Electrical Capote: Hydraulic System

Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP

Find Your Part

Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP - ELECTRICAL CAPOTE: HYDRAULIC SYSTEM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
673012881 HYDRAULIC PUMP $6,323.07 To Order
Photo Part No Description Price (each) Stock
673012882 TC CYLINDER RH $1,365.67 To Order
Photo Part No Description Price (each) Stock
673012883 LH TONNEAU COVER HYDRAULIC CYLINDER WITH PIPES $1,073.32 To Order
Photo Part No Description Price (each) Stock
673012884 RH HYDRAULIC CYLINDER WITH PIPES $1,205.80 To Order
Photo Part No Description Price (each) Stock
673012885 LH HYDRAULIC CYLINDER WITH PIPES $1,205.80 To Order
Photo Part No Description Price (each) Stock
673012886 TB CYLINDER RH $1,505.71 To Order
Photo Part No Description Price (each) Stock
673012887 LH MAIN HYDRAULIC CYLINDER WITH PIPES $1,280.20 To Order
Photo Part No Description Price (each) Stock
673012890 PUMP WIRING Enquire To Order
Photo Part No Description Price (each) Stock
673014073 PUMP INSULATION $123.09 To Order
Photo Part No Description Price (each) Stock
670219162 BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
670218311 SPACER Enquire To Order
Photo Part No Description Price (each) Stock
673014072 PUMP BRACKET ASSEMBLY GROUP $354.52 To Order
Photo Part No Description Price (each) Stock
675001317 SCREW $1.92 To Order
View All
ELECTRICAL CAPOTE: HYDRAULIC SYSTEM of Maserati Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 673012881
HYDRAULIC PUMP 		$6,323.07 1
2 673012882
TC CYLINDER RH 		$1,365.67 1
3 673012883
LH TONNEAU COVER HYDRAULIC CYLINDER WITH PIPES 		$1,073.32 1
4 673012884
RH HYDRAULIC CYLINDER WITH PIPES 		$1,205.80 1
5 673012885
LH HYDRAULIC CYLINDER WITH PIPES 		$1,205.80 1
6 673012886
TB CYLINDER RH 		$1,505.71 1
7 673012887
LH MAIN HYDRAULIC CYLINDER WITH PIPES 		$1,280.20 1
8 673012890
PUMP WIRING 		- 1 Enquire
9 673014073
PUMP INSULATION 		$123.09 1
10 670219162
BRACKET 		- 1 Enquire
11 670218311
SPACER 		- 1 Enquire
12 673014072
PUMP BRACKET ASSEMBLY GROUP 		$354.52 1
13 675001317
SCREW 		$1.92 4
