Refrigerant Circuit, D - Mj 2017>>

Bentley Mulsanne (2010+)

Find Your Part

Bentley Mulsanne (2010+) - refrigerant circuit, D - MJ 2017>>

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
3Y0260347A connecting piece, see illustration: $190.78 To Order
Photo Part No Description Price (each) Stock
3Y5816885 set refrigerant/coolant lines $572.36 To Order
Photo Part No Description Price (each) Stock
8D0201441C speed nut $1.65 To Order
Photo Part No Description Price (each) Stock
4D0260749B seal ring $4.34 To Order
Photo Part No Description Price (each) Stock
4E0260749B seal ring $4.64 IN STOCK
Photo Part No Description Price (each) Stock
4E0260759F bracket for refrigerant, hose $5.65 To Order
Photo Part No Description Price (each) Stock
N90887704 hex. nut $1.20 To Order
Photo Part No Description Price (each) Stock
4E0260759F bracket for refrigerant, hose $5.65 To Order
Photo Part No Description Price (each) Stock
8D0201441C speed nut $1.65 To Order
Photo Part No Description Price (each) Stock
3Y0816725 refrigerant tube $177.15 To Order
Photo Part No Description Price (each) Stock
3D0260749C seal ring $4.64 IN STOCK
Photo Part No Description Price (each) Stock
3D0260749C seal ring $4.64 IN STOCK
Photo Part No Description Price (each) Stock
3Y0816743 refrigerant tube $163.52 To Order
Photo Part No Description Price (each) Stock
4E0260749B seal ring $4.64 IN STOCK
Photo Part No Description Price (each) Stock
4E0260749B seal ring $4.64 IN STOCK
Photo Part No Description Price (each) Stock
N91219101 Flat head multi-point socket bolt $1.19 To Order
Photo Part No Description Price (each) Stock
8A0260749AJ o-ring $2.90 To Order
Photo Part No Description Price (each) Stock
8E0260749D o-ring $4.34 To Order
Photo Part No Description Price (each) Stock
4H0816181 expansion valve $109.85 To Order
Photo Part No Description Price (each) Stock
N10723801 Socket head bolt with inner hex round head $0.42 To Order
Photo Part No Description Price (each) Stock
3Y0260127B cover, expansion valve $62.59 To Order
View All
refrigerant circuit, D - MJ 2017>> of Bentley Bentley Mulsanne (2010+) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 3Y0260347A
connecting piece, see illustration:
260-040, 		$190.78 1
2 3Y5816885
set refrigerant/coolant lines 		$572.36 1
3 8D0201441C
speed nut 		$1.65 1
4 4D0260749B
seal ring
7,6X2,5, 		$4.34 1
5 4E0260749B
seal ring
13,7X2,5,
IN STOCK 		$4.64 1
6 4E0260759F
bracket for refrigerant, hose 		$5.65 1
7 N90887704
hex. nut
M6, 		$1.20 1
8 4E0260759F
bracket for refrigerant, hose 		$5.65 1
9 8D0201441C
speed nut 		$1.65 1
10 3Y0816725
refrigerant tube 		$177.15 1
11 3D0260749C
seal ring
9,5X2,5,
IN STOCK 		$4.64 1
12 3D0260749C
seal ring
9,5X2,5,
IN STOCK 		$4.64 1
13 3Y0816743
refrigerant tube 		$163.52 1
14 4E0260749B
seal ring
13,7X2,5,
IN STOCK 		$4.64 1
15 4E0260749B
seal ring
13,7X2,5,
IN STOCK 		$4.64 1
16 N91219101
Flat head multi-point socket bolt
M8X25, 		$1.19 4
17 8A0260749AJ
o-ring
10,8X1,82, 		$2.90 1
18 8E0260749D
o-ring
14X1,82, 		$4.34 1
19 4H0816181
expansion valve
TXV, 		$109.85 1
20 N10723801
Socket head bolt with inner hex round head
M5X40, 		$0.42 2
21 3Y0260127B
cover, expansion valve 		$62.59 1
