12 - D1 - Steering System - 12.1 - 01 - Steering System

McLaren 12C Coupe

Find Your Part

McLaren 12C Coupe - 12 - D1 - STEERING SYSTEM - 12.1 - 01 - STEERING SYSTEM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
11D0091CP Gaiter Kit - Steering Rack $28.91 To Order
Photo Part No Description Price (each) Stock
11D0116CP Nut & Bolt - Steering Column - Intermediate $8.85 To Order
Photo Part No Description Price (each) Stock
11D0233CP Hose - Pipe - Filter to Steering Rack - RHD - 675LT $385.78 To Order
11D0114CP HOSE-FILTER TO PUM24RHD $385.78 To Order
11D0232CP Hose - Pipe - Filter to Steering Rack - LHD - 675LT Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
11D0010CP Mounting Cap - Steering Rack $366.48 To Order
Photo Part No Description Price (each) Stock
11D0009CP Steering Rack Rubber $53.02 To Order
Photo Part No Description Price (each) Stock
00RA029 Bolt - M10x80 - Hex Enquire To Order
Photo Part No Description Price (each) Stock
11D0113CP HOSE-RESERVOIR TO 24LTER + PUM $482.23 To Order
11D0111CP Hose - PAS Reservoir - Filter - EHPAS - LHD Enquire To Order
Photo Part No Description Price (each) Stock
11D0122CP Heatshield - Trackrod $57.84 To Order
Photo Part No Description Price (each) Stock
13DA034CP RESERVOIR - PAS FLUID $77.15 To Order
Photo Part No Description Price (each) Stock
11C0502CP CAP-EHPAS RESERVOIR $124.56 To Order
Photo Part No Description Price (each) Stock
00RA120 SCREW - M6X25 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA083 SCREW - M6X20 - FLANGE HEX Enquire To Order
Photo Part No Description Price (each) Stock
11D0103CP Bracket - PAS Fluid Reservoir $81.44 To Order
Photo Part No Description Price (each) Stock
00RA055 NUT - M6 - LOCKING - HEX Enquire To Order
Photo Part No Description Price (each) Stock
11D0181CP Hose - PAS Pump to APMU - RHD - Noselift $824.11 To Order
11D0137CP ASSY HOSE-FEED-PUM24TO MANIFOL Enquire To Order
11D0145CP Hose - PAS Pump to APMU - LHD - Noselift Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
11D0074CP Pump - PAS - Steering $2,453.17 To Order
Photo Part No Description Price (each) Stock
00RB045 CLIP - 9.5-10MM - MALE Enquire To Order
Photo Part No Description Price (each) Stock
11D0129CP Cover - Pump - PAS - Steering $144.66 To Order
Photo Part No Description Price (each) Stock
00RA313 SCREW - M6X16 - HEX - SILVER Enquire To Order
Photo Part No Description Price (each) Stock
11D0126CP Bracket - Power Steering Pump - RHD $536.62 To Order
11D0125CP Bracket - Power Steering Pump - LHD Enquire To Order
Photo Part No Description Price (each) Stock
11D0033CP Steering Column - Intermediate - RHD $212.18 To Order
11D0187CP Steering Column - Intermediate - LHD Enquire To Order
Photo Part No Description Price (each) Stock
11D0254CP GAITER-STEERING CO24MN $28.91 To Order
Photo Part No Description Price (each) Stock
00RB049 HOSE CLAMP - 40-60MM Enquire To Order
Photo Part No Description Price (each) Stock
11D0270CP Steering Rack - RHD - Tedrive $11,338.66 To Order
11D0076CP Steering Rack - RHD - TRW $5,850.36 To Order
11D0269CP Steering Rack - LHD - Tedrive Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
00RA153 Bolt - M10x40 - Hex Enquire To Order
Photo Part No Description Price (each) Stock
11D0231CP Hose - APMU to Steering Rack - RHD - Tedrive Rack $268.30 To Order
11C0218CP ASSY-HOSE-FEED-MAN24OLD TO RAC $212.18 To Order
11D0230CP Hose - APMU to Steering Rack - LHD - Tedrive Rack Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
00RB046 CLIP - 8-9MM - FEMALE Enquire To Order
Photo Part No Description Price (each) Stock
11D0127CP BRKT-ANGLE-POWER S24ER BRKT TO $62.67 To Order
Photo Part No Description Price (each) Stock
11D0124CP MOUNT - AV - RUBBER $33.75 To Order
Photo Part No Description Price (each) Stock
00RB032 CLIP - 13-14MM - FEMALE Enquire To Order
Photo Part No Description Price (each) Stock
00RB110 OETIKER CLIP - 19.2 Enquire To Order
11D0095CP FILTER - PAS - STEERING $540.10 To Order
Photo Part No Description Price (each) Stock
11D0100CP O-ring - Hose - EHPAS Pump $5.57 To Order
Photo Part No Description Price (each) Stock
11D0102CP Back-up Ring - Hose - EHPAS Pump $4.59 To Order
Photo Part No Description Price (each) Stock
11D0128CP LAGGING-HOSE-FEED-24MP TO MANI $71.85 To Order
Photo Part No Description Price (each) Stock
11D0054CP Ball Joint - Steering Rack - Outer - Tedrive Rack $135.01 To Order
11B0378CP Tie Rod - Ball Joint - Outer $308.62 To Order
View All
12 - D1 - STEERING SYSTEM - 12.1 - 01 - STEERING SYSTEM of McLaren McLaren 12C Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
010 11D0091CP
Gaiter Kit - Steering Rack 		$28.91 1
011 11D0116CP
Nut & Bolt - Steering Column - Intermediate 		$8.85 1
012 11D0233CP
Hose - Pipe - Filter to Steering Rack - RHD - 675LT 		$385.78 1
012 11D0114CP
HOSE-FILTER TO PUM24RHD 		$385.78 1
012 11D0232CP
Hose - Pipe - Filter to Steering Rack - LHD - 675LT 		- 1 Enquire
012 11D0112CP
Hose - Pipe - Filter to Steering Rack - LHD - TRW Rack 		- 1 Enquire
013 11D0010CP
Mounting Cap - Steering Rack 		$366.48 4
014 11D0009CP
Steering Rack Rubber 		$53.02 2
015 00RA029
Bolt - M10x80 - Hex 		- 2 Enquire
016 11D0113CP
HOSE-RESERVOIR TO 24LTER + PUM 		$482.23 1
016 11D0111CP
Hose - PAS Reservoir - Filter - EHPAS - LHD 		- 1 Enquire
017 11D0122CP
Heatshield - Trackrod 		$57.84 4
018 13DA034CP
RESERVOIR - PAS FLUID 		$77.15 2
019 11C0502CP
CAP-EHPAS RESERVOIR 		$124.56 1
020 00RA120
SCREW - M6X25 - HEX 		- 2 Enquire
021 00RA083
SCREW - M6X20 - FLANGE HEX 		- 2 Enquire
022 11D0103CP
Bracket - PAS Fluid Reservoir 		$81.44 2
023 00RA055
NUT - M6 - LOCKING - HEX 		- 6 Enquire
024 11D0181CP
Hose - PAS Pump to APMU - RHD - Noselift
Superseded parts: 11D0146CP; 		$824.11 1
024 11D0137CP
ASSY HOSE-FEED-PUM24TO MANIFOL 		- 1 Enquire
024 11D0145CP
Hose - PAS Pump to APMU - LHD - Noselift
Superseded parts: 11D0145CP; 		- 1 Enquire
024 11D0149CP
Hose - PAS Pump to APMU - LHD 		- 1 Enquire
025 11D0074CP
Pump - PAS - Steering 		$2,453.17 2
026 00RB045
CLIP - 9.5-10MM - MALE 		- 2 Enquire
027 11D0129CP
Cover - Pump - PAS - Steering 		$144.66 2
028 00RA313
SCREW - M6X16 - HEX - SILVER 		- 4 Enquire
029 11D0126CP
Bracket - Power Steering Pump - RHD 		$536.62 1
029 11D0125CP
Bracket - Power Steering Pump - LHD 		- 1 Enquire
030 11D0033CP
Steering Column - Intermediate - RHD 		$212.18 1
030 11D0187CP
Steering Column - Intermediate - LHD
Superseded parts: 11D0015CP; 		- 1 Enquire
031 11D0254CP
GAITER-STEERING CO24MN
Superseded parts: 11D0045CP; 		$28.91 2
032 00RB049
HOSE CLAMP - 40-60MM 		- 1 Enquire
033 11D0270CP
Steering Rack - RHD - Tedrive 		$11,338.66 1
033 11D0076CP
Steering Rack - RHD - TRW 		$5,850.36 1
033 11D0269CP
Steering Rack - LHD - Tedrive 		- 1 Enquire
033 11D0075CP
Steering Rack - LHD - TRW 		- 1 Enquire
034 00RA153
Bolt - M10x40 - Hex 		- 2 Enquire
035 11D0231CP
Hose - APMU to Steering Rack - RHD - Tedrive Rack 		$268.30 1
035 11C0218CP
ASSY-HOSE-FEED-MAN24OLD TO RAC 		$212.18 1
035 11D0230CP
Hose - APMU to Steering Rack - LHD - Tedrive Rack 		- 1 Enquire
035 11C0217CP
Hose - APMU to Steering Rack - LHD - TRW 		- 1 Enquire
036 00RB046
CLIP - 8-9MM - FEMALE 		- 1 Enquire
037 11D0127CP
BRKT-ANGLE-POWER S24ER BRKT TO 		$62.67 1
038 11D0124CP
MOUNT - AV - RUBBER 		$33.75 1
039 00RB032
CLIP - 13-14MM - FEMALE 		- 1 Enquire
040 00RB110
OETIKER CLIP - 19.2 		- 1 Enquire
040 11D0095CP
FILTER - PAS - STEERING 		$540.10 1
041 11D0100CP
O-ring - Hose - EHPAS Pump 		$5.57 1
042 11D0102CP
Back-up Ring - Hose - EHPAS Pump 		$4.59 1
043 11D0128CP
LAGGING-HOSE-FEED-24MP TO MANI 		$71.85 2
044 11D0054CP
Ball Joint - Steering Rack - Outer - Tedrive Rack 		$135.01 2
044 11B0378CP
Tie Rod - Ball Joint - Outer 		$308.62 1
