Rear Suspension of Lamborghini Lamborghini Diablo SE30 (1993-1995)

View All

Lamborghini Diablo SE30 (1993-1995) - Rear Suspension

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 DADO IN STOCK	$20.54	8
002	410407127A	BOLT	410407127A BOLT ECCENTRICO	$2,178.02	8
003	410407295D	WASHER	410407295D WASHER RONDELLA SP = 3 MM	$27.68	1
003	5133488	SHIM	5133488 SHIM RONDELLA SP= 1,5 MM	$3.11	1
003	410407295	1.0 MM ADJUSTMENT SHIM	410407295 1.0 MM ADJUSTMENT SHIM RONDELLA SP = 1 MM	$4.26	1
003	410407295C	2.5 MM ADJUSTMENT SHIM	410407295C 2.5 MM ADJUSTMENT SHIM RONDELLA SP = 2,5 MM	$6.89	1
003	410407295B	2.0 MM ADJUSTMENT SHIM	410407295B 2.0 MM ADJUSTMENT SHIM RONDELLA SP = 2 MM	$6.26	1
004	8921206	RESILIENT BUSHING	8921206 RESILIENT BUSHING BOCCOLA ELASTICA	$46.86	8
005	410407127A	BOLT	410407127A BOLT PERNO CON ECCENTRICO	$2,178.02	8
006	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.08 MSRP: ~~7.28~~ (85.2% off)	4
007	5227297	BUSHING	5227297 BUSHING BOCCOLA X SNODO SFERICO	$30.14	8
008	5109714	BOOT	5109714 BOOT CAPPUCCIO	$24.45	1
009	5227298	BUSHING	5227298 BUSHING BOCC.RIDUZ.BARRA Dl TORSI	$16.41 MSRP: ~~17.80~~ (7.8% off)	4
010	417801931A	BALL JOINT	417801931A BALL JOINT GIUNTO SFERICO	$249.10	2
011	8201016	NUT	8201016 NUT DADO	$21.20	2
012	5209770	TIE ROD	5209770 TIE ROD TIRANTE	$106.33 MSRP: ~~115.00~~ (7.5% off)	2
013	8201014	NUT	8201014 NUT DADO	$5.73	2
014	5227295	BALL JOINT	5227295 BALL JOINT GIUNTO SFERICO	$142.26	2
015	8251702	PLUG IN STOCK	8251702 PLUG GHIERA IN STOCK	$3.58 MSRP: ~~3.95~~ (9.4% off)	4
016	8401708	WASHER	8401708 WASHER RONDELLA	$2.38 MSRP: ~~2.55~~ (6.7% off)	4
017	5233269	SHOCK ABSORBER	5233269 SHOCK ABSORBER AMMORTIZZATORE POSTERIORE	$706.14	1
018	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 DADO IN STOCK	$20.54	8
019	410512383	FLEXIBLE BUSHING	410512383 FLEXIBLE BUSHING	$552.02	8
020	8101259	SCREW	8101259 SCREW VITE	$14.46	8
021	410512385	RUBBER RING	410512385 RUBBER RING	$49.77	8
022	5235182	SPRING	5235182 SPRING MOLLA	$161.11	4
023	5135183	SPACER	5135183 SPACER DISTANZIALE	$122.95	4
024	5234841	LEFT LOWER ARM	5234841 LEFT LOWER ARM BRACCIO INFERIORE SX.	$2,568.55	1
024	5234842	RIGHT LOWER ARM	5234842 RIGHT LOWER ARM BRACCIO INFERIORE DX.	$1,867.43	1
025	5225207	RESILIENT BUSHING	5225207 RESILIENT BUSHING BOCCOLA ELASTICA	$423.37	8
026	8401710	WASHER	8401710 WASHER RONDELLA	$38.61	24
027	5225205	PIN	5225205 PIN PERNO FISS.BRACCIO SUP.	$85.53 MSRP: ~~92.50~~ (7.5% off)	2
028	5225908	RH UPPER SUSPENSION ARM	5225908 RH UPPER SUSPENSION ARM	$2,224.72	1
028	5225909	ARM	5225909 ARM BRACCIO SUPER.SINISTRO	$2,493.86	1
029	5225204	PIN	5225204 PIN PERNO	$85.53 MSRP: ~~92.50~~ (7.5% off)	2
030	8100810	SCREW	8100810 SCREW VITE	-	2	Enquire
