DOORS 1 of Lamborghini Lamborghini Aventador LP750 SV Roadster

View All

Lamborghini Aventador LP750 SV Roadster - DOORS 1

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	470831052F	Door (contact Your Area Manager-right)	470831052F Door (contact Your Area Manager-right)	$13,562.75	1
001	470831051F	DOOR, LH (CONTACT YOUR AREA MANAGER)	470831051F DOOR, LH (CONTACT YOUR AREA MANAGER)	$13,562.75	1
002	470837350C	Door Seal (right)	470837350C Door Seal (right)	$148.05	1
002	470837349D	DOOR SEAL	470837349D DOOR SEAL	$580.82	1
003	470831411E	LH HINGE	470831411E LH HINGE	$1,795.73	1
003	470831412E	RH HINGE	470831412E RH HINGE	$1,839.85	1
004	470837704C	Window Aperture Seal (right)	470837704C Window Aperture Seal (right)	$185.25	1
004	470837703C	GLASS WEATHERSTRIP, LH	470837703C GLASS WEATHERSTRIP, LH	$185.25	1
005	470837403G	WINDOW GUIDE	470837403G WINDOW GUIDE	$1,663.06	1
005	470837404F	Window Guide (from Vin Ela02674-right)	470837404F Window Guide (from Vin Ela02674-right)	$602.23	1
006	8L3837199B	CLIP IN STOCK	8L3837199B CLIP IN STOCK	$0.98 MSRP: ~~7.25~~ (86.5% off)	14
007	470837918A	DOOR SEAL	470837918A DOOR SEAL	$44.42	1
007	470837917A	DOOR SEAL	470837917A DOOR SEAL	$75.35	1
008	8J0837805A	SOUND ABSORBER (SELF-ADHESIVE) IN STOCK	8J0837805A SOUND ABSORBER (SELF-ADHESIVE) IN STOCK	$14.95	2
009	470831438B	COVER IN STOCK	470831438B COVER IN STOCK	$113.56	1
009	470831437B	COVER	470831437B COVER	$113.56	1
010	8E0837033	LOCK STRIKER	8E0837033 LOCK STRIKER	$27.66	2
011	470837723B	GAS STRUT DOOR IN STOCK	470837723B GAS STRUT DOOR IN STOCK	$223.18	2
012	470837646A	BALL STUD	470837646A BALL STUD	$9.89	4
013	470831547C	Cover (left)	470831547C Cover (left)	$12.98	1
013	470831548C	Cover (right)	470831548C Cover (right)	$12.98	1
014	N10049308	HEXAGON HEAD BOLT (COMBI) IN STOCK	N10049308 HEXAGON HEAD BOLT (COMBI) IN STOCK	$2.72	10
015	N90780903	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N90780903 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$0.92	10
016	N10586401	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10586401 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$0.89	8
017	N91174401	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N91174401 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	$3.54	8
018	N10554005	ROUND HD. SCREW IN STOCK	N10554005 ROUND HD. SCREW IN STOCK	$2.52	4
019	N01152527	WASHER IN STOCK	N01152527 WASHER IN STOCK	$0.45 MSRP: ~~7.33~~ (93.9% off)	4
020	WHT005435	COUNTERSUNK BOLT	WHT005435 COUNTERSUNK BOLT	$5.92	4
021	N91096601	HEXAGON SOCKET FLAT HEAD BOLT IN STOCK	N91096601 HEXAGON SOCKET FLAT HEAD BOLT IN STOCK	$0.98 MSRP: ~~7.33~~ (86.6% off)	4
022	N90745001	HEXAGON COLLAR NUT IN STOCK	N90745001 HEXAGON COLLAR NUT IN STOCK	$0.92 MSRP: ~~7.24~~ (87.3% off)	4
023	N10017307	HEXAGON COLLAR NUT IN STOCK	N10017307 HEXAGON COLLAR NUT IN STOCK	$1.89 MSRP: ~~7.33~~ (74.2% off)	4
024	N91109201	WASHER IN STOCK	N91109201 WASHER IN STOCK	$1.63 MSRP: ~~5.85~~ (72.1% off)	4
025	470831121C	LH BRACKET	470831121C LH BRACKET	$84.05	1
025	470831122C	RH BRACKET	470831122C RH BRACKET	$84.05	1
026	470831400A	GROMMET	470831400A GROMMET	$16.63	4
028	470837779	Intermediate Layer	470837779 Intermediate Layer	$117.79	2
