Electrical System 2

Lamborghini Gallardo LP550 Spyder

Find Your Part

Lamborghini Gallardo LP550 Spyder - ELECTRICAL SYSTEM 2

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
ELECTRICAL SYSTEM 2 of Lamborghini Lamborghini Gallardo LP550 Spyder Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 400907552E
LIE CONTROL UNIT - 2WD (NOT FOR A MARKET SCANDINAVIA -ORDER ALSO REF. 4 - 7) 		$5,292.59 2
002 N91096601
HEXAGON SOCKET FLAT HEAD BOLT
IN STOCK 		$0.97 (86.8% off) 8
003 407907348D
LH BRACKET 		$191.84 1
003 407907324D
RH BRACKET 		$191.84 1
004 N91217601
SHEAR BOLT
IN STOCK 		$1.62 4
005 8E0907411J
BRACKET 		$60.94 2
006 420907637
YAWRATE SENSOR (ESP) 		$1,067.30 1
007 N90980304
SCREW M6X12
IN STOCK 		$1.89 (73.8% off) 4
008 400927156E
E-GEAR CONTROL UNIT (4WD - SOUTH KOREA) 		$1,554.84 1
008 400927156D
E-GEAR CONTROL UNIT (4WD) 		$7,078.23 1
009 8E0907500J
BRACKET 		$39.33 2
010 407907649
RH BRACKET 		$63.97 1
010 407907354
LH BRACKET 		$13.60 1
011 6Q0906507
BRACKET 		$19.13 1
012 N01508213
HEXAGON COLLAR NUT
IN STOCK 		$0.19 3
013 N01508213
HEXAGON COLLAR NUT
IN STOCK 		$0.19 2
014 8P0035503E
ANTENNA BLUETOOTH 		$29.47 1
016 N01508213
HEXAGON COLLAR NUT
IN STOCK 		$0.19 4
017 N01508213
HEXAGON COLLAR NUT
IN STOCK 		$0.19 2
019 8E0959643E
ROLL BAR SENSOR 		$190.03 2
022 407959255A
CAPOTE CONTROL UNIT 		$728.52 1
023 407907347
SUPPORT (E-GEAR) 		$41.77 1
024 N91096601
HEXAGON SOCKET FLAT HEAD BOLT
IN STOCK 		$0.97 (86.8% off) 5
025 N90338204
SCREW M6X45
IN STOCK 		$2.95 (59.1% off) 4
026 N01508213
HEXAGON COLLAR NUT
IN STOCK 		$0.19 2
027 407035643
BRACKET (CAPOTE-CD-ESP) 		$116.61 1
028 8P0862335AA
BLUETOOTH CONTROL UNIT 		$773.66 1
029 N91053801
SCREW M6X20 		$1.44 (80.2% off) 3
030 N91096601
HEXAGON SOCKET FLAT HEAD BOLT
IN STOCK 		$0.97 (86.8% off) 5
031 4F0937503
SUPPORT (ENGINE RELAY BOX WIRING HARNESS) 		$10.79 1
032 N01508213
HEXAGON COLLAR NUT
IN STOCK 		$0.19 2
033 4F1971845A
RETAINER FOR FUSE SOCKET 		$13.74 1
034 4F1937545
SUPPORT (CENTRAL WIRING HARNESS) 		$6.78 1
035 N10595002
ROUND HD. SCREW
IN STOCK 		$1.57 2
036 407862399
SUPPORT (ENGINE RELAY BOX WIRING HARNESS) 		$120.89 1
037 407971856
BRACKET (CAPOTE-CD-ESP) 		$14.81 1
038 4B0937545B
SUPPORT (CENTRAL WIRING HARNESS) 		$7.35 1
039 407971806
SUPPORT 		$52.47 1
