Crankcase

Ferrari 550 Maranello

Find Your Part

Ferrari 550 Maranello - CRANKCASE

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
171622 COMPLETE CRANKCASE $7,290.03 To Order
Photo Part No Description Price (each) Stock
171177 BALL RACE BEARING $17.74 IN STOCK
Photo Part No Description Price (each) Stock
196231 PISTON COOLING NOZZLE $50.55 To Order
Photo Part No Description Price (each) Stock
143856 O-RING $0.14 To Order
Photo Part No Description Price (each) Stock
14303123 SCREW $0.06 IN STOCK
Photo Part No Description Price (each) Stock
11181474 WASHER $0.06 To Order
Photo Part No Description Price (each) Stock
13526170 THREADED INSERT $3.63 To Order
Photo Part No Description Price (each) Stock
13972234 STUD BOLT $3.29 To Order
Photo Part No Description Price (each) Stock
140591 STUD BOLT $5.87 To Order
Photo Part No Description Price (each) Stock
163121 DOWEL $1.28 To Order
Photo Part No Description Price (each) Stock
13541224 STUD BOLT $134.08 To Order
Photo Part No Description Price (each) Stock
13543924 Stud Bolt $1.43 IN STOCK
Photo Part No Description Price (each) Stock
13543524 STUD BOLT $4.13 To Order
Photo Part No Description Price (each) Stock
13541924 STUD BOLT $1.14 To Order
Photo Part No Description Price (each) Stock
13541724 STUD BOLT $1.11 To Order
Photo Part No Description Price (each) Stock
13543424 STUD BOLT $1.69 To Order
Photo Part No Description Price (each) Stock
13543824 STUD BOLT $3.25 IN STOCK
Photo Part No Description Price (each) Stock
100041 CENTERING DOWEL $7.30 To Order
Photo Part No Description Price (each) Stock
13517224 STUD BOLT $0.66 To Order
Photo Part No Description Price (each) Stock
13543924 Stud Bolt $1.43 IN STOCK
Photo Part No Description Price (each) Stock
13543824 STUD BOLT $3.25 IN STOCK
Photo Part No Description Price (each) Stock
102704 ALIGNMENT DOWEL $2.70 IN STOCK
Photo Part No Description Price (each) Stock
13541024 STUD BOLT $0.29 To Order
Photo Part No Description Price (each) Stock
13541224 STUD BOLT $134.08 To Order
Photo Part No Description Price (each) Stock
103038 DOWEL $1.17 IN STOCK
Photo Part No Description Price (each) Stock
13546524 STUD BOLT $1.17 To Order
Photo Part No Description Price (each) Stock
163528 THREADED PLUG $3.70 IN STOCK
Photo Part No Description Price (each) Stock
14325540 THREADED PLUG $8.17 To Order
Photo Part No Description Price (each) Stock
10275550 THREADED PLUG $0.79 To Order
Photo Part No Description Price (each) Stock
13525870 THREADED INSERT $2.79 To Order
Photo Part No Description Price (each) Stock
150731 CAP $3.46 To Order
Photo Part No Description Price (each) Stock
10280060 WASHER COPPER D14. 20 X 1.5 $0.20 IN STOCK
Photo Part No Description Price (each) Stock
140316 CYLINDER LINER $1,108.80 To Order
Photo Part No Description Price (each) Stock
140321 GASKET $6.94 To Order
Photo Part No Description Price (each) Stock
10304640 THREADED PLUG $5.37 To Order
Photo Part No Description Price (each) Stock
10264560 GASKET $0.44 IN STOCK
Photo Part No Description Price (each) Stock
134232 O-RING $1.17 To Order
Photo Part No Description Price (each) Stock
151160 OIL PRESSURE LIMITING VALVE $155.53 To Order
Photo Part No Description Price (each) Stock
140553 STUD $6.49 To Order
Photo Part No Description Price (each) Stock
13525770 THREADED INSERT $2.61 To Order
Photo Part No Description Price (each) Stock
140545 FRONT HAT $138.70 To Order
Photo Part No Description Price (each) Stock
140499 INTERMEDIATE HAT $94.17 To Order
Photo Part No Description Price (each) Stock
140565 REAR HAT $110.48 To Order
Photo Part No Description Price (each) Stock
145493 DOWEL $1.78 To Order
Photo Part No Description Price (each) Stock
142588 WASHER $1.04 To Order
Photo Part No Description Price (each) Stock
142590 NUT $5.26 To Order
Photo Part No Description Price (each) Stock
13525570 THREADED INSERT $2.09 To Order
Photo Part No Description Price (each) Stock
13525570 THREADED INSERT $2.09 To Order
Photo Part No Description Price (each) Stock
141892 SUPPORT FOR MOTOR FIXING $226.85 To Order
Photo Part No Description Price (each) Stock
133988 HEX NUT M10 X 1.25 X 8 $0.20 IN STOCK
Photo Part No Description Price (each) Stock
11190574 WASHER $0.06 IN STOCK
Photo Part No Description Price (each) Stock
142865 HEAD GASKET $522.43 IN STOCK
Photo Part No Description Price (each) Stock
168358 Engine supporting pad $214.87 To Order
Photo Part No Description Price (each) Stock
172936 SPACER $6.34 To Order
Photo Part No Description Price (each) Stock
132269 LOWER SPACER $16.33 To Order
Photo Part No Description Price (each) Stock
11369634 SCREW $3.12 To Order
Photo Part No Description Price (each) Stock
12601774A WASHER Enquire To Order
Photo Part No Description Price (each) Stock
176573 SELF-LOCKING HEX NUT M16 X 1.5 $1.74 IN STOCK
Photo Part No Description Price (each) Stock
15970634 SCREW $0.38 To Order
Photo Part No Description Price (each) Stock
133988 HEX NUT M10 X 1.25 X 8 $0.20 IN STOCK
Photo Part No Description Price (each) Stock
127497 SPRING WASHER M10 $0.06 IN STOCK
Photo Part No Description Price (each) Stock
140664 NUT $53.09 To Order
Photo Part No Description Price (each) Stock
140603 WASHER $0.70 To Order
Photo Part No Description Price (each) Stock
126648 WASHER D.10.5-21 X 2 $1.66 IN STOCK
Photo Part No Description Price (each) Stock
127497 SPRING WASHER M10 $0.06 IN STOCK
Photo Part No Description Price (each) Stock
182141 RETAINER WASHER $41.69 To Order
View All
CRANKCASE of Ferrari Ferrari 550 Maranello Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 15981634
SCREW -Valid till Ass. Nr. 16066-
Valid from car Nr. 124570 		$2.38 (58.6% off) 2
- 192022
WICK BODY
Valid from car Nr. 124570 		$265.41 (30.6% off) 2
- 171622
COMPLETE CRANKCASE 		$7,290.03 1
- 171177
BALL RACE BEARING
Valid after stock exhaustion of 144713
IN STOCK 		$17.74 2
1 171622
COMPLETE CRANKCASE
With the complete crankcase 		$7,290.03 1
2 171177
BALL RACE BEARING
IN STOCK 		$17.74 2
3 196231
PISTON COOLING NOZZLE 		$50.55 12
4 143856
O-RING 		$0.14 (72% off) 12
5 14303123
SCREW
IN STOCK 		$0.06 12
6 11181474
WASHER 		$0.06 12
7 13526170
THREADED INSERT 		$3.63 (38.7% off) 3
8 13972234
STUD BOLT 		$3.29 1
9 140591
STUD BOLT 		$5.87 28
10 163121
DOWEL 		$1.28 4
11 13541224
STUD BOLT 		$134.08 1
12 13543924
Stud Bolt
IN STOCK 		$1.43 1
13 13543524
STUD BOLT 		$4.13 (5.1% off) 1
14 13541924
STUD BOLT 		$1.14 1
15 13541724
STUD BOLT 		$1.11 (72.3% off) 1
16 13543424
STUD BOLT 		$1.69 1
17 13543824
STUD BOLT
IN STOCK 		$3.25 1
18 100041
CENTERING DOWEL 		$7.30 2
19 13517224
STUD BOLT 		$0.66 (34% off) 2
20 13543924
Stud Bolt
IN STOCK 		$1.43 2
21 13543824
STUD BOLT
IN STOCK 		$3.25 3
22 102704
ALIGNMENT DOWEL
IN STOCK 		$2.70 2
23 13541024
STUD BOLT 		$0.29 (51.7% off) 2
24 13541224
STUD BOLT 		$134.08 2
25 103038
DOWEL
IN STOCK 		$1.17 2
26 13546524
STUD BOLT 		$1.17 (41.5% off) 8
27 163528
THREADED PLUG
IN STOCK 		$3.70 (12.9% off) 2
28 14325540
THREADED PLUG 		$8.17 2
29 10275550
THREADED PLUG 		$0.79 3
30 13525870
THREADED INSERT 		$2.79 2
31 150731
CAP 		$3.46 (3.6% off) 2
32 10280060
WASHER COPPER D14. 20 X 1.5
IN STOCK 		$0.20 (80% off) 2
33 140316
CYLINDER LINER 		$1,108.80 12
34 140321
GASKET 		$6.94 (27.9% off) 12
35 10304640
THREADED PLUG 		$5.37 1
36 10264560
GASKET
IN STOCK 		$0.44 (56% off) 1
37 134232
O-RING 		$1.17 (6.4% off) 1
38 151160
OIL PRESSURE LIMITING VALVE 		$155.53 1
39 140553
STUD 		$6.49 14
40 13525770
THREADED INSERT 		$2.61 (28.9% off) 2
41 140545
FRONT HAT
With complete crankcase 		$138.70 1
42 140499
INTERMEDIATE HAT
With complete crankcase 		$94.17 5
43 140565
REAR HAT
With complete crankcase 		$110.48 1
44 145493
DOWEL 		$1.78 14
45 142588
WASHER 		$1.04 14
46 142590
NUT 		$5.26 14
47 13525570
THREADED INSERT 		$2.09 2
48 13525570
THREADED INSERT 		$2.09 1
49 141892
SUPPORT FOR MOTOR FIXING 		$226.85 2
50 133988
HEX NUT M10 X 1.25 X 8
IN STOCK 		$0.20 (42.9% off) 8
51 11190574
WASHER
IN STOCK 		$0.06 8
52 142865
HEAD GASKET
IN STOCK 		$522.43 2
53 168358
Engine supporting pad
Valid till car Nr. 124569 		$214.87 (28.6% off) 2
54 172936
SPACER
Vale fino alla vett. No. 124569 		$6.34 2
55 132269
LOWER SPACER
Vale fino alla vett. No. 124569 		$16.33 2
56 11369634
SCREW
Valid till car Nr. 124569 		$3.12 (22% off) 2
57 12601774A
WASHER 		- 2 Enquire
58 176573
SELF-LOCKING HEX NUT M16 X 1.5
IN STOCK 		$1.74 (22.7% off) 2
59 15970634
SCREW 		$0.38 (88.3% off) 8
60 133988
HEX NUT M10 X 1.25 X 8
IN STOCK 		$0.20 (42.9% off) 8
61 127497
SPRING WASHER M10
IN STOCK 		$0.06 (92% off) 8
62 140664
NUT 		$53.09 28
63 140603
WASHER 		$0.70 (34.6% off) 28
64 126648
WASHER D.10.5-21 X 2
IN STOCK 		$1.66 (5.1% off) 8
65 127497
SPRING WASHER M10
IN STOCK 		$0.06 (92% off) 8
66 182141
RETAINER WASHER
Valid from car Nr. 124570 		$41.69 (32.2% off) 2
