Front Suspension of Lamborghini Lamborghini Diablo GT (1999-2000)

View All

Lamborghini Diablo GT (1999-2000) - Front Suspension

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 DADO IN STOCK	$20.49	4
002	410512383	FLEXIBLE BUSHING	410512383 FLEXIBLE BUSHING	$550.67	4
003	8101280	SCREW	8101280 SCREW VITE	$3.99	2
004	5134315	SPACER	5134315 SPACER SPESSORE	$33.38 MSRP: ~~36.30~~ (8% off)	2
005	8401234	WASHER	8401234 WASHER RONDELLA	$1.56 MSRP: ~~7.11~~ (78.1% off)	12
006	5133229	SCREW	5133229 SCREW VITE	$103.06	2
007	410512385	RUBBER RING	410512385 RUBBER RING	$49.65	4
008	51005137	SPRING	51005137 SPRING MOLLA	$898.09	2
009	51005374	ARM	51005374 ARM BRACCIO SUPERIORE DX	$1,472.82	1
009	51005375	ARM	51005375 ARM BRACCIO SUPERIORE SX	$1,439.19	1
010	5134392	TORSION BAR	5134392 TORSION BAR BARRA TORSIONE	$875.03 MSRP: ~~950.00~~ (7.9% off)	1
011	8101269	SCREW	8101269 SCREW VITE	$4.86	4
012	51004521	SPACER	51004521 SPACER DISTANZIALE	$36.79	4
013	8921206	RESILIENT BUSHING	8921206 RESILIENT BUSHING BOCCOLA ELASTICA	$46.75	8
014	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 DADO IN STOCK	$20.49	8
015	5238302	BUSHING IN STOCK	5238302 BUSHING BOCCOLA IN STOCK	$134.56	2
016	5230258	RETAINER	5230258 RETAINER CAVALLOTTO	$289.35	2
017	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$41.69	4
018	WHT002960	SCREW IN STOCK	WHT002960 SCREW VITE IN STOCK	$8.24	4
019	410411317	CONNECTING ROD	410411317 CONNECTING ROD BIELLETTA COMPLETA	$412.07	2
020	8100810	SCREW	8100810 SCREW VITE	-	4	Enquire
021	410407127A	BOLT	410407127A BOLT VITE CON ECCENTRICO	$2,172.69	4
022	410407127A	BOLT	410407127A BOLT ECCENTRICO	$2,172.69	4
023	51004125	ARM	51004125 ARM BRACCIO INFERIORE SX	$1,139.25	1
023	51004126	ARM	51004126 ARM BRACCIO INFERIORE DX	$1,139.25	1
024	WHT002941	SCREW M6X1X10	WHT002941 SCREW M6X1X10 VITE	$0.90 MSRP: ~~7.24~~ (87.6% off)	4
025	410407361B	COUPLING	410407361B COUPLING TESTA A SNODO	$1,171.51	2
026	410407171C	BUSH	410407171C BUSH BUSSOLA	$1,373.53	4
027	8201003	NUT	8201003 NUT DADO	$3.23	2
028	WHT000919	WASHER	WHT000919 WASHER	$14.05	2
029	51001030	BUSHING	51001030 BUSHING BUSSOLA	-	2	Enquire
030	410407365	Coupling	410407365 Coupling TESTA A SNODO	$246.60	2
031	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.08 MSRP: ~~7.28~~ (85.2% off)	4
032	5133165	SHOCK ABSORBER	5133165 SHOCK ABSORBER AMMORTIZZATORE	$1,236.45	2
