Central Structural Frames And Sheet Panels

Maserati GranCabrio M189 AUTOMATIC 4WD 3.0 BT V6 490 HP

Find Your Part

Maserati GranCabrio M189 AUTOMATIC 4WD 3.0 BT V6 490 HP - CENTRAL STRUCTURAL FRAMES AND SHEET PANELS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
673015414 FRONT CPL FRAME $2,197.31 To Order
Photo Part No Description Price (each) Stock
673015417 LH FRONT UNDERFLOOR LONGITUD $76.35 To Order
Photo Part No Description Price (each) Stock
673015418 RH FRONT UNDERFLOOR LONGITUD $76.35 To Order
Photo Part No Description Price (each) Stock
670299263 BRACKET $200.93 To Order
Photo Part No Description Price (each) Stock
675002300 SCREW $3.47 To Order
Photo Part No Description Price (each) Stock
673015416 LH UNDERFLOOR MEMBER $61.02 To Order
Photo Part No Description Price (each) Stock
673015415 RH UNDERFLOOR MEMBER $61.02 To Order
Photo Part No Description Price (each) Stock
675001899 PLUG $1.52 To Order
Photo Part No Description Price (each) Stock
675000743 TESA FASTENER $3.10 To Order
Photo Part No Description Price (each) Stock
675000546 ADHESIVE GASKET $53.81 To Order
View All
CENTRAL STRUCTURAL FRAMES AND SHEET PANELS of Maserati Maserati GranCabrio M189 AUTOMATIC 4WD 3.0 BT V6 490 HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 673015414
FRONT CPL FRAME 		$2,197.31 1
2 673015417
LH FRONT UNDERFLOOR LONGITUD 		$76.35 1
3 673015418
RH FRONT UNDERFLOOR LONGITUD 		$76.35 1
4 670299263
BRACKET 		$200.93 1
5 675002300
SCREW 		$3.47 4
6 673015416
LH UNDERFLOOR MEMBER 		$61.02 1
7 673015415
RH UNDERFLOOR MEMBER 		$61.02 1
8 675001899
PLUG 		$1.52 21
9 675000743
TESA FASTENER 		$3.10 38
10 675000546
ADHESIVE GASKET 		$53.81 4
