Name: Exterior trim / Grille / Seals
Rating: 5.0 (1 reviews)

Exterior trim / Grille / Seals of Rolls Royce Rolls Royce Phantom Drophead Coupe

View All

Rolls Royce Phantom Drophead Coupe - Exterior trim / Grille / Seals

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	51117166090	Trim ring, headlight, right	$628.92	To Order
	51137166089	Trim ring, headlight, left	$628.92	To Order

Photo	Part No	Description	Price (each)	Stock
	51137174550	Moulding, hood, centre	$2,511.56	To Order

Photo	Part No	Description	Price (each)	Stock
	51137165554	Trim, windscreen, top	$4,237.78	To Order
	51137190254	Trim, windscreen, top	$2,756.16	To Order

Photo	Part No	Description	Price (each)	Stock
	51137165555	Cover, side window, left	$6,358.38	To Order
	51137165556	Cover, side window, right	$6,358.38	To Order
	51137190257	Cover, side window, left	$5,601.42	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	51317184755	Bracket, left	$87.84	To Order
	51317184756	Bracket, right	$87.84	To Order

Photo	Part No	Description	Price (each)	Stock
	51137165559	Cover, windshield, top	$2,941.07	To Order

Photo	Part No	Description	Price (each)	Stock
	54347178421	Strip upper apron	$688.10	To Order

Photo	Part No	Description	Price (each)	Stock
	51317165607	Seal, side window, front left	$461.76	To Order
	51317165608	Seal, side window, front right	$461.76	To Order

Photo	Part No	Description	Price (each)	Stock
	51137205399	GASKET LEFT	$55.50	To Order
	51137205400	GASKET RIGHT	$55.50	To Order

Photo	Part No	Description	Price (each)	Stock
	7147193038	Torx-bolt with washer	$4.42	To Order
	51167044405	Fillister head screw	$1.55	To Order

Photo	Part No	Description	Price (each)	Stock
	51137189320	Clamp	$13.82	To Order

Photo	Part No	Description	Price (each)	Stock
	54347129643	Grommet	$3.24	To Order

Photo	Part No	Description	Price (each)	Stock
	63261378067	Expanding nut	$0.25	To Order

Photo	Part No	Description	Price (each)	Stock
	51417060988	Fillister head screw	$4.42	To Order

Photo	Part No	Description	Price (each)	Stock
	51361960559	Washer	$9.13	To Order

Photo	Part No	Description	Price (each)	Stock
	7129903266	Screw	$1.17	To Order

Photo	Part No	Description	Price (each)	Stock
	51717130195	Nut	$0.82	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7149124807	Sealing tape	$33.81	To Order
	81229407639	Butyl cord Bostik 1127	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	51137208725	Bracket	$37.41	To Order
	51137208726	Bracket	$37.41	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	51117166090	Trim ring, headlight, right	51117166090 Trim ring, headlight, right	$628.92	-
1	51137166089	Trim ring, headlight, left	51137166089 Trim ring, headlight, left	$628.92	-
2	51137174550	Moulding, hood, centre	51137174550 Moulding, hood, centre	$2,511.56	-
3	51137165554	Trim, windscreen, top	51137165554 Trim, windscreen, top STAINLESS STEEL	$4,237.78	-
3	51137190254	Trim, windscreen, top	51137190254 Trim, windscreen, top PRIMED	$2,756.16	-
4	51137165555	Cover, side window, left	51137165555 Cover, side window, left STAINLESS STEEL	$6,358.38	-
4	51137165556	Cover, side window, right	51137165556 Cover, side window, right STAINLESS STEEL	$6,358.38	-
4	51137190257	Cover, side window, left	51137190257 Cover, side window, left PRIMED	$5,601.42	-
4	51137190258	Cover, side window, right	51137190258 Cover, side window, right PRIMED	$5,601.42	-
5	51317184755	Bracket, left	51317184755 Bracket, left	$87.84	-
5	51317184756	Bracket, right	51317184756 Bracket, right	$87.84	-
6	51137165559	Cover, windshield, top	51137165559 Cover, windshield, top	$2,941.07	-
7	54347178421	Strip upper apron	54347178421 Strip upper apron	$688.10	-
8	51317165607	Seal, side window, front left	51317165607 Seal, side window, front left	$461.76	-
8	51317165608	Seal, side window, front right	51317165608 Seal, side window, front right	$461.76	-
9	51137205399	GASKET LEFT	51137205399 GASKET LEFT	$55.50	-
9	51137205400	GASKET RIGHT	51137205400 GASKET RIGHT	$55.50	-
10	7147193038	Torx-bolt with washer	7147193038 Torx-bolt with washer ISA M4X12	$4.42	-
10	51167044405	Fillister head screw	51167044405 Fillister head screw 4X10MM	$1.55	-
11	51137189320	Clamp	51137189320 Clamp	$13.82	-
12	54347129643	Grommet	54347129643 Grommet	$3.24	-
13	63261378067	Expanding nut	63261378067 Expanding nut	$0.25	-
14	51417060988	Fillister head screw	51417060988 Fillister head screw M5X18,5	$4.42	-
15	51361960559	Washer	51361960559 Washer	$9.13	-
16	7129903266	Screw	7129903266 Screw NS-TS5X16-ZNFE	$1.17	-
17	51717130195	Nut IN STOCK	51717130195 Nut IN STOCK	$0.82	-
18	7149124807	Sealing tape	7149124807 Sealing tape	$33.81	-
18	81229407639	Butyl cord Bostik 1127	81229407639 Butyl cord Bostik 1127 B=3MM, L=5M	-	-	Enquire
19	51137208725	Bracket	51137208725 Bracket LH	$37.41	-
19	51137208726	Bracket	51137208726 Bracket RH	$37.41	-

Exterior Trim / Grille / Seals

Rolls Royce Phantom Drophead Coupe

Rolls Royce Phantom Drophead Coupe - Exterior trim / Grille / Seals
