Name: BODY SHEEL: LOADING BED FRAME
Rating: 5.0 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	381300194	REAR FLOOR FRAMEWORK ASSY	$1,639.79	To Order

Photo	Part No	Description	Price (each)	Stock
	381300544	REAR RH SIDE MEMBER SIDE REINFORCEMENT	$24.61	To Order

Photo	Part No	Description	Price (each)	Stock
	381300186	REAR CENTRAL FLOOR ASSY	$3,186.52	To Order

Photo	Part No	Description	Price (each)	Stock
	381300633	UNDER ROOF REINF. WASHER.	$9.24	To Order

Photo	Part No	Description	Price (each)	Stock
	381300543	LH REAR SIDE MEMBER SIDE REINFORCEMENT	$24.61	To Order

Photo	Part No	Description	Price (each)	Stock
	381300427	REINFORCEMENT FOR JACK FRONT SUPPORT	$18.86	To Order

Photo	Part No	Description	Price (each)	Stock
	381300428	JACK COUPLING FRONT SUPPORT	$23.30	To Order

Photo	Part No	Description	Price (each)	Stock
	381300429	LH UNDERFLOOR FRONT REINFORCEMENT.	$22.88	To Order

Photo	Part No	Description	Price (each)	Stock
	381300189	RH CENTRE SIDE MEMBER FOR FLOOR ASSY	$53.45	To Order

Photo	Part No	Description	Price (each)	Stock
	381300193	LH CENTRE SIDE MEMBER FOR FLOOR ASSY	$57.20	To Order

Photo	Part No	Description	Price (each)	Stock
	381300430	RH UNDERFLOOR FRONT REINFORCEMENT.	$22.88	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	381300194	REAR FLOOR FRAMEWORK ASSY	381300194 REAR FLOOR FRAMEWORK ASSY	$1,639.79	1
2	381300544	REAR RH SIDE MEMBER SIDE REINFORCEMENT	381300544 REAR RH SIDE MEMBER SIDE REINFORCEMENT	$24.61	1
3	381300186	REAR CENTRAL FLOOR ASSY	381300186 REAR CENTRAL FLOOR ASSY	$3,186.52	1
4	381300633	UNDER ROOF REINF. WASHER.	381300633 UNDER ROOF REINF. WASHER.	$9.24	2
5	381300543	LH REAR SIDE MEMBER SIDE REINFORCEMENT	381300543 LH REAR SIDE MEMBER SIDE REINFORCEMENT	$24.61	1
6	381300427	REINFORCEMENT FOR JACK FRONT SUPPORT	381300427 REINFORCEMENT FOR JACK FRONT SUPPORT	$18.86	2
7	381300428	JACK COUPLING FRONT SUPPORT	381300428 JACK COUPLING FRONT SUPPORT	$23.30	2
8	381300429	LH UNDERFLOOR FRONT REINFORCEMENT.	381300429 LH UNDERFLOOR FRONT REINFORCEMENT.	$22.88	1
9	381300189	RH CENTRE SIDE MEMBER FOR FLOOR ASSY	381300189 RH CENTRE SIDE MEMBER FOR FLOOR ASSY	$53.45	1
10	381300193	LH CENTRE SIDE MEMBER FOR FLOOR ASSY	381300193 LH CENTRE SIDE MEMBER FOR FLOOR ASSY	$57.20	1
11	381300430	RH UNDERFLOOR FRONT REINFORCEMENT.	381300430 RH UNDERFLOOR FRONT REINFORCEMENT.	$22.88	1

Body Sheel: Loading Bed Frame

Maserati 3200 GT / Assetto Corsa
