External Side Member

Lamborghini Aventador LP720 Roadster

Find Your Part

Lamborghini Aventador LP720 Roadster - EXTERNAL SIDE MEMBER

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
EXTERNAL SIDE MEMBER of Lamborghini Lamborghini Aventador LP720 Roadster Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 470853564C
FRONT RIGHT SIDE MEMBER ASSEMBLY (FROM VIN DLA01710 - 		$4,038.68 1
001 470853563A
FRONT LEFT SIDE MEMBER ASSEMBLY(from Vin Dla01710 - 		- 1 Enquire
001 470853564B
FRONT RIGHT SIDE MEMBER ASSEMBLY (UNTIL THE VIN DLA01709 - 		$2,280.83 1
001 470853563C
FRONT LEFT SIDE MEMBER ASSEMBLY (FROM VIN DLA01710 - 		$4,038.68 1
001 470853563B
FRONT LEFT SIDE MEMBER ASSEMBLY(from Vin Dla01710 - 		$2,280.83 1
002 470853989
LEFT COVER (UNTIL THE VIN DLA01709 - CONTACT YOUR AREA 		$565.81 1
002 470853990
RIGHT COVER (UNTIL THE VIN DLA01709 - CONTACT YOUR AREA 		$565.81 1
002 470853990B
RIGHT COVER (FROM VIN DLA01710 - CONTACT YOUR AREA 		$565.81 1
002 470853989B
LEFT COVER (FROM VIN DLA01710 - CONTACT YOUR AREA MANAGER) 		$565.81 1
003 470854775B
LH ORNAMENT (EXTERNAL CARBON) 		$6,475.65 1
003 470854776A
RH ORNAMENT 		$1,272.44 1
003 470854775A
LH ORNAMENT 		$1,272.44 1
003 470854776B
RH ORNAMENT (EXTERNAL CARBON) 		$6,475.65 1
004 470853293A
LEFT COVER 		$248.81 1
004 470853294A
RIGHT COVER
IN STOCK 		$248.81 1
005 470814708
ARM
IN STOCK 		$22.75 1
005 470814707
ARM 		$22.75 1
006 470809922A
RIGHT COVER 		$82.66 1
006 470809921A
LEFT COVER 		$82.66 1
007 N0154487
SPEED NUT
IN STOCK 		$1.00 20
008 N90688703
SPEED NUT CLAMP M6 X 23 8 X 16
IN STOCK 		$1.24 4
009 6N0867190A
CLIP 		$4.54 (37.6% off) 6
010 N90986803
HEXAGON SOCKET HEAD PANEL BOLT 2 X 13
IN STOCK 		$1.38 18
011 N91188301
HEXAGON SOCKET HEAD BOLT
IN STOCK 		$1.84 (74.6% off) 16
012 N10558102
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
IN STOCK 		$4.11 26
013 N01166623
WASHER
IN STOCK 		$1.43 20
014 N10405702
HEXAGON SOCKET HEAD BOLT
IN STOCK 		$3.06 2
015 N10661002
HEX SOCKET OVAL HEAD COLLARED
IN STOCK 		$1.43 (80.3% off) 10
016 470853883A
SECURING BRACKET 		$59.05 1
016 470853884A
SECURING BRACKET 		$165.09 1
017 470853654C
RADIATOR GRILLE 		$955.20 1
017 470853653A
LEFT GRID 		$141.77 1
018 470853492B
SILL TRIM STRIP 		$436.03 1
018 470853492
RIGHT SCUFF PLATE (UNTIL THE VIN DLA01709) 		$436.03 1
018 470853491
LEFT SCUFF PLATE (UNTIL THE VIN DLA01709) 		$436.03 1
018 470853491B
SILL TRIM STRIP 		$436.03 1
019 470853655B
MOLDING FOR SIDE MEMBER 		$2,054.02 2
019 470853655A
MOLDING FOR SIDE MEMBER
IN STOCK 		$342.94 2
020 470814590
BRACKET 		$32.64 1
020 470814589
BRACKET 		$19.35 1
021 7L6868243
CLIP
IN STOCK 		$1.17 (83.8% off) 2
022 470853383A
GASKET (LH) 		$697.96 1
022 470853384A
GASKET (RH) 		$147.40 1
