Water Pump of Lamborghini Lamborghini Diablo VT (1993-1998)

View All

Lamborghini Diablo VT (1993-1998) - Water Pump

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
000	17002472	Water pump assy (power steering version)	17002472 Water pump assy (power steering version)	$4,641.08	1
001	7L919501A	Water Temperature Sensor IN STOCK	7L919501A Water Temperature Sensor SENSORE TEMPERATURA ACQUA IN STOCK	$338.07	2
002	8832604	STRAP	8832604 STRAP FASCETTA	$3.14 MSRP: ~~3.40~~ (7.6% off)	2
003	1732811	PIPE	1732811 PIPE TUBO	$23.42 MSRP: ~~25.50~~ (8.2% off)	1
004	8700617	SCREW IN STOCK	8700617 SCREW VITE IN STOCK	$0.23 MSRP: ~~7.35~~ (96.9% off)	2
005	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$41.71	2
006	WHT003062	SEAL RING	WHT003062 SEAL RING ANELLO TENUTA	$6.19	1
007	8700650	SCREW IN STOCK	8700650 SCREW VITE IN STOCK	$2.25 MSRP: ~~2.50~~ (10% off)	1
008	8301034	STUD	8301034 STUD PRIGIONIERO	$5.41 MSRP: ~~6.00~~ (9.8% off)	1
009	WHT003028	THREADED PIN	WHT003028 THREADED PIN PRIGIONIERO	$20.73	2
010	1733982	IMPELLER	1733982 IMPELLER GIRANTE	-	1	Enquire
011	1734244	SHIM	1734244 SHIM SPESSORE Dl REGISTRO 2.0 MM	$34.10	1
011	1734242	SHIM	1734242 SHIM SPESSORE Dl REGISTRO 1.6 MM	$34.10	1
011	1734241	SHIM	1734241 SHIM SPESSORE Dl REGISTRO 1.4 MM	$50.66	1
011	1734240	SHIM	1734240 SHIM SPESSORE Dl REGISTRO 1.2 MM	$34.10	1
011	1734239	SHIM	1734239 SHIM SPESSORE Dl REGISTRO 1.0 MM	$34.10	1
011	1734243	SHIM	1734243 SHIM SPESSORE Dl REGISTRO 1.8 MM	$34.10	1
011	1734248	SHIM	1734248 SHIM SPESSORE Dl REGISTRO 2.8 MM	$34.10	1
011	1734245	SHIM	1734245 SHIM SPESSORE Dl REGISTRO 2.2 MM	$34.10	1
011	1734247	SHIM	1734247 SHIM SPESSORE Dl REGISTRO 2.6 MM	$34.10	1
011	1734246	SHIM	1734246 SHIM SPESSORE Dl REGISTRO 2.4 MM	$34.10	1
012	1726539	SEAL IN STOCK	1726539 SEAL TENUTA FRONTALE IN STOCK	$187.19	1
013	1727739	SMALL SHAFT	1727739 SMALL SHAFT ALBERINO	$437.31	1
014	WHT003018	SEAL RING IN STOCK	WHT003018 SEAL RING ANELLO TENUTA IN STOCK	$82.08	1
015	1732800	WATER PUMP CASE	1732800 WATER PUMP CASE CORPO POMPA ACQUA	-	1	Enquire
016	8300833	STUD BOLT	8300833 STUD BOLT PRIGIONIERO	$5.66 MSRP: ~~6.30~~ (10.2% off)	1
017	1736517	TRANS BELT	1736517 TRANS BELT CINGHIA POMPA ACQUA E ALTERNAT.	$302.09	1
018	N0122094	WASHER IN STOCK	N0122094 WASHER RONDELLA IN STOCK	$1.44 MSRP: ~~7.15~~ (79.9% off)	3
019	N0111849	NUT IN STOCK	N0111849 NUT DADO IN STOCK	$2.13 MSRP: ~~7.25~~ (70.6% off)	3
020	8301008	STUD	8301008 STUD PRIGIONIERO	$9.87	1
021	1232211	BUSHING	1232211 BUSHING BUSSOLA	$112.90	1
022	8575201	RETAINING RING IN STOCK	8575201 RETAINING RING ANELLO RITEGNO IN STOCK	$1.13 MSRP: ~~7.20~~ (84.3% off)	1
023	8502501	BEARING	8502501 BEARING CUSCINETTO	$50.76	1
024	1228675	BELT STRETCHER	1228675 BELT STRETCHER TENDICINGHIA	$349.45	1
025	1626949	WASHER	1626949 WASHER RONDELLA	$29.64	1
026	8201008	NUT IN STOCK	8201008 NUT DADO IN STOCK	$0.75 MSRP: ~~7.24~~ (89.6% off)	1
027	1724221	THERMOCOUPLE	1724221 THERMOCOUPLE TERMOCOPPIA	$132.01	1
028	8401408	WASHER IN STOCK	8401408 WASHER RONDELLA IN STOCK	$0.81 MSRP: ~~7.22~~ (88.8% off)	1
029	1732803	CONNECTION	1732803 CONNECTION RACCORDO	$306.80 MSRP: ~~333.00~~ (7.9% off)	1
030	8840601	HELI-COIL	8840601 HELI-COIL	$2.38 MSRP: ~~2.55~~ (6.7% off)	2
031	1733986	PULLEY	1733986 PULLEY PULEGGIA	$974.56	1
