Lamborghini Diablo VT (1993-1998) - Rear Body Elements

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
002	8400303	WASHER IN STOCK	8400303 WASHER RONDELLA IN STOCK	$0.04	4
003	8200302	NUT IN STOCK	8200302 NUT DADO IN STOCK	$0.15	4
004	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$19.93	3
005	8400624	WASHER	8400624 WASHER RONDELLA	$4.45	3
007	9455245	INSULATOR	9455245 INSULATOR ISOLANTE	$163.62	1
008	WHT002959	CLAMPING NUT IN STOCK	WHT002959 CLAMPING NUT DADO IN STOCK	$0.77 MSRP: ~~7.26~~ (89.4% off)	4
009	8220503	CLIP	8220503 CLIP MOLLETTA	$9.76 MSRP: ~~10.90~~ (10.5% off)	4
010	9430132	SHIELD	9430132 SHIELD PROTEZIONE ANTICALORE	$227.42	1
011	WHT003066	SCREW IN STOCK	WHT003066 SCREW IN STOCK	$13.13	6
012	N90834301	CLIP NUT IN STOCK	N90834301 CLIP NUT IN STOCK	$1.19	6
013	9410210	REAR FRAME	9410210 REAR FRAME CORNICE POSTERIORE	$2,518.35	1
014	9430007	GRILLE	9430007 GRILLE GRIGLIA	-	1	Enquire
015	9430134	GRILLE	9430134 GRILLE GRIGLIA	$292.04	1
016	9410212	SUPPORT - SUPPORTO	9410212 SUPPORT - SUPPORTO O	$234.34	1
017	9455246	LINING	9455246 LINING ISOLAMENTO	$38.46	2
018	N90834301	CLIP NUT IN STOCK	N90834301 CLIP NUT IN STOCK	$1.19	2
019	8400624	WASHER	8400624 WASHER RONDELLA	$4.45	2
020	8700449	SCREW IN STOCK	8700449 SCREW VITE IN STOCK	$2.78 MSRP: ~~7.37~~ (62.3% off)	2
021	WHT003383	CLIP	WHT003383 CLIP MOLLETTA	$14.51	4
022	8700437	SCREW	8700437 SCREW VITE	-	4	Enquire
023	8100621	SCREW M6 X 20 UNI 5739/5S/Z IN STOCK	8100621 SCREW M6 X 20 UNI 5739/5S/Z VITE IN STOCK	$0.11 MSRP: ~~7.37~~ (98.5% off)	8
024	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.39	8
025	9410205	SPACER	9410205 SPACER DISTANZIALE	$11.58	2
026	N01508213	HEXAGON COLLAR NUT IN STOCK	N01508213 HEXAGON COLLAR NUT DADO IN STOCK	$0.19	4
027	9410200	REAR PANEL	9410200 REAR PANEL ELEMENTO SCOCCA POSTERIORE	$1,794.98 MSRP: ~~1,950.00~~ (7.9% off)	1
028	9430104	LEFT GRILLE	9430104 LEFT GRILLE GRIGLIA SX	$3,454.29	1
029	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$19.93	3
030	9410206	SPACER	9410206 SPACER DISTANZIALE	$46.60	2
031	8200301	NUT	8200301 NUT DADO	$0.07 MSRP: ~~7.38~~ (99.1% off)	8
032	8700328	SCREW	8700328 SCREW VITE	$0.15	8
033	9410216	PLATE	9410216 PLATE LAMIERINO	$76.07	1
034	8700449	SCREW IN STOCK	8700449 SCREW VITE IN STOCK	$2.78 MSRP: ~~7.37~~ (62.3% off)	4
035	9430146	LEFT PLATE	9430146 LEFT PLATE LAMIERINO SX	$39.55 MSRP: ~~42.80~~ (7.6% off)	1
036	N91115501	WASHER	N91115501 WASHER RONDELLA	$1.16 MSRP: ~~7.33~~ (84.2% off)	4
037	N90834301	CLIP NUT IN STOCK	N90834301 CLIP NUT IN STOCK	$1.19	2
038	9430145	GRILL	9430145 GRILL GRIGLIA	$3,386.96	1
039	N91049601	OVAL HEAD PANEL SCREW (COMBI) IN STOCK	N91049601 OVAL HEAD PANEL SCREW (COMBI) VITE IN STOCK	$0.95 MSRP: ~~7.31~~ (87% off)	4
040	9430144	RIGHT PLATE	9430144 RIGHT PLATE LAMIERINO DX	$39.55 MSRP: ~~42.80~~ (7.6% off)	1
041	8220402	CLIP	8220402 CLIP MOLLETTA	$4.11 MSRP: ~~7.12~~ (42.3% off)	4
042	9430103	RIGHT GRILLE	9430103 RIGHT GRILLE GRIGLIA DX	$3,319.63	1
043	9430136	GRILLE	9430136 GRILLE GRIGLIA	$355.54	1
044	9410215	PLATE	9410215 PLATE LAMIERINO DX	$76.07	1
045	9410211	SUPPORT - SUPPORTO	9410211 SUPPORT - SUPPORTO O	$50.22	1
046	9430135	NET	9430135 NET RETE	$241.27	1
047	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$19.93	2
048	N10718801	HEX COLLARED BOLT IN STOCK	N10718801 HEX COLLARED BOLT VITE IN STOCK	$1.69	2
