View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	13A0286CP	GAS STRUT - BONNET	$62.84	To Order

Photo	Part No	Description	Price (each)	Stock
	00RA083	SCREW - M6X20 - FLANGE HEX	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	00RA392	BOLT - HEX HEAD - TUFLOK - M6X20 - 8.8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	00RC064	WASHER - M6X18X1.6 - BLACK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13AB108CP	HINGE - BONNET - RH	$379.47	To Order

Photo	Part No	Description	Price (each)	Stock
	13AB107CP	HINGE - BONNET - LH	$270.74	To Order

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
010	13A0286CP	GAS STRUT - BONNET	13A0286CP GAS STRUT - BONNET	$62.84	2
011	00RA083	SCREW - M6X20 - FLANGE HEX	00RA083 SCREW - M6X20 - FLANGE HEX	-	6	Enquire
012	00RA392	BOLT - HEX HEAD - TUFLOK - M6X20 - 8.8	00RA392 BOLT - HEX HEAD - TUFLOK - M6X20 - 8.8 Superseded parts: 00RA600;	-	8	Enquire
013	00RC064	WASHER - M6X18X1.6 - BLACK	00RC064 WASHER - M6X18X1.6 - BLACK	-	8	Enquire
014	13AB108CP	HINGE - BONNET - RH	13AB108CP HINGE - BONNET - RH	$379.47	1
015	13AB107CP	HINGE - BONNET - LH	13AB107CP HINGE - BONNET - LH	$270.74	1
