Sunroof

Maserati Grecale Modena Automatic 2.0 T4 4WD 250HP MHEV

Illustration Number: 09711

Find Your Part

Maserati Grecale Modena Automatic 2.0 T4 4WD 250HP MHEV - SUNROOF (09711)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670286741 SUNROOF ASSEMBLY Enquire To Order
Photo Part No Description Price (each) Stock
673012080 RH MECHANISM $740.25 To Order
Photo Part No Description Price (each) Stock
673012081 LH MECHANISM $835.63 To Order
Photo Part No Description Price (each) Stock
673012082 GEAR MOTOR $394.89 To Order
Photo Part No Description Price (each) Stock
673012083 WIRING HARNESS $98.41 To Order
Photo Part No Description Price (each) Stock
673012085 PIPES MECHANISMS $210.58 To Order
Photo Part No Description Price (each) Stock
673012086 ROLLER PIPES $210.58 To Order
Photo Part No Description Price (each) Stock
673012087 DEFLECTOR $223.37 To Order
Photo Part No Description Price (each) Stock
673012088 FRONT GLASS $496.02 To Order
Photo Part No Description Price (each) Stock
673012089 KIT REAR GLASS $331.57 To Order
Photo Part No Description Price (each) Stock
673012093 KIT FRONT PAVILION $667.42 To Order
Photo Part No Description Price (each) Stock
673012091 SUNROOF SUNSHADE $1,093.10 To Order
673012090 SUNROOF SUNSHADE $1,312.37 To Order
Photo Part No Description Price (each) Stock
673012084 COVERING CENTRAL CROSS $97.37 To Order
Photo Part No Description Price (each) Stock
673012094 GASKET $166.91 To Order
Photo Part No Description Price (each) Stock
673012095 GASKETS KIT $251.45 To Order
Photo Part No Description Price (each) Stock
673012096 MECHANISMS COVER GASKET $130.05 To Order
Photo Part No Description Price (each) Stock
673012100 CLIPS KIT $41.40 To Order
Photo Part No Description Price (each) Stock
673015805 RH KIT MOLDING GASKET $220.02 To Order
Photo Part No Description Price (each) Stock
673015806 LH KIT MOLDING GASKET $220.02 To Order
Photo Part No Description Price (each) Stock
673012097 KIT GLASS FIXING SCREWS $40.30 To Order
Photo Part No Description Price (each) Stock
673012098 KIT ENGINE FIXING SCREW $35.21 To Order
Photo Part No Description Price (each) Stock
673012099 KIT MECHANISM FIXING SCREWS $36.28 To Order
Photo Part No Description Price (each) Stock
670286743 RH MOULDING DOME Enquire To Order
670286744 RH MOULDING DOME Enquire To Order
Photo Part No Description Price (each) Stock
670286745 LH MOULDING DOME Enquire To Order
670286746 LH MOULDING DOME Enquire To Order
Photo Part No Description Price (each) Stock
670174010 PLUG $2.04 To Order
View All
SUNROOF of Maserati Maserati Grecale Modena Automatic 2.0 T4 4WD 250HP MHEV Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670286741
SUNROOF ASSEMBLY
Bespoke Assembly Number 2033022 - 99999999; EU AU CN UK JP ME JRH IN KO N0 N8; 		- 1 Enquire
4 673012080
RH MECHANISM 		$740.25 1
5 673012081
LH MECHANISM 		$835.63 1
6 673012082
GEAR MOTOR 		$394.89 2
7 673012083
WIRING HARNESS 		$98.41 1
8 673012085
PIPES MECHANISMS 		$210.58 1
9 673012086
ROLLER PIPES 		$210.58 1
10 673012087
DEFLECTOR 		$223.37 1
11 673012088
FRONT GLASS 		$496.02 1
12 673012089
KIT REAR GLASS 		$331.57 1
13 673012093
KIT FRONT PAVILION 		$667.42 1
14 673012091
SUNROOF SUNSHADE
GREIGE; 		$1,093.10 1
14 673012090
SUNROOF SUNSHADE
BLACK; 		$1,312.37 1
15 673012084
COVERING CENTRAL CROSS 		$97.37 1
16 673012094
GASKET 		$166.91 1
17 673012095
GASKETS KIT 		$251.45 1
18 673012096
MECHANISMS COVER GASKET 		$130.05 1
19 673012100
CLIPS KIT
CONTAINS 7 CLIPS; 		$41.40 2
20 673015805
RH KIT MOLDING GASKET
Bespoke Assembly Number 2033022 - 99999999; 		$220.02 1
21 673015806
LH KIT MOLDING GASKET
Bespoke Assembly Number 2033022 - 99999999; 		$220.02 1
22 673012097
KIT GLASS FIXING SCREWS
CONTAINS 6 SCREWS; 		$40.30 1
23 673012098
KIT ENGINE FIXING SCREW
CONTAINS 4 SCREWS; 		$35.21 1
24 673012099
KIT MECHANISM FIXING SCREWS
CONTAINS 12 SCREWS; 		$36.28 1
25 670286743
RH MOULDING DOME
Available with: ROOF RAILS ; 		- 1 Enquire
25 670286744
RH MOULDING DOME
WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 2033022 - 99999999; Not available with: ROOF RAILS; 		- 1 Enquire
26 670286745
LH MOULDING DOME
WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 2033022 - 99999999; Available with: ROOF RAILS ; 		- 1 Enquire
26 670286746
LH MOULDING DOME
WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 2033022 - 99999999; Not available with: ROOF RAILS; 		- 1 Enquire
27 670174010
PLUG
Not available with: ROOF RAILS; 		$2.04 8
