Rear Brakes - Carboceramic

Lamborghini Murcielago LP670

Find Your Part

Lamborghini Murcielago LP670 - Rear Brakes - Carboceramic

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Rear Brakes - Carboceramic of Lamborghini Lamborghini Murcielago LP670 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 N10065003
SCREW M12X1,5X70 		$16.66 4
003 410611775A
HOSE 		$214.60 2
004 410615404C
RH BRAKE CALIPER 		$1,301.31 1
004 410615403C
LH BRAKE CALIPER 		$1,301.31 1
005 WHT002636
SCREW 		$7.46 2
006 WHT002636
SCREW 		$7.46 2
007 410798041A
BRAKE PAD SET 		$1,068.59 1
008 N90972501
HEXAGON SOCKET HEAD BOLT 		$2.64 (63.4% off) 6
010 410615601B
LH REAR BRAKE 		$7,559.18 1
010 410615602B
RH REAR BRAKE 		$7,559.18 1
011 410615405M
BLACK LH REAR CALIPER 		$4,217.63 1
011 410615406P
RH REAR BRAKE - SILVER 		$2,978.61 1
011 410615406R
ORANGE RH REAR CALIPER 		$2,978.61 1
011 410615406N
YELLOW RH REAR CALIPER 		$2,978.61 1
011 410615405N
YELLOW LH REAR CALIPER 		$2,978.61 1
011 410615405P
LH REAR BRAKE - SILVER 		$2,978.61 1
011 410615405R
ORANGE LH REAR CALIPER 		$3,910.98 1
011 410615406M
BLACK RH REAR CALIPER 		$4,217.63 1
012 4S0698151AA
SET OF BRAKE PADS FOR DISC BRAKE
IN STOCK 		$773.23 1
013 WHT004089
SCREW M12X1,25X35 		$8.26 4
014 WHT003303
SCREW WITH HOLE 		$12.09 2
015 WHT001191
WASHER
IN STOCK 		$0.35 (95.2% off) 2
016 WHT001191
WASHER
IN STOCK 		$0.35 (95.2% off) 2
020 410615384
BRACKET 		$616.87 2
021 400698317A
BRAKE PAD WEAR SENSOR 		- 2 Enquire
