Lamborghini Diablo (1990-1998) - Fuel System 2

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	6230214	STRAP	6230214 STRAP O FILTRI	-	1	Enquire
002	410201349	GASKET	410201349 GASKET GUARNIZIONE	$30.79	1
003	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.08	2
004	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.39	2
005	6230564	CONNECTION	6230564 CONNECTION RACCORDO	-	2	Enquire
006	8603703	SEAL	8603703 SEAL ANELLO TENUTA	$19.43 MSRP: ~~21.75~~ (10.7% off)	2
007	5122740	CONNECTION	5122740 CONNECTION RACCORDO	$81.58	2
008	6227630	CONNECTION	6227630 CONNECTION RACCORDO	$13.96	2
009	8830902	STRAP	8830902 STRAP FASCETTA	$5.34	2
010	6231552	PIPE	6231552 PIPE TUBO PER BANCATA 1 - 6	$241.31	1
010	6231554	PIPE	6231554 PIPE TUBO PER BANCATA 7-12	$141.53	1
011	400201511A	Fuel Filter IN STOCK	400201511A Fuel Filter IN STOCK	$242.28	2
012	410201196	GASKET	410201196 GASKET GUARNIZIONE	$4.69	1
013	6230218	PIPE	6230218 PIPE TUBO	$46.57 MSRP: ~~50.40~~ (7.6% off)	2
014	N0245097	CLAMP	N0245097 CLAMP FASCETTA	$17.03	2
015	6130194	ELECT CABLE	6130194 ELECT CABLE CABLAGGIO POMPE BENZINA	$38.88 MSRP: ~~43.65~~ (10.9% off)	1
016	8300803	STUD BOLT	8300803 STUD BOLT PRIGIONIERO	$12.62	2
017	1701495	RUBBER RING	1701495 RUBBER RING ANELLO COMMA	$54.60	2
018	1701592	DOWEL	1701592 DOWEL GRANO	$26.91	2
019	WHT001189	PLASTIC WASHER IN STOCK	WHT001189 PLASTIC WASHER IN STOCK	$5.88	2
020	WHT001942	WASHER IN STOCK	WHT001942 WASHER RONDELLA IN STOCK	$3.07	2
021	N0111849	NUT IN STOCK	N0111849 NUT DADO IN STOCK	$2.13 MSRP: ~~7.25~~ (70.6% off)	2
022	6229532	STRAP	6229532 STRAP FASCETTA	$101.81	1
023	6226900	GASKET	6226900 GASKET GUARNIZIONE	$24.95	2
024	6229533	PLATE	6229533 PLATE PIASTRA	$56.74 MSRP: ~~63.80~~ (11.1% off)	1
025	2024398	FUEL PUMP	2024398 FUEL PUMP POMPA ALIMENTAZIONE	$711.74	2
026	8831320	STRAP	8831320 STRAP FASCETTA	$3.02 MSRP: ~~3.25~~ (7.1% off)	8
027	6230225	PIPE	6230225 PIPE TUBO	$20.91	2
028	6229221	OIL FILTER IN STOCK	6229221 OIL FILTER FILTRO COMBUSTIBILE IN STOCK	$107.52	2
029	6230226	PIPE	6230226 PIPE TUBO	$43.20 MSRP: ~~46.80~~ (7.7% off)	2
030	6230175	PIPE	6230175 PIPE TUBOPESCANTE	$344.31	2
031	8402007	WASHER IN STOCK	8402007 WASHER RONDELLA IN STOCK	$0.59 MSRP: ~~7.29~~ (91.9% off)	2
032	6229580	NET	6229580 NET PREFILTRO A RETE METALLIGA	$1,002.88	2
