Air Conditioning System 4 of Lamborghini Lamborghini Gallardo LP560 Coupe

View All

Lamborghini Gallardo LP560 Coupe - Air Conditioning System 4

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	400819120	SLEEVE	400819120 SLEEVE	$57.51	1
002	400819119	SLEEVE	400819119 SLEEVE	$80.63	1
003	400819258	SLEEVE	400819258 SLEEVE	$80.63	1
004	N10202001	CLAMP	N10202001 CLAMP	$2.33 MSRP: ~~7.03~~ (66.9% off)	2
005	N90863701	CLAMP	N90863701 CLAMP	$4.32	1
006	N90687001	SPRING BAND CLAMP IN STOCK	N90687001 SPRING BAND CLAMP IN STOCK	$7.05	7
007	N90686901	SPRING BAND CLAMP IN STOCK	N90686901 SPRING BAND CLAMP IN STOCK	$5.77	6
008	400819885A	PIPE	400819885A PIPE	$238.51	1
009	400819372B	PIPE	400819372B PIPE	$99.27	1
010	400820529	BRACKET	400820529 BRACKET	$10.70	1
011	400820891	BRACKET	400820891 BRACKET	$23.28	1
012	N90996001	CLAMP	N90996001 CLAMP	$7.27	1
013	N01508213	HEXAGON COLLAR NUT IN STOCK	N01508213 HEXAGON COLLAR NUT IN STOCK	$0.19	2
014	N91096701	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91096701 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$1.52	2
015	400819567	BRACKET	400819567 BRACKET	$22.71	1
016	N90687001	SPRING BAND CLAMP IN STOCK	N90687001 SPRING BAND CLAMP IN STOCK	$7.05	1
017	400819672	PIPE	400819672 PIPE	$187.15	1
018	400121129A	SPACER HOLDER	400121129A SPACER HOLDER	$14.60	2
019	7L121585	RUBBER BUSHING	7L121585 RUBBER BUSHING	$17.66	2
020	N91123701	CLAMP	N91123701 CLAMP	$4.57	2
021	N01508213	HEXAGON COLLAR NUT IN STOCK	N01508213 HEXAGON COLLAR NUT IN STOCK	$0.19	4
022	400965557A	BRACKET	400965557A BRACKET	$41.14	1
023	400819334	SLEEVE	400819334 SLEEVE	$330.51	1
024	3D0965561D	WATER PUMP	3D0965561D WATER PUMP	$290.52 MSRP: ~~297.00~~ (2.2% off)	1
025	N90770201	SPRING BAND CLAMP IN STOCK	N90770201 SPRING BAND CLAMP IN STOCK	$3.78	1
026	8Z0820535	EXTERNAL TEMPERATURE SENSOR	8Z0820535 EXTERNAL TEMPERATURE SENSOR	$37.01	1
029	400819373A	PIPE	400819373A PIPE	$148.99	1
030	400820036A	Heater Control Valve	400820036A Heater Control Valve	$596.27	1
031	400819374	PIPE	400819374 PIPE	$148.99	1
032	400820761B	BRACKET	400820761B BRACKET	$36.24	1
033	4D0614177A	STOP BUFFER	4D0614177A STOP BUFFER	$3.58	2
034	4D0614173B	BUSHING	4D0614173B BUSHING	$9.20	2
035	N10442204	HEXAGON SOCKET OVAL HEAD BOLT (COMBI) IN STOCK	N10442204 HEXAGON SOCKET OVAL HEAD BOLT (COMBI) IN STOCK	$2.08 MSRP: ~~7.14~~ (70.9% off)	2
036	420819498	GASKET	420819498 GASKET	$16.53	1
