Driven Shaft of Lamborghini Lamborghini Murcielago Roadster

View All

Lamborghini Murcielago Roadster - Driven Shaft

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	86311244B	SYNCHRONIZER T.C. D.100+CROWN GEAR	86311244B SYNCHRONIZER T.C. D.100+CROWN GEAR	$1,685.59	1
002	86311250C	FIRST GEAR ASSEMBLY (Order linked to the ref. 9 tav.24.05.00)	86311250C FIRST GEAR ASSEMBLY (Order linked to the ref. 9 tav.24.05.00)	$650.53	1
003	86311228A	Roller Bearing	86311228A Roller Bearing	$100.03	1
004	86301374A	BUSHING	86301374A BUSHING	$307.15	1
005	86311279	SHIM ADJUSTMENT	86311279 SHIM ADJUSTMENT	$333.37	1
006	86311762B	SYNCHRONIZING GEAR D.82 + CROWN GEAR	86311762B SYNCHRONIZING GEAR D.82 + CROWN GEAR	$842.79	1
007	86311532C	REVERSE GEAR ASSEMBLY + SYNCHRO	86311532C REVERSE GEAR ASSEMBLY + SYNCHRO	$591.85	1
008	24007184	INNER RING	24007184 INNER RING	$486.96	1
009	86311195G	SHAFT	86311195G SHAFT	$1,479.55	1
010	WHT003585	SEAL RING	WHT003585 SEAL RING	$43.53	1
011	86301609	BEARING 085	86301609 BEARING 085	$170.43	1
012	86311348C	GEAR	86311348C GEAR	$3,570.91	1
013	WHT003573	RETAINING RING	WHT003573 RETAINING RING	$2.50	1
014	86301897	BEARING	86301897 BEARING	$506.93	1
015	86301618	RING NUT	86301618 RING NUT	$268.46	1
016	86311599	PLUG	86311599 PLUG	$25.48	1
017	86311270C	FIRST GEAR ASSEMBLY	86311270C FIRST GEAR ASSEMBLY	$1,098.77	1
018	86311533A	INNER RING	86311533A INNER RING	$359.61	1
019	WHT003584	SEAL RING	WHT003584 SEAL RING	$29.90	1
020	86311187B	INNER RING	86311187B INNER RING	$328.40	1
021	86311129A	THIRD GEAR ASSEMBLY	86311129A THIRD GEAR ASSEMBLY	$4,376.25	1
022	86311309B	SYNCHRONIZING GEAR D.71/76 + CROWN GEAR	86311309B SYNCHRONIZING GEAR D.71/76 + CROWN GEAR	$1,348.46	1
023	86311145A	FOURTH GEAR ASSEMBLY	86311145A FOURTH GEAR ASSEMBLY	$3,308.73	1
024	86311153A	FIFTH GEAR	86311153A FIFTH GEAR	$636.79	1
025	86311165A	SIXTH GEAR	86311165A SIXTH GEAR	$614.29	1
026	86311876C	SPACER	86311876C SPACER	$179.20	1
027	86301845	BEARING	86301845 BEARING	$70.54	1
028	86311388	SHIM ADJUSTMENT	86311388 SHIM ADJUSTMENT	$34.86	2
029	86311770A	ROLLER CAGE	86311770A ROLLER CAGE	$42.39	2
030	86311531B	REVERSE IDLE GEAR	86311531B REVERSE IDLE GEAR	$636.79	1
031	8300610	STUD BOLT	8300610 STUD BOLT	$22.87 MSRP: ~~25.65~~ (10.8% off)	1
032	86311509	REVERS IDLE GEAR SHAFT	86311509 REVERS IDLE GEAR SHAFT	$342.12	1
034	8200616	NUT	8200616 NUT	$0.86 MSRP: ~~7.20~~ (88.1% off)	1
035	86311791	PLUG	86311791 PLUG	$15.61	1
036	WHT003587	SEAL RING	WHT003587 SEAL RING	$12.73	1
037	86311440	BEARING	86311440 BEARING	$167.31	1
039	WHT003582	SEAL RING	WHT003582 SEAL RING	$19.92	1
040	86311345C	GEAR	86311345C GEAR	$2,153.78	1
041	86311439	BEARING	86311439 BEARING	$61.68	1
042	86311667	RING NUT	86311667 RING NUT	$129.24	1
043	WHT003580	SEAL RING IN STOCK	WHT003580 SEAL RING IN STOCK	$14.18	1
044	86301133	BEARING 080	86301133 BEARING 080	$112.02	1
