Air Conditioning System 3

Lamborghini Murcielago Roadster

Find Your Part

Lamborghini Murcielago Roadster - Air Conditioning System 3

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Air Conditioning System 3 of Lamborghini Lamborghini Murcielago Roadster Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 413819203
DEFROSTER AIR CONVEYOR ASSEMBLY 		$826.63 1
002 400820901B
Air Vent 		$324.72 4
003 410819077
SUPPORT 		$37.45 3
004 410819320
PIPE 		$25.73 1
005 410819196
PIPE 		$19.37 2
006 410819119
CONNECTOR 		$24.92 2
007 410819318
PIPE 		$38.71 1
008 410819324
PIPE 		$4.50 1
009 410819226
GASKET 		$11.36 1
010 410819018
SEALING TAPE 		$28.72 2
011 410806229A
LEFT COVERING 		$261.60 1
011 410806230A
RIGHT COVERING 		$261.60 1
013 410805392
RIGHT CLOSING GRID 		$52.50 1
013 410805391
LEFT CLOSING GRID 		$52.50 1
014 410820367A
Pollen Filter
IN STOCK 		$59.02 2
015 410805395
RIGHT SUPPORT 		$132.36 1
015 410805396
LEFT SUPPORT 		$132.36 1
016 410805230
LH GASKET 		$21.43 1
016 410805349
RH GASKET 		$21.43 1
017 410805084
Fastener 		$4.31 4
018 N0115484
WASHER 		$4.11 2
019 WHT003093
Washer
IN STOCK 		$0.44 (94% off) 2
020 N90986803
HEXAGON SOCKET HEAD PANEL BOLT 2 X13
IN STOCK 		$1.37 2
021 N91109201
WASHER
IN STOCK 		$1.62 (72.3% off) 7
022 WHT000916A
CLIP 		$14.44 2
023 WHT000760
NUT M5 		$0.12 7
