SECONDARY AIR SYSTEM of Lamborghini Lamborghini Aventador LP700 Roadster

View All

Lamborghini Aventador LP700 Roadster - SECONDARY AIR SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	400998075	PUMP IN STOCK	400998075 PUMP IN STOCK	$562.81	2
002	N10451408	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10451408 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$1.62	8
003	400127217	CLAMP IN STOCK	400127217 CLAMP IN STOCK	$0.37 MSRP: ~~7.33~~ (95% off)	6
004	N02214812	HEXAGON NUT, SELF-LOCKING	N02214812 HEXAGON NUT, SELF-LOCKING	$2.01 MSRP: ~~7.29~~ (72.4% off)	6
005	WHT002961	WASHER IN STOCK	WHT002961 WASHER IN STOCK	$0.39	10
006	N91054001	SEMI ROUND BOLT (COMBI) WITH HEXAGON SOCKET HEAD	N91054001 SEMI ROUND BOLT (COMBI) WITH HEXAGON SOCKET HEAD	$1.37 MSRP: ~~7.27~~ (81.2% off)	9
007	N10451408	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10451408 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$1.62	4
008	470131611B	AIR HOSE IN STOCK	470131611B AIR HOSE IN STOCK	$684.68	1
009	470131611C	AIR HOSE	470131611C AIR HOSE	$662.88	1
010	N0206253	CLAMP	N0206253 CLAMP	$1.83 MSRP: ~~7.07~~ (74.1% off)	5
011	6A131120D	SEAL IN STOCK	6A131120D SEAL IN STOCK	$7.51	4
012	470906613C	SUPPORT	470906613C SUPPORT	$42.58	1
013	470906617A	SUPPORT	470906617A SUPPORT	$22.84	1
014	7L131119	ADAPTER IN STOCK	7L131119 ADAPTER IN STOCK	$16.15	2
015	7L131101N	COMBINATION VALVE IN STOCK	7L131101N COMBINATION VALVE IN STOCK	$152.47	2
016	470133898A	PIPE	470133898A PIPE	$181.37	1
017	470133897B	PIPE	470133897B PIPE	$187.60	1
018	7L133579	T-PIECE	7L133579 T-PIECE	$7.45	1
019	470131845	PIPE	470131845 PIPE	$92.05	1
020	470131846	PIPE	470131846 PIPE	$43.09	1
021	470131853	PIPE	470131853 PIPE	$18.78	1
022	6L906052A	PRESSURE SENSOR IN STOCK	6L906052A PRESSURE SENSOR IN STOCK	$83.08	2
023	7M133106B	HEAT SHIELD	7M133106B HEAT SHIELD	$96.95	2
025	470906325A	HEAT SHIELD	470906325A HEAT SHIELD	$42.42	1
026	470906294A	HEAT SHIELD	470906294A HEAT SHIELD	$96.68	1
