View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	828152	HYDRAULIC UNIT	$3,206.65	To Order

Photo	Part No	Description	Price (each)	Stock
	232869	BUSH	$38.35	To Order

Photo	Part No	Description	Price (each)	Stock
	16287524	SCREW	$1.19	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	307688	YAW SENSOR	$257.85	To Order

Photo	Part No	Description	Price (each)	Stock
	16286124	SCREW	$0.35	To Order

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	828152	HYDRAULIC UNIT	828152 HYDRAULIC UNIT	$3,206.65	1
0002	305932	BRACKET	305932 BRACKET	$106.15	1
0002	316707	BRACKET	316707 BRACKET	$106.15	1
0003	232869	BUSH	232869 BUSH	$38.35	3
0004	16287524	SCREW IN STOCK	16287524 SCREW M8 X 25 IN STOCK	$1.19	3
0005	307688	YAW SENSOR	307688 YAW SENSOR	$257.85	1
0006	16286124	SCREW	16286124 SCREW M6 X 20	$0.35	2
