Name: Fuel Pipe and Mounting Parts
Rating: 5.0 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	16127446741	Fuel feed line front	$117.58	To Order

Photo	Part No	Description	Price (each)	Stock
	16127454999	Fuel feed line	$117.58	To Order

Photo	Part No	Description	Price (each)	Stock
	16127415286	Fuel feed line rear	$117.58	To Order

Photo	Part No	Description	Price (each)	Stock
	16127455000	Scavenge air line	$121.52	To Order

Photo	Part No	Description	Price (each)	Stock
	16137446743	Scavenging line rear	$109.26	To Order

Photo	Part No	Description	Price (each)	Stock
	7147441119	Clip	$4.51	To Order

Photo	Part No	Description	Price (each)	Stock
	7147441123	Clip	$6.02	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
01	16127446741	Fuel feed line front	16127446741 Fuel feed line front	$117.58	1
02	16127454999	Fuel feed line	16127454999 Fuel feed line	$117.58	1
03	16127415286	Fuel feed line rear	16127415286 Fuel feed line rear	$117.58	1
04	16137446742	Scavenging line front	16137446742 Scavenging line front from 08.2020	$167.61	1
04	16125A20A13	Scavenging line front	16125A20A13 Scavenging line front to 08.2020	$293.72	1
05	16127455000	Scavenge air line	16127455000 Scavenge air line	$121.52	1
06	16137446743	Scavenging line rear	16137446743 Scavenging line rear	$109.26	1
07	7147441116	Clip	7147441116 Clip D8/10 D10/12; from 02.2021	$6.02	1
07	7145A154B0	Clip	7145A154B0 Clip D10 D12	$1.33	1
11	7147441119	Clip	7147441119 Clip 2XD5 D4 D10/12	$4.51	11
12	7147441123	Clip	7147441123 Clip D10/12	$6.02	8

Fuel Pipe And Mounting Parts

Rolls Royce Cullinan RR31(2017-2023)
