK	$41.82	4
012	24005155	SPRING	24005155 SPRING	$34.98 MSRP: ~~37.85~~ (7.6% off)	1
013	2427207	BUSHING	2427207 BUSHING	$299.54	1
014	2429161	SHAFT	2429161 SHAFT	$283.93 MSRP: ~~308.00~~ (7.8% off)	1
015	8900305	PIN - SPINA	8900305 PIN - SPINA	$0.25 MSRP: ~~7.35~~ (96.6% off)	1
016	410711615	RH JOINT	410711615 RH JOINT	$1,017.08	1
017	8201224	NUT	8201224 NUT	-	1	Enquire
018	2434472	TIE ROD	2434472 TIE ROD	$36.44 MSRP: ~~39.45~~ (7.6% off)	1
019	8201223	NUT	8201223 NUT	-	1	Enquire
020	8830305	CLAMP	8830305 CLAMP	$0.37 MSRP: ~~7.33~~ (95% off)	2
021	2434614	BOOT	2434614 BOOT	-	1	Enquire
022	2408637	SWITCH	2408637 SWITCH	$109.29	1
023	8410817	WASHER	8410817 WASHER	$4.46	4
024	N01029315	SCREW (FROM VIN 5LA01545)	N01029315 SCREW (FROM VIN 5LA01545)	$2.26 MSRP: ~~7.23~~ (68.7% off)	4
025	240132017	MACHINED CASE	240132017 MACHINED CASE	$1,280.40	1
026	8410820	WASHER	8410820 WASHER	$0.18 MSRP: ~~7.37~~ (97.6% off)	4
027	8700804	SCREW IN STOCK	8700804 SCREW IN STOCK	$1.52 MSRP: ~~7.33~~ (79.3% off)	4
028	24006223	SPACER	24006223 SPACER	$274.68 MSRP: ~~297.00~~ (7.5% off)	1
029	2433904	PLATE (REVERSE)	2433904 PLATE (REVERSE)	$749.40	1
030	24005218	PLATE	24005218 PLATE	$1,022.73	1
031	8740640	SCREW IN STOCK	8740640 SCREW IN STOCK	$0.37 MSRP: ~~7.32~~ (94.9% off)	2
032	2431785	FLEX PAD	2431785 FLEX PAD	-	1	Enquire
