Dashboard Instruments of Lamborghini Lamborghini Diablo SV (1999)

View All

Lamborghini Diablo SV (1999) - Dashboard Instruments

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	9414415	BRACKET	9414415 BRACKET STAFFA SX	$64.31	1
001	9414422	LEFT BRACKET	9414422 LEFT BRACKET (Valid for GB - July 1999) STAFFA SX	$45.38	1
001	9414422	LEFT BRACKET	9414422 LEFT BRACKET (Valid for AUSTRALIA - July 1999) STAFFA SX	$45.38	1
002	N01152427	WASHER IN STOCK	N01152427 WASHER RONDELLA IN STOCK	$0.28	4
003	N01100637	NUT M6 IN STOCK	N01100637 NUT M6 DADO IN STOCK	$0.30 MSRP: ~~7.29~~ (95.9% off)	4
004	9414435	RIGHT BRACKET	9414435 RIGHT BRACKET (Valid for GB - July 1999) STAFFA DX	$31.42	1
004	9414414	BRACKET	9414414 BRACKET STAFFA DX	$41.17	1
004	9414435	RIGHT BRACKET	9414435 RIGHT BRACKET (Valid for AUSTRALIA - July 1999) STAFFA DX	$31.42	1
005	9414416	SPRING	9414416 SPRING MOLLA	$17.43 MSRP: ~~19.60~~ (11.1% off)	2
006	4526662	TEMPERATURE SENS.	4526662 TEMPERATURE SENS. SENSORE TEMPERATURA ESTERNA	$218.81	1
007	60002492	WARNING LIGHTS	60002492 WARNING LIGHTS GRUPPO SPIE	$392.49 MSRP: ~~427.00~~ (8.1% off)	1
008	8700449	SCREW IN STOCK	8700449 SCREW VITE IN STOCK	$2.78 MSRP: ~~7.37~~ (62.3% off)	5
009	8220306	SPRING	8220306 SPRING MOLLA	$3.29 MSRP: ~~3.65~~ (9.9% off)	9
010	60002603	CLOCK	60002603 CLOCK OROLOGIO	$591.05 MSRP: ~~665.00~~ (11.1% off)	1
011	5933188	CIGAR LIGHTER	5933188 CIGAR LIGHTER ACCENDISIGARI	$21.54 MSRP: ~~23.35~~ (7.8% off)	1
012	60002617	INSTRUMENT PANEL	60002617 INSTRUMENT PANEL (Valid for GB - July 1999) PLANCIA PORTASTRUMENTI	$332.47 MSRP: ~~372.00~~ (10.6% off)	1
012	60002596	INSTRUMENT PANEL	60002596 INSTRUMENT PANEL PLANCIA PORTASTRUMENTI	$332.47 MSRP: ~~372.00~~ (10.6% off)	1
012	60002617	INSTRUMENT PANEL	60002617 INSTRUMENT PANEL (Valid for AUSTRALIA - July 1999) PLANCIA PORTASTRUMENTI	$332.47 MSRP: ~~372.00~~ (10.6% off)	1
013	8700347	SCREW	8700347 SCREW VITE	$29.09	9
014	8609802	SEAL	8609802 SEAL ANELLO COMMA	$0.58 MSRP: ~~7.28~~ (92% off)	1
015	60002598	REVOLUTION COUNT.	60002598 REVOLUTION COUNT. CONTAGIRI	$818.46 MSRP: ~~919.00~~ (10.9% off)	1
016	60002601	WATER TEMP. GAUGE	60002601 WATER TEMP. GAUGE INDICATORE TEMPERATURA ACQUA	$140.85 MSRP: ~~153.00~~ (7.9% off)	1
017	60002602	FUEL LEVEL GAUGE	60002602 FUEL LEVEL GAUGE INDICATORE LIVELLO CARBURANTE	$517.16 MSRP: ~~579.00~~ (10.7% off)	1
018	6030886	SPACER	6030886 SPACER DISTANZIALE	$51.19	5
019	60002604	SPEEDOMETER-MILES	60002604 SPEEDOMETER-MILES (Valid for USA - July 1999) CONTAMIGLIA	$688.03 MSRP: ~~746.00~~ (7.8% off)	1
019	60002597	SPEEDOMETER - KM	60002597 SPEEDOMETER - KM CONTACHILOMETRI	$2,929.28	1
019	60002604	SPEEDOMETER-MILES	60002604 SPEEDOMETER-MILES (Valid for GB - July 1999) CONTAMIGLIA	$688.03 MSRP: ~~746.00~~ (7.8% off)	1
020	8700457	SCREW	8700457 SCREW VITE	$0.07	4
021	9414433	BRACKET	9414433 BRACKET STAFFA	$58.66	2
022	9414432	BRACKET	9414432 BRACKET STAFFA	$30.08	2
023	8400509	WASHER	8400509 WASHER RONDELLA	$0.11 MSRP: ~~7.37~~ (98.5% off)	2
024	8200501	NUT	8200501 NUT DADO	$0.06	2
025	60002599	OIL PRESSURE GAUGE	60002599 OIL PRESSURE GAUGE INDICATORE PRESSIONE OLIO	$140.85 MSRP: ~~153.00~~ (7.9% off)	1
026	60002600	OIL TEMPERA. GAUGE	60002600 OIL TEMPERA. GAUGE INDICATORE TEMPERATURA OLIO	$518.34 MSRP: ~~580.00~~ (10.6% off)	1
027	60002493	WARNING LIGHTS	60002493 WARNING LIGHTS GRUPPO SPIE	$392.49 MSRP: ~~427.00~~ (8.1% off)	1
028	WHT002959	CLAMPING NUT IN STOCK	WHT002959 CLAMPING NUT DADO IN STOCK	$0.77 MSRP: ~~7.26~~ (89.4% off)	2
029	61002126	ELECT CABLE	61002126 ELECT CABLE CABLAGGIO CRUSCOTTO	$228.00 MSRP: ~~256.00~~ (10.9% off)	1
