Water Pump of Lamborghini Lamborghini Diablo SV (1995-1997)

View All

Lamborghini Diablo SV (1995-1997) - Water Pump

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	7L919501A	Water Temperature Sensor IN STOCK	7L919501A Water Temperature Sensor SENSORE TEMP. ACQUA IN STOCK	$339.55	2
002	8832604	STRAP	8832604 STRAP FASCETTA	$3.15 MSRP: ~~3.40~~ (7.4% off)	2
003	1732811	PIPE	1732811 PIPE TUBO	$23.53 MSRP: ~~25.50~~ (7.7% off)	1
004	8700617	SCREW IN STOCK	8700617 SCREW VITE IN STOCK	$0.24 MSRP: ~~7.35~~ (96.7% off)	2
005	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$41.89	2
006	WHT003062	SEAL RING	WHT003062 SEAL RING ANELLO TENUTA	$6.21	1
007	8700650	SCREW IN STOCK	8700650 SCREW VITE IN STOCK	$2.26 MSRP: ~~2.50~~ (9.6% off)	1
008	8301034	STUD	8301034 STUD PRIGIONIERO	$5.44 MSRP: ~~6.00~~ (9.3% off)	1
009	WHT003028	THREADED PIN	WHT003028 THREADED PIN PRIGIONIERO	$20.82	2
010	1734252	IMPELLER	1734252 IMPELLER GIRANTE	$553.43	1
011	1734243	SHIM	1734243 SHIM SPESSORE Dl REGISTRO 1.8 MM	$34.25	1
011	1734242	SHIM	1734242 SHIM SPESSORE Dl REGISTRO 1.6 MM	$34.25	1
011	1734241	SHIM	1734241 SHIM SPESSORE Dl REGISTRO 1.4 MM	$50.88	1
011	1734240	SHIM	1734240 SHIM SPESSORE Dl REGISTRO 1.2 MM	$34.25	1
011	1734239	SHIM	1734239 SHIM SPESSORE Dl REGISTRO 1 .0 MM	$34.25	1
011	1734247	SHIM	1734247 SHIM SPESSORE Dl REGISTRO 2.6 MM	$34.25	1
011	1734244	SHIM	1734244 SHIM SPESSORE Dl REGISTRO 2.0 MM	$34.25	1
011	1734248	SHIM	1734248 SHIM SPESSORE Dl REGISTRO 2.8 MM	$34.25	1
011	1734246	SHIM	1734246 SHIM SPESSORE Dl REGISTRO 2.4 MM	$34.25	1
011	1734245	SHIM	1734245 SHIM SPESSORE Dl REGISTRO 2.2 MM	$34.25	1
012	1734675	SEAL	1734675 SEAL TENUTA FRONTALE	$43.50	1
013	1727739	SMALL SHAFT	1727739 SMALL SHAFT CUSCINETTO	$439.23	1
014	WHT003018	SEAL RING IN STOCK	WHT003018 SEAL RING ANELLO TENUTA IN STOCK	$82.44	1
015	1734676	WATER PUMP CASE	1734676 WATER PUMP CASE CORPO POMPA ACQUA	-	1	Enquire
016	8300833	STUD BOLT	8300833 STUD BOLT PRIGIONIERO	$5.69 MSRP: ~~6.30~~ (9.7% off)	1
017	1736516	TRANS BELT	1736516 TRANS BELT WATER PUMP, ALTERNATOR & POWER STEERING	$400.03	1
018	N0122094	WASHER IN STOCK	N0122094 WASHER RONDELLA IN STOCK	$1.44 MSRP: ~~7.15~~ (79.9% off)	3
019	N0111849	NUT IN STOCK	N0111849 NUT DADO IN STOCK	$2.14 MSRP: ~~7.25~~ (70.5% off)	3
020	8301034	STUD	8301034 STUD PRIGIONIERO	$5.44 MSRP: ~~6.00~~ (9.3% off)	1
021	1237082	BUSHING	1237082 BUSHING BUSSOLA	$244.61	1
022	7M109565	PULLEY	7M109565 PULLEY PULEGGIA	$3,713.69	1
023	8401006	WASHER	8401006 WASHER RONDELLA	$0.57 MSRP: ~~7.29~~ (92.2% off)	1
024	8201008	NUT IN STOCK	8201008 NUT DADO IN STOCK	$0.75 MSRP: ~~7.24~~ (89.6% off)	1
025	1736801	PULLEY	1736801 PULLEY PULEGGIA	$1,110.88	1
026	1724221	THERMOCOUPLE	1724221 THERMOCOUPLE TERMOCOPPIA	$132.58	1
027	8401408	WASHER IN STOCK	8401408 WASHER RONDELLA IN STOCK	$0.82 MSRP: ~~7.22~~ (88.6% off)	1
028	1732803	CONNECTION	1732803 CONNECTION RACCORDO	$308.14 MSRP: ~~333.00~~ (7.5% off)	1
029	8840601	HELI-COIL	8840601 HELI-COIL	$2.39 MSRP: ~~2.55~~ (6.3% off)	2
