Lamborghini Diablo VT (1993-1998) - Steering 2

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	8581501	RETAINER RING	8581501 RETAINER RING ANELLO RITEGNO	$0.33	1
002	7M109381	RETAINING RING IN STOCK	7M109381 RETAINING RING ANELLO RITEGNO IN STOCK	$1.57 MSRP: ~~7.14~~ (78% off)	1
003	8501703	BEARING	8501703 BEARING CUSCINETTO	-	1	Enquire
004	4330715	SHIM	4330715 SHIM SPESSORE Dl REGISTRO	$3.85	1
004	4330714	SHIM	4330714 SHIM SPESSORE Dl REGISTRO	$3.12	1
004	4330716	SHIM	4330716 SHIM SPESSORE Dl REGISTRO	$9.20	1
005	4319324	STEERING COLUMN	4319324 STEERING COLUMN PIANTONE STERZO	$609.52	1
006	4309824	PIN	4309824 PIN PERNO	$69.06	1
007	8201416	NUT	8201416 NUT DADO	$1.62	1
008	4331627	PIN	4331627 PIN PERNO	$14.75	1
009	8522002	BEARING	8522002 BEARING CUSCINETTO	$9.83	1
010	8900401	PIN IN STOCK	8900401 PIN SA IN STOCK	$0.24 MSRP: ~~7.35~~ (96.7% off)	1
011	8100852	SCREW	8100852 SCREW VITE	$23.95	1
012	4327449	SUPPORT - SUPPORTO CANOTTO	4327449 SUPPORT - SUPPORTO CANOTTO O CANOTTO	$593.59	1
013	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.08 MSRP: ~~7.28~~ (85.2% off)	1
014	8401427	WASHER	8401427 WASHER RONDELLA	$2.62	1
015	4331626	LEVER	4331626 LEVER LEVA	$116.23	1
016	N10648502	SCREW M5X10 IN STOCK	N10648502 SCREW M5X10 VITE IN STOCK	$1.25 MSRP: ~~7.18~~ (82.6% off)	4
017	4310698	GUIDE	4310698 GUIDE GUIDA	$449.90	1
018	4330628	LOCK KEY	4330628 LOCK KEY CHIAVE Dl FERMtf	$87.67	1
019	8100401	SCREW	8100401 SCREW VITE	$0.44 MSRP: ~~7.30~~ (94% off)	1
020	8700611	SCREW UNI 5931 6X14	8700611 SCREW UNI 5931 6X14 VITE	$0.46	4
021	WHT003053	WASHER	WHT003053 WASHER RONDELLA	$3.07	4
022	4330288	PIPE	4330288 PIPE TUBO PORTA ALBERO	$918.30	1
023	8100815	SCREW	8100815 SCREW VITE	$8.96	1
024	8400801	WASHER	8400801 WASHER RONDELLA	$0.64	1
025	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.08 MSRP: ~~7.28~~ (85.2% off)	1
