Passenger Compartment B Pillar Trim Panels And Side Panels

Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP

Find Your Part

Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP - PASSENGER COMPARTMENT B PILLAR TRIM PANELS AND SIDE PANELS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670184413 REAR LH DOOR PANEL ASSEMBLY Enquire To Order
670184414 REAR LH DOOR PANEL ASSEMBLY Enquire To Order
Photo Part No Description Price (each) Stock
670184409 REAR RH DOOR PANEL ASSEMBLY Enquire To Order
670184410 REAR RH DOOR PANEL ASSEMBLY Enquire To Order
Photo Part No Description Price (each) Stock
670314713 FRONT RH PILLAR COVER ASSEMBLY Enquire To Order
Photo Part No Description Price (each) Stock
670314716 FRONT LH PILLAR COVER ASSEMBLY Enquire To Order
Photo Part No Description Price (each) Stock
670266147 TRIM ON LEFT REAR DOOR UPPER PANEL Enquire To Order
Photo Part No Description Price (each) Stock
670266146 TRIM ON RIGHT REAR DOOR UPPER PANEL Enquire To Order
Photo Part No Description Price (each) Stock
670212939 BRACKET $10.01 To Order
Photo Part No Description Price (each) Stock
670212941 BRACKET $10.01 To Order
Photo Part No Description Price (each) Stock
670270156 COMPLETE LH. KICK PLATE Enquire To Order
670270159 COMPLETE LH. KICK PLATE Enquire To Order
Photo Part No Description Price (each) Stock
670270160 COMPLETE RH. KICK PLATE Enquire To Order
670270163 COMPLETE RH. KICK PLATE Enquire To Order
Photo Part No Description Price (each) Stock
670198395 LH FRONT KICK PLATE Enquire To Order
670198396 LH FRONT KICK PLATE Enquire To Order
Photo Part No Description Price (each) Stock
670198397 RH FRONT KICK PLATE Enquire To Order
670198398 RH FRONT KICK PLATE Enquire To Order
Photo Part No Description Price (each) Stock
675000969 NUT $1.03 To Order
Photo Part No Description Price (each) Stock
675002310 SCREW $1.32 To Order
Photo Part No Description Price (each) Stock
670037768 FASTENING $1.83 To Order
Photo Part No Description Price (each) Stock
670295872 BRACKET $48.89 To Order
Photo Part No Description Price (each) Stock
670295873 BRACKET $48.89 To Order
Photo Part No Description Price (each) Stock
670295233 BRACKET $21.51 To Order
Photo Part No Description Price (each) Stock
675000432 SCREWM6X20 $2.42 To Order
Photo Part No Description Price (each) Stock
670295232 BRACKET $21.51 To Order
Photo Part No Description Price (each) Stock
670171794 COMPLETE SEAT BACK UPPER MOULDING Enquire To Order
670317918 COMPLETE SEAT BACK UPPER MOULDING Enquire To Order
Photo Part No Description Price (each) Stock
670006374 SCREW $3.13 To Order
675002310 SCREW $1.32 To Order
Photo Part No Description Price (each) Stock
675002321 BRACKET $1.41 To Order
Photo Part No Description Price (each) Stock
670266338 RH LOUD SPEAKER GRILL Enquire To Order
Photo Part No Description Price (each) Stock
670266339 LH LOUD SPEAKER GRILL Enquire To Order
Photo Part No Description Price (each) Stock
670214550 FASTENING PIN $1.45 To Order
Photo Part No Description Price (each) Stock
673014497 BUSHING $1.59 To Order
Photo Part No Description Price (each) Stock
673014498 SCREW $1.56 To Order
Photo Part No Description Price (each) Stock
673016617 ACOUSTIC FLEECE CABRIO RH/LH $22.72 To Order
Photo Part No Description Price (each) Stock
670035714 SCREW $2.21 To Order
Photo Part No Description Price (each) Stock
670295893 SCREW $2.62 To Order
Photo Part No Description Price (each) Stock
670219079 FIXING BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
670295443 RH BRACKET $49.71 To Order
Photo Part No Description Price (each) Stock
670295444 LH BRACKET $49.71 To Order
Photo Part No Description Price (each) Stock
670266957 RH REAR DOOR BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
670266958 LH REAR DOOR BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
673016618 METAL BUSHING $3.92 To Order
Photo Part No Description Price (each) Stock
673016619 ARMREST WINDOW REGULATOR CAP $31.06 To Order
Photo Part No Description Price (each) Stock
673016620 ARMREST WINDOW REGULATOR CAP $37.82 To Order
Photo Part No Description Price (each) Stock
673016621 METAL CLIP M5 $2.00 To Order
Photo Part No Description Price (each) Stock
673016622 ADHESIVE PAD $4.97 To Order
Photo Part No Description Price (each) Stock
673016623 PLASTIC CLIP (RIBLOCK) $1.32 To Order
Photo Part No Description Price (each) Stock
673016625 FRONT WIND DEFLECTOR CUP CAB $21.27 To Order
Photo Part No Description Price (each) Stock
673016626 FRONT WIND DEFLECTOR CUP CAB $21.27 To Order
View All
PASSENGER COMPARTMENT B PILLAR TRIM PANELS AND SIDE PANELS of Maserati Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670184413
REAR LH DOOR PANEL ASSEMBLY
Available with: PREMIUM AUDIO SYSTEM ; 		- 1 Enquire
1 670184414
REAR LH DOOR PANEL ASSEMBLY
Available with: HIGH-PREMIUM AUDIO SYSTEM ; 		- 1 Enquire
2 670184409
REAR RH DOOR PANEL ASSEMBLY
Available with: PREMIUM AUDIO SYSTEM ; 		- 1 Enquire
2 670184410
REAR RH DOOR PANEL ASSEMBLY
Available with: HIGH-PREMIUM AUDIO SYSTEM ; 		- 1 Enquire
3 670314713
FRONT RH PILLAR COVER ASSEMBLY
Available with: ALCANTARA ROOFLINING ; 		- 1 Enquire
4 670314716
FRONT LH PILLAR COVER ASSEMBLY
Available with: ALCANTARA ROOFLINING ; 		- 1 Enquire
5 670266147
TRIM ON LEFT REAR DOOR UPPER PANEL 		- 1 Enquire
6 670266146
TRIM ON RIGHT REAR DOOR UPPER PANEL 		- 1 Enquire
7 670212939
BRACKET 		$10.01 1
8 670212941
BRACKET 		$10.01 1
9 670270156
COMPLETE LH. KICK PLATE
Available with: ILLUMINATED STEEL DOOR SILLS ; 		- 1 Enquire
9 670270159
COMPLETE LH. KICK PLATE
Available with: STAINLESS STEEL DOOR SILLS ; 		- 1 Enquire
10 670270160
COMPLETE RH. KICK PLATE
Available with: ILLUMINATED STEEL DOOR SILLS ; 		- 1 Enquire
10 670270163
COMPLETE RH. KICK PLATE
Available with: STAINLESS STEEL DOOR SILLS ; 		- 1 Enquire
11 670198395
LH FRONT KICK PLATE
EU CN US JP ME KO N0; 		- 1 Enquire
11 670198396
LH FRONT KICK PLATE
AU UK JRH IN N8 UK3 GB; 		- 1 Enquire
12 670198397
RH FRONT KICK PLATE
EU CN US JP ME KO N0; 		- 1 Enquire
12 670198398
RH FRONT KICK PLATE
AU UK JRH IN N8 UK3 GB; 		- 1 Enquire
13 675000969
NUT 		$1.03 6
14 675002310
SCREW 		$1.32 12
15 670037768
FASTENING 		$1.83 2
16 670295872
BRACKET 		$48.89 1
17 670295873
BRACKET 		$48.89 1
18 670295233
BRACKET 		$21.51 1
19 675000432
SCREWM6X20 		$2.42 4
20 670295232
BRACKET 		$21.51 1
21 670171794
COMPLETE SEAT BACK UPPER MOULDING 		- 1 Enquire
21 670317918
COMPLETE SEAT BACK UPPER MOULDING
WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 8002898 - 99999999; 		- 1 Enquire
22 670006374
SCREW
EU CN US JP ME KO; 		$3.13 2
22 675002310
SCREW
AU UK JRH IN N8 UK3 GB; 		$1.32 2
23 675002321
BRACKET 		$1.41 2
24 670266338
RH LOUD SPEAKER GRILL 		- 1 Enquire
25 670266339
LH LOUD SPEAKER GRILL 		- 1 Enquire
26 670214550
FASTENING PIN 		$1.45 6
27 673014497
BUSHING 		$1.59 4
28 673014498
SCREW 		$1.56 42
29 673016617
ACOUSTIC FLEECE CABRIO RH/LH 		$22.72 2
30 670035714
SCREW 		$2.21 6
32 670295893
SCREW 		$2.62 13
33 670219079
FIXING BRACKET 		- 1 Enquire
34 670295443
RH BRACKET 		$49.71 1
35 670295444
LH BRACKET 		$49.71 1
37 670266957
RH REAR DOOR BUSHING 		- 1 Enquire
38 670266958
LH REAR DOOR BUSHING 		- 1 Enquire
39 673016618
METAL BUSHING 		$3.92 6
40 673016619
ARMREST WINDOW REGULATOR CAP 		$31.06 1
41 673016620
ARMREST WINDOW REGULATOR CAP 		$37.82 1
42 673016621
METAL CLIP M5 		$2.00 4
43 673016622
ADHESIVE PAD 		$4.97 4
44 673016623
PLASTIC CLIP (RIBLOCK) 		$1.32 22
45 673016625
FRONT WIND DEFLECTOR CUP CAB 		$21.27 1
46 673016626
FRONT WIND DEFLECTOR CUP CAB 		$21.27 1
