Lamborghini Diablo VT Roadster (1998-2000) - Electrical System 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	WHT002963	WASHER IN STOCK	WHT002963 WASHER RONDELLA IN STOCK	$0.12 MSRP: ~~7.38~~ (98.4% off)	3
002	8920602	FLEXIBLE SUPPORT	8920602 FLEXIBLE SUPPORT SUPPORTO ELASTICO	$13.73	3
003	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.39	3
004	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.07	3
005	20001497	E.C.U. GFA	20001497 E.C.U. GFA (Valid for ARABIA 1998) CENTRALINA GFA	$9,715.03	1
005	20001497	E.C.U. GFA	20001497 E.C.U. GFA (Valid for DUBAI .1998) CENTRALINA GFA	$9,715.03	1
005	20001193	E.C.U. GFA	20001193 E.C.U. GFA CENTRALINA GFA	$5,664.23	1
005	20001194	E.C.U. GFA	20001194 E.C.U. GFA (Valid for U.S.A.1998) CENTRALINA GFA	-	1	Enquire
006	6311155	RELAY - (Valid for R.H.D. version - April 1994) RELAY BOSCH 87B 0332.015.006	6311155 RELAY - (Valid for R.H.D. version - April 1994) RELAY BOSCH 87B 0332.015.006 RELE ALIMENT. HAZARD	$53.59	1
007	6036297	RELAY	6036297 RELAY RELE ALIMENT. +15/30 HAZARD.	$37.23 MSRP: ~~41.90~~ (11.1% off)	1
008	6030676	RELAY - (Valid for R.H.D. version - April 1994) RELAY ITALAMEC 424.10	6030676 RELAY - (Valid for R.H.D. version - April 1994) RELAY ITALAMEC 424.10 RELE INTERMITTENZA	$146.37 MSRP: ~~160.00~~ (8.5% off)	1
009	6036296	RELAY	6036296 RELAY RELE CLACSON	$19.65 MSRP: ~~22.10~~ (11.1% off)	1
010	6135155	SUPPORT - SUPPORTO	6135155 SUPPORT - SUPPORTO O	$134.28	1
011	8400620	WASHER	8400620 WASHER RONDELLA	$1.39 MSRP: ~~7.38~~ (81.2% off)	4
012	8200605	NUT IN STOCK	8200605 NUT DADO IN STOCK	$2.84	4
013	WHT002959	CLAMPING NUT IN STOCK	WHT002959 CLAMPING NUT DADO IN STOCK	$0.77 MSRP: ~~7.26~~ (89.4% off)	4
014	8920603	ELASTIC SUPPORT	8920603 ELASTIC SUPPORT SUPPORTO ELASTICO	-	1	Enquire
015	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.39	1
016	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.07	1
017	6138342	CASE	6138342 CASE (Valid for U.S.A.1998) SCATOLA RELE/FUSIBILI	$1,112.09 MSRP: ~~1,210.00~~ (8.1% off)	1
017	6137052	CASE	6137052 CASE SCATOLA RELE/FUSIBILI	$845.89 MSRP: ~~919.00~~ (8% off)	1
017	6137443	CASE	6137443 CASE (Valid for U.K 1998) SCATOLA RELE/FUSIBILI	$1,062.56 MSRP: ~~1,155.00~~ (8% off)	1
018	6136981	KONI - SWITCH	6136981 KONI - SWITCH INTERRUTTORE - KONI	$219.54 MSRP: ~~239.50~~ (8.3% off)	1
019	6037932	E.C.U. AIR BAG	6037932 E.C.U. AIR BAG CENTRALINA AIR BAG	$755.44	1
020	5929915	LOCKING E.C.U.	5929915 LOCKING E.C.U. CENTR. CHIUSURA CENTR.	$412.77	1
021	6036175	LOW TIRE E.C.U.	6036175 LOW TIRE E.C.U. CENTRALINA LOW TIRE	$803.24 MSRP: ~~873.00~~ (8% off)	1
022	61001923	REMO. LOCKING E.C.U.	61001923 REMO. LOCKING E.C.U. COMANDO CHIUSURA CENTR.	$663.79 MSRP: ~~721.00~~ (7.9% off)	1
023	1629258	FUSE	1629258 FUSE FUSIBILE20A	$0.57 MSRP: ~~7.28~~ (92.2% off)	1
024	5936929	WINDOW LIFT E.C.U.	5936929 WINDOW LIFT E.C.U. CENTRALINA ALZAVETRO	$2,466.21	1
025	N01508213	HEXAGON COLLAR NUT IN STOCK	N01508213 HEXAGON COLLAR NUT DADO IN STOCK	$0.19	2
026	1128397	STUD	1128397 STUD COLONNETTA	$32.79 MSRP: ~~35.60~~ (7.9% off)	2
027	WHT002963	WASHER IN STOCK	WHT002963 WASHER RONDELLA IN STOCK	$0.12 MSRP: ~~7.38~~ (98.4% off)	2
028	8920602	FLEXIBLE SUPPORT	8920602 FLEXIBLE SUPPORT SUPPORTO ELASTICO	$13.73	2
029	6137314	LOW TIRE E. DEVICE	6137314 LOW TIRE E. DEVICE INTERFACCIA - LOW TIRE	$335.37 MSRP: ~~365.00~~ (8.1% off)	1
030	5134572	KONI E.C.U.	5134572 KONI E.C.U. CENTRALINA KONI	$2,091.69 MSRP: ~~2,340.00~~ (10.6% off)	1
031	6038007	RELAY	6038007 RELAY RELE	$11.36 MSRP: ~~12.35~~ (8% off)	3
031	6311155	RELAY - (Valid for R.H.D. version - April 1994) RELAY BOSCH 87B 0332.015.006	6311155 RELAY - (Valid for R.H.D. version - April 1994) RELAY BOSCH 87B 0332.015.006 RELE	$53.59	1
