Ferrari 488 Pista USA - BATTERY INSTALLATION

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
828637 BATTERY RETAINER BRACKET $94.77 To Order
85280000 BATTERY RETAINER BRACKET $82.97 To Order
Photo Part No Description Price (each) Stock
85235500 BATTERY FASTENER TIE-ROD $18.95 To Order
Photo Part No Description Price (each) Stock
14059211 NUT $0.06 IN STOCK
Photo Part No Description Price (each) Stock
880041 Allen Head Bolt M6 X 26 $5.30 ARRIVING SOON
Photo Part No Description Price (each) Stock
770922 COMPL. BATTERY BRACKET $123.84 To Order
803850 COMPL. BATTERY BRACKET $123.84 To Order
Photo Part No Description Price (each) Stock
770786 BATTERY BREATHER PIPE FITTING $65.71 To Order
199631 CONNECTOR $0.35 IN STOCK
Photo Part No Description Price (each) Stock
14084117 NUT $0.81 To Order
Photo Part No Description Price (each) Stock
770933 COMPL. BATTERY RETAINER FRAME $64.44 To Order
803866 BATTERY RETAINER FRAME $50.54 To Order
82514100 RETAINER BRACKET $34.11 To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
817742 VENTING PIPE FLANGE GASKET $39.52 To Order
Photo Part No Description Price (each) Stock
10396280 CABLE GROMMET $2.87 IN STOCK
Photo Part No Description Price (each) Stock
952336 BLANKING PLUG $4.97 IN STOCK
Photo Part No Description Price (each) Stock
777613 LEAD ACID BATTERY INSTALLATION KIT $2,013.29 To Order
Photo Part No Description Price (each) Stock
777614 LEAD ACID BATTERY INSTALLATION KIT $2,592.13 To Order
View All
BATTERY INSTALLATION of Ferrari Ferrari 488 Pista USA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 828637
BATTERY RETAINER BRACKET
Version for lithium battery 		$94.77 1
0001 85280000
BATTERY RETAINER BRACKET
Version for lead battery - Also included with lead acid battery installation kit 		$82.97 1
0002 85235500
BATTERY FASTENER TIE-ROD 		$18.95 2
0003 14059211
NUT
IN STOCK 		$0.06 2
0004 880041
Allen Head Bolt M6 X 26
M6 X 14
ARRIVING SOON 		$5.30 6
0005 770922
COMPL. BATTERY BRACKET 		$123.84 1
0005 803850
COMPL. BATTERY BRACKET 		$123.84 1
0006 770786
BATTERY BREATHER PIPE FITTING
Version for lithium battery 		$65.71 1
0006 199631
CONNECTOR
Version for lead battery - Also included with lead acid battery installation kit
IN STOCK 		$0.35 1
0007 14084117
NUT
Version for lithium battery 		$0.81 2
0008 770933
COMPL. BATTERY RETAINER FRAME 		$64.44 1
0008 803866
BATTERY RETAINER FRAME
Version for lithium battery 		$50.54 1
0008 82514100
RETAINER BRACKET
Version for lead battery - Also included with lead acid battery installation kit 		$34.11 1
0008 793036
COMPL. BATTERY FRAME
Applies until depletion 		$202.19 1
0008 906365
COMPL. BATTERY FRAME
Applicable after depletion of 793036 		$227.48 1
0009 817742
VENTING PIPE FLANGE GASKET
Version for lithium battery 		$39.52 1
0010 10396280
CABLE GROMMET
Version for lead battery - Also included with lead acid battery installation kit
IN STOCK 		$2.87 1
0011 952336
BLANKING PLUG
IN STOCK 		$4.97 1
0012 777613
LEAD ACID BATTERY INSTALLATION KIT 		$2,013.29 1
0013 777614
LEAD ACID BATTERY INSTALLATION KIT 		$2,592.13 1
