Lamborghini Revuelto Coupe - REAR

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
47B807307B CRASH MEMBER $1,436.61 To Order
47B807307C CRASH MEMBER $490.59 To Order
Photo Part No Description Price (each) Stock
47B813119B CARRIER $1,562.10 To Order
47B813120B CARRIER $1,474.25 To Order
Photo Part No Description Price (each) Stock
47B814101B CARRIER $2,540.19 To Order
47B814102B CARRIER $2,508.83 To Order
Photo Part No Description Price (each) Stock
47B813649B REINFORCEMENT $1,191.96 To Order
47B813650B REINFORCEMENT $1,178.13 To Order
Photo Part No Description Price (each) Stock
47B813441B REINFORCEMENT $2,765.98 To Order
Photo Part No Description Price (each) Stock
47B813981A SUPPORT $42.66 To Order
47B813982A SUPPORT $42.66 To Order
Photo Part No Description Price (each) Stock
47B814541A BRACKET $355.01 To Order
47B814542A BRACKET $355.01 To Order
Photo Part No Description Price (each) Stock
N10709401 HEXAGON HEAD BOLT (COMBI) $7.03 To Order
Photo Part No Description Price (each) Stock
N10753102 INT. SERRATION FLANGE SCREW $5.55 To Order
Photo Part No Description Price (each) Stock
N91174301 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD $3.95 To Order
Photo Part No Description Price (each) Stock
N10665002 FLAT HEAD MULTI-POINT SOCKET BOLT $5.46 To Order
Photo Part No Description Price (each) Stock
N10827302 12-POINT SOCKET HEAD BOLT (COMBI) $7.53 To Order
Photo Part No Description Price (each) Stock
N10661002 HEX SOCKET OVAL HEAD COLLARED $1.43 IN STOCK
Photo Part No Description Price (each) Stock
47B501429B MOUNTING FOR TRACK CONTROL ARM $740.11 To Order
47B501430B MOUNTING FOR TRACK CONTROL ARM $740.11 To Order
Photo Part No Description Price (each) Stock
N10701501 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD $13.94 To Order
View All
REAR of Lamborghini Lamborghini Revuelto Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 47B807307B
CRASH MEMBER 		$1,436.61 1
1 47B807307C
CRASH MEMBER 		$490.59 1
2 47B813119B
CARRIER
LEFT 		$1,562.10 1
2 47B813120B
CARRIER
RIGHT 		$1,474.25 1
3 47B814101B
CARRIER
LEFT 		$2,540.19 1
3 47B814102B
CARRIER
RIGHT 		$2,508.83 1
4 47B813649B
REINFORCEMENT
LEFT 		$1,191.96 1
4 47B813650B
REINFORCEMENT
RIGHT 		$1,178.13 1
5 47B813441B
REINFORCEMENT 		$2,765.98 1
6 47B813981A
SUPPORT
LEFT 		$42.66 1
6 47B813982A
SUPPORT
RIGHT 		$42.66 1
7 47B814541A
BRACKET
LEFT 		$355.01 1
7 47B814542A
BRACKET
RIGHT 		$355.01 1
8 N10709401
HEXAGON HEAD BOLT (COMBI)
M8X120X80 		$7.03 1
9 N10753102
INT. SERRATION FLANGE SCREW
M8X22 		$5.55 1
10 N91174301
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
M8X50 		$3.95 1
11 N10665002
FLAT HEAD MULTI-POINT SOCKET BOLT
M8X30 		$5.46 1
12 N10827302
12-POINT SOCKET HEAD BOLT (COMBI) 		$7.53 1
13 N10661002
HEX SOCKET OVAL HEAD COLLARED
M6X20
IN STOCK 		$1.43 (80.3% off) 1
14 47B501429B
MOUNTING FOR TRACK CONTROL ARM
LEFT 		$740.11 1
14 47B501430B
MOUNTING FOR TRACK CONTROL ARM
RIGHT 		$740.11 1
15 N10701501
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD 		$13.94 1
