Find Your Part

Photo Part No Description Price (each) Stock
247589 ELECTRO-INJECTOR $162.50 To Order
247588 ELECTRO-INJECTOR $162.50 To Order
Photo Part No Description Price (each) Stock
231926 CLIP $5.39 To Order
Photo Part No Description Price (each) Stock
246615 Spark Plug $30.86 IN STOCK
Photo Part No Description Price (each) Stock
281449 Ignition Coil $101.37 IN STOCK
281449 Ignition Coil $101.37 IN STOCK
281449 Ignition Coil $101.37 IN STOCK
Photo Part No Description Price (each) Stock
274645 LH INJECTION WIRING HARNESS $1,326.97 To Order
274645 LH INJECTION WIRING HARNESS $1,326.97 To Order
268673 LH INJECTION WIRING HARNESS $921.86 To Order
...and 4 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
238263 IGNITION ECU $2,242.65 To Order
238263 IGNITION ECU $2,242.65 To Order
238263 IGNITION ECU $2,242.65 To Order
...and 16 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
228677 LH BRACKET $131.71 To Order
283210 LH BRACKET $86.11 To Order
Photo Part No Description Price (each) Stock
16296924 SCREW $0.75 To Order
16286124 SCREW $0.75 To Order
Photo Part No Description Price (each) Stock
191273 CLIP $0.75 To Order
320598 CLIP $1.27 To Order
Photo Part No Description Price (each) Stock
251812 L.H. FRONT BRACKET $30.34 To Order
Photo Part No Description Price (each) Stock
248391 L.H. REAR BRACKET $24.64 To Order
Photo Part No Description Price (each) Stock
67885100 CLIP $0.96 To Order
Photo Part No Description Price (each) Stock
236876 CONTROL UNIT FIXING BRACKET $6.90 To Order
Photo Part No Description Price (each) Stock
251811 HEAT SHIELD $34.43 To Order
# Part Details Price
(each)
Qty on
Diagram
Add to
Cart
1 247589
ELECTRO-INJECTOR
Pressure sensor side; Supplied with COMPL. INJECTOR PIPE, Tab.7 pos.14; No longer supplied
$162.50 2
1 247588
ELECTRO-INJECTOR
Opposite pressure sensor side; Supplied with COMPL. INJECTOR PIPE, Tab.7 pos.14; No longer supplied
$162.50 2
2 231926
CLIP
Supplied with COMPL. INJECTOR PIPE, Tab.7 pos.14; No longer supplied
$5.39 4
3 246615
Spark Plug
IN STOCK
$30.86 4
4 281449
Ignition Coil
Applicable from Ass. No. 105502
IN STOCK
$101.37 (41.9% off) 4
4 281449
Ignition Coil
No longer supplied; Replaced by 248404
IN STOCK
$101.37 (41.9% off) 4
4 281449
Ignition Coil
Applicable up to Ass. No. 105501
IN STOCK
$101.37 (41.9% off) 4
5 274645
LH INJECTION WIRING HARNESS
Applicable for Soft Start; Applicable from MY 11; Applicable for USA, CDN, USA LIGHT
$1,326.97 1
5 274645
LH INJECTION WIRING HARNESS
Applicable for Soft Start; Not for USA, CDN, GD, USA LIGHT; Applicable from Ass. No. 97352
$1,326.97 1
5 268673
LH INJECTION WIRING HARNESS
Applicable for HELE; Applicable for Stop & Start; Applicable from Ass. No. 95558 up to Ass. No. 103178
$921.86 1
5 283503
LH INJECTION WIRING HARNESS
Applicable for HELE; Applicable for Stop & Start; See note A for Ass. Numbers of vehicles not affected by modification; Applicable from Ass. No. 103179
$890.28 1
5 264125
LH INJECTION WIRING HARNESS
Not for Stop & Start; Applicable from Ass. No. 90971; Applicable from engine No. 159183
$881.86 1
5 264132
LH INJECTION WIRING HARNESS
Applicable for Stop & Start; Applicable up to Ass. No. 95557
$909.21 1
5 251899
LH INJECTION WIRING HARNESS
Not for Stop & Start; Applicable up to Ass. No. 90970; Applicable up to engine No. 159182
$893.80 1
6 238263
IGNITION ECU
Unprogrammed
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
China; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Korea; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 88123; Applicable from engine No. 153879; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Korea; Applicable up to Ass. No. 86422; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Korea; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 86423 up to Ass. No. 88122; Applicable up to engine No. 153878; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Not for DCT-F1 gearbox (Applicable for mechanical gearbox); Applicable for J; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for J; Applicable from Ass. No. 88123; Applicable from engine No. 153879; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Not for DCT-F1 gearbox (Applicable for mechanical gearbox); Applicable for USA, CDN, USA LIGHT; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for J; Applicable up to Ass. No. 88122; Applicable up to engine No. 153878; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for USA, CDN, USA LIGHT; Applicable from Ass. No. 88123; Applicable from engine No. 153879; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for USA, CDN, USA LIGHT; Applicable from Ass. No. 86423 up to Ass. No. 88122; Applicable up to engine No. 153878; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
MY 10; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for USA, CDN, USA LIGHT; Applicable from Ass. No. 85745 up to Ass. No. 86422; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
MY 09; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for USA, CDN, USA LIGHT; Applicable up to Ass. No. 85744; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Not for DCT-F1 gearbox (Applicable for mechanical gearbox); Not for USA, CDN, USA LIGHT; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Russia; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 88123; Applicable from engine No. 153879; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Taiwan; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 88123; Applicable from engine No. 153879; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Russia; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable up to Ass. No. 88122; Applicable up to engine No. 153878; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Not for CINA, USA, CDN, USA LIGHT; Applicable from Ass. No. 88123; Applicable from engine No. 153879; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
6 238263
IGNITION ECU
Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Not for CINA, USA, CDN, USA LIGHT; Applicable up to Ass. No. 88122; Applicable up to engine No. 153878; No longer supplied; Replaced by 238263
$2,242.65 (13.2% off) 1
7 228677
LH BRACKET
Applicable up to Ass. No. 103178
$131.71 1
7 283210
LH BRACKET
See note A for Ass. Numbers of vehicles not affected by modification; Applicable from Ass. No. 103179
$86.11 1
8 16296924
SCREW
Applicable up to Ass. No. 103178
$0.75 3
8 16286124
SCREW
See note A for Ass. Numbers of vehicles not affected by modification; Applicable from Ass. No. 103179
$0.75 4
9 191273
CLIP
D. 16.5
$0.75 1
9 320598
CLIP
D. 16
$1.27 2
10 251812
L.H. FRONT BRACKET
$30.34 1
11 248391
L.H. REAR BRACKET
$24.64 1
12 67885100
CLIP
$0.96 1
13 236876
CONTROL UNIT FIXING BRACKET
$6.90 1
14 251811
HEAT SHIELD
$34.43 1
