Front Seats - Racing Seat

Ferrari 12Cilindri

Find Your Part

Ferrari 12Cilindri - FRONT SEATS - RACING SEAT

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
886274 COMPL. LH RACING SEAT $45,267.42 To Order
973528 COMPL. LH RACING SEAT Enquire To Order
886275 COMPL. LH RACING SEAT $31,087.85 To Order
...and 21 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
884801 SPECIAL SCREW $1.52 To Order
Photo Part No Description Price (each) Stock
66155100 COVER $5.69 To Order
Photo Part No Description Price (each) Stock
900726 SEAT ARCH $390.37 To Order
Photo Part No Description Price (each) Stock
955855 COMPLETE MANUAL GUIDE $3,323.22 To Order
955857 COMPLETE MANUAL GUIDE $3,323.22 To Order
Photo Part No Description Price (each) Stock
894026 SCUFF GUARD $12.57 To Order
Photo Part No Description Price (each) Stock
900603 SEAT ADJUSTMENT KNOB $264.43 To Order
Photo Part No Description Price (each) Stock
900604 RH COVER PANEL FOR LH SEAT BACKREST $103.24 To Order
900605 RH COVER PANEL FOR RH SEAT BACKREST $93.17 To Order
Photo Part No Description Price (each) Stock
900606 LH COVER PANEL FOR LH SEAT BACKREST $93.17 To Order
900679 LH COVER PANEL FOR RH SEAT BACKREST $103.24 To Order
Photo Part No Description Price (each) Stock
900688 LH REAR BACKREST CASING $163.69 To Order
Photo Part No Description Price (each) Stock
900705 RH REAR BACKREST CASING $163.69 To Order
Photo Part No Description Price (each) Stock
900706 CASING FASTENER SCREW KIT $61.29 To Order
Photo Part No Description Price (each) Stock
900709 BACKREST ADJUSTMENT ROD Enquire To Order
Photo Part No Description Price (each) Stock
900720 BUCKLE STALK FASTENER KIT $176.28 To Order
Photo Part No Description Price (each) Stock
900723 COMPLETE LH SEAT WIRING HARNESS $133.79 To Order
900724 COMPLETE RH SEAT WIRING HARNESS Enquire To Order
55021533 COMPLETE SEAT WIRING HARNESS $642.22 To Order
Photo Part No Description Price (each) Stock
947642 SEAT ROD STOP $32.73 To Order
Photo Part No Description Price (each) Stock
55030696 OUTER COVER OF SEAT TILT MECHANISM ADJUSTMENT BUTTON $251.84 To Order
Photo Part No Description Price (each) Stock
917520 BUCKLE SECTION $214.07 To Order
Photo Part No Description Price (each) Stock
82140000 SCREW $2.76 IN STOCK
View All
FRONT SEATS - RACING SEAT of Ferrari Ferrari 12Cilindri Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 886274
COMPL. LH RACING SEAT
Driver- -Daytona- -Medium; With electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Not applicable for: GD 		$45,267.42 1
1 973528
COMPL. LH RACING SEAT
Passenger- -Daytona- -Medium; Without electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Applicable for: GD 		- 1 Enquire
1 886275
COMPL. LH RACING SEAT
Driver- -Daytona- -Large; With electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Not applicable for: GD 		$31,087.85 1
1 973530
COMPL. LH RACING SEAT
Passenger- -Daytona- -Large; Without electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Applicable for: GD 		- 1 Enquire
1 886276
COMPL. LH RACING SEAT
Driver- -Daytona- -Extra Large; With electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Not applicable for: GD 		$45,267.42 1
1 973533
COMPL. LH RACING SEAT
Passenger- -Daytona- -Extra Large; Without electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Applicable for: GD 		$45,387.69 1
1 886271
COMPL. LH RACING SEAT
Driver- -Corsa- -Medium; With electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish- -Select CIMP SI for matte carbon finish; Not applicable for: GD 		- 1 Enquire
1 973520
COMPL. LH RACING SEAT
Passenger- -Corsa- -Medium; Without electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Applicable for: GD 		- 1 Enquire
1 886272
COMPL. LH RACING SEAT
Driver- -Corsa- -Large; With electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Not applicable for: GD 		- 1 Enquire
1 973523
COMPL. LH RACING SEAT
Passenger- -Corsa- -Large; Without electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Applicable for: GD 		- 1 Enquire
1 886273
COMPL. LH RACING SEAT
Driver- -Corsa- -Extra Large; With electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Not applicable for: GD 		- 1 Enquire
1 973525
COMPL. LH RACING SEAT
Passenger- -Corsa- -Extra Large; Without electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Applicable for: GD 		$42,024.47 1
1 886280
COMPL. RH RACING SEAT
Passenger- -Daytona- -Medium; Without electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Not applicable for: GD 		$34,436.55 1
1 973542
COMPL. RH RACING SEAT
Driver- -Daytona- -Medium; With electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Applicable for: GD 		- 1 Enquire
1 886281
COMPL. RH RACING SEAT
Passenger- -Daytona- -Large; Without electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Not applicable for: GD 		- 1 Enquire
1 973544
COMPL. RH RACING SEAT
Driver- -Daytona- -Large; With electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Applicable for: GD 		- 1 Enquire
1 886282
COMPL. RH RACING SEAT
Passenger- -Daytona- -Extra Large; Without electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Not applicable for: GD 		- 1 Enquire
1 973546
COMPL. RH RACING SEAT
Driver- -Daytona- -Extra Large; With electric seat tilt mechanism - Gloss finish carbon version - INTP - DUAL - DAAL - CLDT - ALDT - STP1 - STP2 - 1CAV - EMPH - STC1 - STC2; Applicable for: GD 		- 1 Enquire
1 886277
COMPL. RH RACING SEAT
Passenger- -Corsa- -Medium; Without electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Not applicable for: GD 		- 1 Enquire
1 973536
COMPL. RH RACING SEAT
Driver- -Corsa- -Medium; With electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Applicable for: GD 		- 1 Enquire
1 886278
COMPL. RH RACING SEAT
Passenger- -Corsa- -Large; Without electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Not applicable for: GD 		- 1 Enquire
1 973538
COMPL. RH RACING SEAT
Driver- -Corsa- -Large; With electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Applicable for: GD 		- 1 Enquire
1 886279
COMPL. RH RACING SEAT
Passenger- -Corsa- -Extra Large; Without electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Not applicable for: GD 		- 1 Enquire
1 973540
COMPL. RH RACING SEAT
Driver- -Corsa- -Extra Large; With electric seat tilt mechanism - INTP - DUAL - DAAL - CLDT - ALDT - 1CAV - EMPH - CIMP - STC1 - STC2 - Select CIMP NO for gloss carbon finish - Select CIMP SI for matte carbon finish; Applicable for: GD 		- 1 Enquire
2 884801
SPECIAL SCREW
M10 x 1.25 		$1.52 8
3 66155100
COVER 		$5.69 (26.7% off) 2
4 900726
SEAT ARCH 		$390.37 2
5 955855
COMPLETE MANUAL GUIDE
Without seat tilt mechanism 		$3,323.22 4
5 955857
COMPLETE MANUAL GUIDE
With seat tilt mechanism 		$3,323.22 2
6 894026
SCUFF GUARD 		$12.57 4
7 900603
SEAT ADJUSTMENT KNOB 		$264.43 2
8 900604
RH COVER PANEL FOR LH SEAT BACKREST 		$103.24 1
8 900605
RH COVER PANEL FOR RH SEAT BACKREST 		$93.17 1
9 900606
LH COVER PANEL FOR LH SEAT BACKREST 		$93.17 1
9 900679
LH COVER PANEL FOR RH SEAT BACKREST 		$103.24 1
10 900688
LH REAR BACKREST CASING 		$163.69 2
11 900705
RH REAR BACKREST CASING 		$163.69 2
12 900706
CASING FASTENER SCREW KIT 		$61.29 1
13 900709
BACKREST ADJUSTMENT ROD 		- 2 Enquire
14 900720
BUCKLE STALK FASTENER KIT 		$176.28 2
16 900723
COMPLETE LH SEAT WIRING HARNESS
Driver side; Not applicable for: GD 		$133.79 1
16 900724
COMPLETE RH SEAT WIRING HARNESS
Driver side; Applicable for: GD 		- 1 Enquire
16 55021533
COMPLETE SEAT WIRING HARNESS
Passenger side 		$642.22 1
17 947642
SEAT ROD STOP 		$32.73 1
18 55030696
OUTER COVER OF SEAT TILT MECHANISM ADJUSTMENT BUTTON 		$251.84 1
19 917520
BUCKLE SECTION 		$214.07 2
20 82140000
SCREW
M10 X 1.25 X 25
IN STOCK 		$2.76 (34.3% off) 8
