View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	52107329941	Seat frame, comfort seat, left	$1,823.67	To Order
	52107329942	Seat frame, comfort seat, right	$1,823.67	To Order

Photo	Part No	Description	Price (each)	Stock
	52107299674	Spring pad, basic	$148.80	To Order

Photo	Part No	Description	Price (each)	Stock
	52107299673	Carrier thigh support	$44.87	To Order

Photo	Part No	Description	Price (each)	Stock
	7149156953	Fillister head screw	$4.22	To Order

Photo	Part No	Description	Price (each)	Stock
	7119908419	Countersunk screw	$1.22	To Order

Photo	Part No	Description	Price (each)	Stock
	52107372454	stop, fore-and-aft adjustment	$11.72	To Order

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	52107329941	Seat frame, comfort seat, left	52107329941 Seat frame, comfort seat, left to 08.2014	$1,823.67	1
1	52107329942	Seat frame, comfort seat, right	52107329942 Seat frame, comfort seat, right to 08.2014	$1,823.67	1
2	52107299674	Spring pad, basic	52107299674 Spring pad, basic to 08.2014	$148.80	2
3	52107299673	Carrier thigh support	52107299673 Carrier thigh support to 08.2014	$44.87	2
4	7149156953	Fillister head screw	7149156953 Fillister head screw M10X37; to 08.2014	$4.22	8
5	7119908419	Countersunk screw	7119908419 Countersunk screw M10X16-8.8 SW; to 08.2014	$1.22	8
6	52107372454	stop, fore-and-aft adjustment	52107372454 stop, fore-and-aft adjustment to 08.2014	$11.72	4
