Volante Roof and Upper Trim of Aston Martin Aston Martin DB7 Vantage

View All

Aston Martin DB7 Vantage - Volante Roof and Upper Trim

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	93110874BAW	ASSEMBLY - COMPLETE CONVERTIBLE HOOD	$16,416.49	To Order
	93100529BAW	ASSY COVER (MOHAIR) OUTER	$4,931.37	To Order
	9389695	TENSION WIRE ASSY RR	$78.92	To Order

Photo	Part No	Description	Price (each)	Stock
	88111770BAW	TONNEAU COVER -HAARTZ TWILLFAST II	$3,252.45	To Order
	88123912BAW	TONNEAU COVER - LEATHER/PIPED	$7,914.75	To Order
	88111772BAW	TONNEAU COVER -EVERFLEX	$3,176.27	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	12008	Calico	$14.15	To Order

Photo	Part No	Description	Price (each)	Stock
	83140144ABW	Headlining assy, quilted	Enquire	To Order
	83140174ABW	Headlining assy, ribbed	Enquire	To Order
	93100548BAW	ASSY HOOD HEADLINING (ALCANTARA)	$5,291.98	To Order

Photo	Part No	Description	Price (each)	Stock
	692205	POP-RIVET 1/8 x3/8	$0.47	To Order

Photo	Part No	Description	Price (each)	Stock
	9389749	WEBBING FIXING PLATE	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	696578	SCREW No 6 X 1/2" CSK POZI GRD 4 8 ZINC BLACK PASSIVATE	$0.08	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	696578	SCREW No 6 X 1/2" CSK POZI GRD 4 8 ZINC BLACK PASSIVATE	$0.08	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	9389513	RAIL RETAINING H/LINING RR CENTRE	$35.10	To Order

Photo	Part No	Description	Price (each)	Stock
	9389514	RAIL RETAINING H/LINING RR OUTER	$38.85	To Order

Photo	Part No	Description	Price (each)	Stock
	9389552	CAM ADJUSTER	$7.01	To Order

Photo	Part No	Description	Price (each)	Stock
	697078	Screw, flg, M8 x 20	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	9389748	ROD STRAP INSERT 70mm long	$47.78	To Order

Photo	Part No	Description	Price (each)	Stock
	9389670	WIRE TUBE TENSION	$2.19	To Order

Photo	Part No	Description	Price (each)	Stock
	697066	POP RIVET 3-2X11	$0.11	To Order

Photo	Part No	Description	Price (each)	Stock
	9389671	SIDE TENSION WIRE ASSY	$55.22	To Order

Photo	Part No	Description	Price (each)	Stock
	9389669	WIRE SPRING TENSION	$3.34	To Order

Photo	Part No	Description	Price (each)	Stock
	696652	End tip	$0.46	To Order

Photo	Part No	Description	Price (each)	Stock
	9389665	TENSION WIRE ASSY	$22.30	To Order

Photo	Part No	Description	Price (each)	Stock
	9389880	ASSY B/LIGHT SUPPORT BRACKET RH	$81.00	To Order
	9389838	CAP SPRING WIRE TOP	$4.02	To Order

Photo	Part No	Description	Price (each)	Stock
	9389881	ASSY BACKLIGHT SUPPT BRACKET LH	$81.00	To Order

Photo	Part No	Description	Price (each)	Stock
	699165	SCREW M6x12 CSK GED 4 8 BLACK CROSS RECS	$1.23	To Order

Photo	Part No	Description	Price (each)	Stock
	9389550	DEFLECTOR WIND REAR REWORK RH	$46.42	To Order
	700606	Screw, M6 x 12, Hex Flange Head	$0.19	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	9389551	DEFLECTOR WIND REAR REWORK LH	$46.42	To Order

Photo	Part No	Description	Price (each)	Stock
	9389548	DEFLECTOR WIND FRONT REWORK RH	$43.14	To Order
	698489	POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS	$0.13	To Order

Photo	Part No	Description	Price (each)	Stock
	9389549	DEFLECTOR WIND FRONT REWORK LH	$43.14	To Order

Photo	Part No	Description	Price (each)	Stock
	9389560	WIRE GUIDE TENSION RH	$12.91	To Order
	698490	POP RIVET -AL-DOMED 1/8x0.310 - BLACK DEFLECTORS	$0.09	To Order

Photo	Part No	Description	Price (each)	Stock
	9389561	WIRE GUIDE TENSION LH	$12.91	To Order

Photo	Part No	Description	Price (each)	Stock
	6300000102	WASHER No6 PLAIN CHROME	$0.13	To Order

Photo	Part No	Description	Price (each)	Stock
	9389669	WIRE SPRING TENSION	$3.34	To Order

Photo	Part No	Description	Price (each)	Stock
	9389558	SPACE PLATE CANTRAIL RH	$1.10	To Order
	697066	POP RIVET 3-2X11	$0.11	To Order

Photo	Part No	Description	Price (each)	Stock
	9389559	SPACE PLATE CANTRAIL LH	$1.10	To Order

Photo	Part No	Description	Price (each)	Stock
	9389580	ASY CLOSING LATCH RH	$128.19	To Order
	698489	POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS	$0.13	To Order

Photo	Part No	Description	Price (each)	Stock
	9389581	ASY CLOSING LATCH LH	$128.19	To Order

Photo	Part No	Description	Price (each)	Stock
	9389612	ASSY HANDLE CLOSING LATCH RH	$494.45	To Order
	692345	SCREW M5 x 10 CSK POZI M/C ZINC PLTD	$0.73	To Order

Photo	Part No	Description	Price (each)	Stock
	9389613	ASSY HANDLE CLOSING LATCH LH	$494.45	To Order

Photo	Part No	Description	Price (each)	Stock
	9389571	CIRCLIP (LATCH)	$19.34	To Order

Photo	Part No	Description	Price (each)	Stock
	9389543	PIN BEARING FRT SHORT	$8.51	To Order

Photo	Part No	Description	Price (each)	Stock
	9389554	HANDLE COVER REWORK RH	$35.73	To Order
	9389555	HANDLE COVER REWORK LH	$35.73	To Order

Photo	Part No	Description	Price (each)	Stock
	9386253	PIVOT PIN	$98.81	To Order

Photo	Part No	Description	Price (each)	Stock
	697080	SCREW M6x8 BTN FLG GRD 10 9 BLACK COVER TO LATCH	$0.46	To Order

Photo	Part No	Description	Price (each)	Stock
	697436	SPEED NUT	$0.22	To Order

Photo	Part No	Description	Price (each)	Stock
	695158	SCREW M6 x12 HEX FLG GRD 8.8 ZINC PLATED	$1.23	To Order

Photo	Part No	Description	Price (each)	Stock
	9389535	MOULDING ROOF FRONT	$13.56	To Order
	93124876BA	INSERT - REAR BOW RH	$43.11	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	93124877BA	INSERT - REAR BOW LH	$43.11	To Order

Photo	Part No	Description	Price (each)	Stock
	697079	SCREW NO 8x5/8 POZI BLACK PAN HEAD CLOSING LATCH COVER	$0.08	To Order

Photo	Part No	Description	Price (each)	Stock
	9389502	Backlight assembly - volante	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	696042	Foam	$6.94	To Order

Photo	Part No	Description	Price (each)	Stock
	83140153ABW	Header assy rear, trimmed, complete	Enquire	To Order
	83140158ABW	Cantrail assy, trimmed complete, RH	Enquire	To Order
	83140159ABW	Cantrail assy, trimmed complete, LH	Enquire	To Order

...and 38 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	93110874BAW	ASSEMBLY - COMPLETE CONVERTIBLE HOOD	93110874BAW ASSEMBLY - COMPLETE CONVERTIBLE HOOD State material required	$16,416.49	1
1	93100529BAW	ASSY COVER (MOHAIR) OUTER	93100529BAW ASSY COVER (MOHAIR) OUTER	$4,931.37	1
1	9389695	TENSION WIRE ASSY RR	9389695 TENSION WIRE ASSY RR	$78.92	1
2	88111770BAW	TONNEAU COVER -HAARTZ TWILLFAST II	88111770BAW TONNEAU COVER -HAARTZ TWILLFAST II	$3,252.45	1
2	88123912BAW	TONNEAU COVER - LEATHER/PIPED	88123912BAW TONNEAU COVER - LEATHER/PIPED	$7,914.75	1
2	88111772BAW	TONNEAU COVER -EVERFLEX	88111772BAW TONNEAU COVER -EVERFLEX	$3,176.27	1
2	88111771BAW	TONNEAU COVER -LEATHER	88111771BAW TONNEAU COVER -LEATHER	$3,160.43	1
3	12008	Calico	12008 Calico	$14.15	1
4	83140144ABW	Headlining assy, quilted	83140144ABW Headlining assy, quilted Zagato	-	1	Enquire
4	83140174ABW	Headlining assy, ribbed	83140174ABW Headlining assy, ribbed Zagato	-	1	Enquire
4	93100548BAW	ASSY HOOD HEADLINING (ALCANTARA)	93100548BAW ASSY HOOD HEADLINING (ALCANTARA)	$5,291.98	1
5	692205	POP-RIVET 1/8 x3/8	692205 POP-RIVET 1/8 x3/8	$0.47	8
6	9389749	WEBBING FIXING PLATE	9389749 WEBBING FIXING PLATE	$1.97	4
7	696578	SCREW No 6 X 1/2" CSK POZI GRD 4 8 ZINC BLACK PASSIVATE IN STOCK	696578 SCREW No 6 X 1/2" CSK POZI GRD 4 8 ZINC BLACK PASSIVATE IN STOCK	$0.08	8
8	696578	SCREW No 6 X 1/2" CSK POZI GRD 4 8 ZINC BLACK PASSIVATE IN STOCK	696578 SCREW No 6 X 1/2" CSK POZI GRD 4 8 ZINC BLACK PASSIVATE IN STOCK	$0.08	9
9	9389513	RAIL RETAINING H/LINING RR CENTRE	9389513 RAIL RETAINING H/LINING RR CENTRE	$35.10	1
10	9389514	RAIL RETAINING H/LINING RR OUTER	9389514 RAIL RETAINING H/LINING RR OUTER	$38.85	2
11	9389552	CAM ADJUSTER	9389552 CAM ADJUSTER	$7.01	2
12	697078	Screw, flg, M8 x 20	697078 Screw, flg, M8 x 20	-	2	Enquire
13	9389748	ROD STRAP INSERT 70mm long	9389748 ROD STRAP INSERT 70mm long	$47.78	2
14	9389670	WIRE TUBE TENSION	9389670 WIRE TUBE TENSION	$2.19	2
15	697066	POP RIVET 3-2X11	697066 POP RIVET 3-2X11	$0.11	2
16	9389671	SIDE TENSION WIRE ASSY	9389671 SIDE TENSION WIRE ASSY	$55.22	2
17	9389669	WIRE SPRING TENSION	9389669 WIRE SPRING TENSION	$3.34	2
18	696652	End tip	696652 End tip	$0.46	2
19	9389665	TENSION WIRE ASSY	9389665 TENSION WIRE ASSY	$22.30	2
20	9389880	ASSY B/LIGHT SUPPORT BRACKET RH	9389880 ASSY B/LIGHT SUPPORT BRACKET RH	$81.00	1
20	9389838	CAP SPRING WIRE TOP	9389838 CAP SPRING WIRE TOP	$4.02	1
21	9389881	ASSY BACKLIGHT SUPPT BRACKET LH	9389881 ASSY BACKLIGHT SUPPT BRACKET LH	$81.00	1
22	699165	SCREW M6x12 CSK GED 4 8 BLACK CROSS RECS	699165 SCREW M6x12 CSK GED 4 8 BLACK CROSS RECS	$1.23	4
23	9389550	DEFLECTOR WIND REAR REWORK RH	9389550 DEFLECTOR WIND REAR REWORK RH	$46.42	1
23	700606	Screw, M6 x 12, Hex Flange Head IN STOCK	700606 Screw, M6 x 12, Hex Flange Head IN STOCK	$0.19	2
24	9389551	DEFLECTOR WIND REAR REWORK LH	9389551 DEFLECTOR WIND REAR REWORK LH	$46.42	1
25	9389548	DEFLECTOR WIND FRONT REWORK RH	9389548 DEFLECTOR WIND FRONT REWORK RH	$43.14	1
25	698489	POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS	698489 POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS	$0.13	8
26	9389549	DEFLECTOR WIND FRONT REWORK LH	9389549 DEFLECTOR WIND FRONT REWORK LH	$43.14	1
27	9389560	WIRE GUIDE TENSION RH	9389560 WIRE GUIDE TENSION RH	$12.91	1
27	698490	POP RIVET -AL-DOMED 1/8x0.310 - BLACK DEFLECTORS	698490 POP RIVET -AL-DOMED 1/8x0.310 - BLACK DEFLECTORS	$0.09	4
28	9389561	WIRE GUIDE TENSION LH	9389561 WIRE GUIDE TENSION LH	$12.91	1
29	6300000102	WASHER No6 PLAIN CHROME	6300000102 WASHER No6 PLAIN CHROME	$0.13	2
30	9389669	WIRE SPRING TENSION	9389669 WIRE SPRING TENSION	$3.34	2
31	9389558	SPACE PLATE CANTRAIL RH	9389558 SPACE PLATE CANTRAIL RH	$1.10	1
31	697066	POP RIVET 3-2X11	697066 POP RIVET 3-2X11	$0.11	2
32	9389559	SPACE PLATE CANTRAIL LH	9389559 SPACE PLATE CANTRAIL LH	$1.10	1
33	9389580	ASY CLOSING LATCH RH	9389580 ASY CLOSING LATCH RH	$128.19	1
33	698489	POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS	698489 POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS	$0.13	2
34	9389581	ASY CLOSING LATCH LH	9389581 ASY CLOSING LATCH LH	$128.19	1
35	9389612	ASSY HANDLE CLOSING LATCH RH	9389612 ASSY HANDLE CLOSING LATCH RH	$494.45	1
35	692345	SCREW M5 x 10 CSK POZI M/C ZINC PLTD	692345 SCREW M5 x 10 CSK POZI M/C ZINC PLTD	$0.73	4
36	9389613	ASSY HANDLE CLOSING LATCH LH	9389613 ASSY HANDLE CLOSING LATCH LH	$494.45	1
37	9389571	CIRCLIP (LATCH)	9389571 CIRCLIP (LATCH)	$19.34	2
38	9389543	PIN BEARING FRT SHORT	9389543 PIN BEARING FRT SHORT	$8.51	2
39	9389554	HANDLE COVER REWORK RH	9389554 HANDLE COVER REWORK RH	$35.73	1
39	9389555	HANDLE COVER REWORK LH	9389555 HANDLE COVER REWORK LH	$35.73	1
40	9386253	PIVOT PIN	9386253 PIVOT PIN	$98.81	2
41	697080	SCREW M6x8 BTN FLG GRD 10 9 BLACK COVER TO LATCH	697080 SCREW M6x8 BTN FLG GRD 10 9 BLACK COVER TO LATCH	$0.46	2
42	697436	SPEED NUT	697436 SPEED NUT	$0.22	2
43	695158	SCREW M6 x12 HEX FLG GRD 8.8 ZINC PLATED	695158 SCREW M6 x12 HEX FLG GRD 8.8 ZINC PLATED	$1.23	2
44	9389535	MOULDING ROOF FRONT	9389535 MOULDING ROOF FRONT	$13.56	1
44	93124876BA	INSERT - REAR BOW RH IN STOCK	93124876BA INSERT - REAR BOW RH IN STOCK	$43.11	1
45	93124877BA	INSERT - REAR BOW LH	93124877BA INSERT - REAR BOW LH	$43.11	1
46	697079	SCREW NO 8x5/8 POZI BLACK PAN HEAD CLOSING LATCH COVER	697079 SCREW NO 8x5/8 POZI BLACK PAN HEAD CLOSING LATCH COVER	$0.08	2
47	9389502	Backlight assembly - volante	9389502 Backlight assembly - volante	-	1	Enquire
48	696042	Foam	696042 Foam	$6.94	1
49	83140153ABW	Header assy rear, trimmed, complete	83140153ABW Header assy rear, trimmed, complete Zagato	-	1	Enquire
49	83140158ABW	Cantrail assy, trimmed complete, RH	83140158ABW Cantrail assy, trimmed complete, RH Zagato	-	1	Enquire
49	83140159ABW	Cantrail assy, trimmed complete, LH	83140159ABW Cantrail assy, trimmed complete, LH Zagato	-	1	Enquire
49	83140148ABW	ASSEMBLY COMPLETE FRONT HEADER	83140148ABW ASSEMBLY COMPLETE FRONT HEADER Zagato	-	1	Enquire
49	83140151AAW	Trim panel, front header	83140151AAW Trim panel, front header Zagato	-	1	Enquire
49	83140128AAW	B post assy complete, RH	83140128AAW B post assy complete, RH Zagato	-	1	Enquire
49	83140129AAW	B post assy complete, LH	83140129AAW B post assy complete, LH Zagato	-	1	Enquire
49	83140136AAW	C post assy complete, RH	83140136AAW C post assy complete, RH Zagato	-	1	Enquire
49	83140137AAW	C post assy complete, LH	83140137AAW C post assy complete, LH Zagato	-	1	Enquire
49	83140155AAW	Trim panel, rear header	83140155AAW Trim panel, rear header Zagato	-	1	Enquire
49	83140162AAW	Trim panel cantrail, RH	83140162AAW Trim panel cantrail, RH Zagato	-	1	Enquire
49	83140163AAW	Trim panel cantrail, LH	83140163AAW Trim panel cantrail, LH Zagato	-	1	Enquire
49	83140134AAW	Trim panel, B post, RH	83140134AAW Trim panel, B post, RH Zagato	-	1	Enquire
49	83140135AAW	Trim panel, B post, LH	83140135AAW Trim panel, B post, LH Zagato	-	1	Enquire
49	83140142AAW	Trim panel, C post, RH	83140142AAW Trim panel, C post, RH Zagato	-	1	Enquire
49	83140143AAW	Trim panel, C post, LH	83140143AAW Trim panel, C post, LH Zagato	-	1	Enquire
49	83140149AB	ASSEMBLY FRONT HEADER	83140149AB ASSEMBLY FRONT HEADER Zagato	$114.47	1
49	83140154AB	Header assy, rear	83140154AB Header assy, rear Zagato	-	1	Enquire
49	83140160AB	CANTRAIL ASSEMBLY RH	83140160AB CANTRAIL ASSEMBLY RH Zagato	$115.76	1
49	83140161AB	CANTRAIL ASSEMBLY LH	83140161AB CANTRAIL ASSEMBLY LH Zagato	$115.76	1
49	83140130AA	ASSEMBLY B POST RH	83140130AA ASSEMBLY B POST RH Zagato	$52.95	1
49	83140131AA	ASSEMBLY B POST LH	83140131AA ASSEMBLY B POST LH Zagato	$52.95	1
49	83140138AA	ASSEMBLY C POST RH	83140138AA ASSEMBLY C POST RH Zagato	-	1	Enquire
49	83140139AA	ASSEMBLY C POST LH	83140139AA ASSEMBLY C POST LH Zagato	-	1	Enquire
49	697468	SCREW/WASHER No8 x19 PAN HD AB	697468 SCREW/WASHER No8 x19 PAN HD AB Zagato	$0.66	2
49	1R12834052AA	PLATE - REINFORCED COAT HOOK	1R12834052AA PLATE - REINFORCED COAT HOOK Zagato	$5.77	2
49	697571	NUT LOKUT	697571 NUT LOKUT Zagato	$0.11	2
49	8384823	SNAPSAC	8384823 SNAPSAC Zagato	$0.43	2
49	1R12834074AAW	COAT HOOK - TRIMMED	1R12834074AAW COAT HOOK - TRIMMED Zagato	$264.10	2
49	700106	SCREW No6x13 S/TAPP	700106 SCREW No6x13 S/TAPP Zagato	$3.47	2
49	83110940AA	FIRTREE BUTTON	83110940AA FIRTREE BUTTON Zagato	$2.02	2
49	697648	Fastener, Fir Tree	697648 Fastener, Fir Tree Zagato	$0.79	4
49	697645	SCREW-SELF DRILLING IN STOCK	697645 SCREW-SELF DRILLING Zagato IN STOCK	$0.27	6
49	83124911BAW	Header rail, convertible	83124911BAW Header rail, convertible USA	-	1	Enquire
49	93111432BA	STUD-TONNEAU FIXING	93111432BA STUD-TONNEAU FIXING	$10.56	-
49	698086	DURABLE DOT RIVET COMPLETE	698086 DURABLE DOT RIVET COMPLETE	$1.28	-
49	93125642BA	TORSIONAL SPRING HOOD WIRE RH	93125642BA TORSIONAL SPRING HOOD WIRE RH	$3.20	1
49	93125643BA	TORSIOANAL SPRING HOOD WIRE LH	93125643BA TORSIOANAL SPRING HOOD WIRE LH	$3.11	1
49	9389837	SPRING WIRE	9389837 SPRING WIRE	$26.17	1
49	93100592	EDGE RETAINER - SIDE SHORT RT ANGLE	93100592 EDGE RETAINER - SIDE SHORT RT ANGLE	$46.04	2
49	9389925	EDGE RETAINER REAR LONG	9389925 EDGE RETAINER REAR LONG	$50.55	2
