Cooling: Air Radiators And Ducts

Maserati Quattroporte (2008-2012) 4.2

Find Your Part

Maserati Quattroporte (2008-2012) 4.2 - COOLING: AIR RADIATORS AND DUCTS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
223561 Water Radiator $511.16 IN STOCK
Photo Part No Description Price (each) Stock
201064 LH BRACKET FOR UPPER FIXING WATER RADIATOR $8.35 To Order
201372 RH BRACKET FOR UPPER FIXING WATER RADIATOR $7.60 To Order
Photo Part No Description Price (each) Stock
16044624 SCREW $2.52 IN STOCK
Photo Part No Description Price (each) Stock
84653800 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
12601374 WASHER D.8.40-15 X 0.8 $1.42 IN STOCK
Photo Part No Description Price (each) Stock
14040711 NUT M8 FLANGED $1.90 IN STOCK
Photo Part No Description Price (each) Stock
193556 RUBBER PROFILE $2.24 To Order
Photo Part No Description Price (each) Stock
199512 L.H. UPPER BRACKET $6.65 To Order
199513 R.H. UPPER BRACKET $6.65 To Order
Photo Part No Description Price (each) Stock
181114 Pad $12.85 IN STOCK
Photo Part No Description Price (each) Stock
16043021 SCREW $1.76 To Order
Photo Part No Description Price (each) Stock
12601374 WASHER D.8.40-15 X 0.8 $1.42 IN STOCK
Photo Part No Description Price (each) Stock
248334 SCREW M6 X 14MM $3.09 IN STOCK
Photo Part No Description Price (each) Stock
11197774 WAVY WASHER D.6.4 X 12 X 1.2 $2.36 IN STOCK
Photo Part No Description Price (each) Stock
240471 RADIATOR AIR DUCT $384.14 To Order
Photo Part No Description Price (each) Stock
233535 PROFILE $2.52 IN STOCK
Photo Part No Description Price (each) Stock
233735 PROFILE $2.52 IN STOCK
Photo Part No Description Price (each) Stock
67257100 BRACKET $1.90 IN STOCK
Photo Part No Description Price (each) Stock
13274077 SCREW $1.76 IN STOCK
Photo Part No Description Price (each) Stock
12604178 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
12638178 Washer $1.90 IN STOCK
Photo Part No Description Price (each) Stock
199546 RH BRACKET $5.25 To Order
Photo Part No Description Price (each) Stock
248334 SCREW M6 X 14MM $3.09 IN STOCK
Photo Part No Description Price (each) Stock
11197774 WAVY WASHER D.6.4 X 12 X 1.2 $2.36 IN STOCK
Photo Part No Description Price (each) Stock
15699804 SCREW $1.85 IN STOCK
Photo Part No Description Price (each) Stock
15699804 SCREW $1.85 IN STOCK
Photo Part No Description Price (each) Stock
15699904 SCREW $2.15 IN STOCK
Photo Part No Description Price (each) Stock
263142 COMPLETE ELECTROFANS SET $886.32 IN STOCK
Photo Part No Description Price (each) Stock
16044824 SCREW $2.52 To Order
Photo Part No Description Price (each) Stock
84653800 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
197585 BUSH $6.93 IN STOCK
Photo Part No Description Price (each) Stock
197584 RUBBER BUSHING $6.02 IN STOCK
Photo Part No Description Price (each) Stock
263140 ELECTRIC FAN RESISTOR 0.23 OHM $91.10 To Order
Photo Part No Description Price (each) Stock
193538 AIR CONVEYOR SUPPORT BRACKET $25.76 IN STOCK
Photo Part No Description Price (each) Stock
980139638 PLUG LOWER RADIATOR $11.37 IN STOCK
Photo Part No Description Price (each) Stock
14054511 NUT $1.12 To Order
Photo Part No Description Price (each) Stock
14039614 NUT $1.34 IN STOCK
Photo Part No Description Price (each) Stock
12644424 WASHER 6.15-15 X 1 $1.45 IN STOCK
Photo Part No Description Price (each) Stock
13274077 SCREW $1.76 IN STOCK
Photo Part No Description Price (each) Stock
14039614 NUT $1.34 IN STOCK
Photo Part No Description Price (each) Stock
268185 CLAMP $1.85 To Order
Photo Part No Description Price (each) Stock
187713 RETAINING CLIP $5.23 IN STOCK
Photo Part No Description Price (each) Stock
81874500 BRACKET $23.10 To Order
Photo Part No Description Price (each) Stock
61789700 CLIP $1.60 IN STOCK
Photo Part No Description Price (each) Stock
68479900 Screw $3.68 IN STOCK
View All
COOLING: AIR RADIATORS AND DUCTS of Maserati Maserati Quattroporte (2008-2012) 4.2 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 223561
Water Radiator
IN STOCK 		$511.16 1
2 201064
LH BRACKET FOR UPPER FIXING WATER RADIATOR 		$8.35 1
2 201372
RH BRACKET FOR UPPER FIXING WATER RADIATOR 		$7.60 1
3 16044624
SCREW
IN STOCK 		$2.52 2
4 84653800
WASHER 		- 4 Enquire
5 12601374
WASHER D.8.40-15 X 0.8
IN STOCK 		$1.42 2
6 14040711
NUT M8 FLANGED
IN STOCK 		$1.90 2
7 193556
RUBBER PROFILE 		$2.24 (3.9% off) 2
8 199512
L.H. UPPER BRACKET 		$6.65 (13.4% off) 1
8 199513
R.H. UPPER BRACKET 		$6.65 (13.4% off) 1
9 181114
Pad
IN STOCK 		$12.85 2
10 16043021
SCREW 		$1.76 2
11 12601374
WASHER D.8.40-15 X 0.8
IN STOCK 		$1.42 2
12 248334
SCREW M6 X 14MM
IN STOCK 		$3.09 2
13 11197774
WAVY WASHER D.6.4 X 12 X 1.2
IN STOCK 		$2.36 2
14 240471
RADIATOR AIR DUCT 		$384.14 1
15 233535
PROFILE
IN STOCK 		$2.52 1
16 233735
PROFILE
IN STOCK 		$2.52 1
17 67257100
BRACKET
IN STOCK 		$1.90 5
18 13274077
SCREW
M5X12
IN STOCK 		$1.76 5
19 12604178
WASHER
D.5.3-11X0.5 		- 5 Enquire
20 12638178
Washer
D.5,2-14 X1
IN STOCK 		$1.90 5
21 199546
RH BRACKET 		$5.25 (14.4% off) 1
22 248334
SCREW M6 X 14MM
IN STOCK 		$3.09 1
23 11197774
WAVY WASHER D.6.4 X 12 X 1.2
IN STOCK 		$2.36 1
24 15699804
SCREW
IN STOCK 		$1.85 2
25 15699804
SCREW
IN STOCK 		$1.85 3
26 15699904
SCREW
IN STOCK 		$2.15 4
27 263142
COMPLETE ELECTROFANS SET
IN STOCK 		$886.32 1
28 16044824
SCREW 		$2.52 2
29 84653800
WASHER 		- 2 Enquire
30 197585
BUSH
IN STOCK 		$6.93 4
31 197584
RUBBER BUSHING
IN STOCK 		$6.02 4
32 263140
ELECTRIC FAN RESISTOR 0.23 OHM 		$91.10 (8.6% off) 1
33 193538
AIR CONVEYOR SUPPORT BRACKET
IN STOCK 		$25.76 2
34 980139638
PLUG LOWER RADIATOR
IN STOCK 		$11.37 1
35 14054511
NUT 		$1.12 2
36 14039614
NUT
IN STOCK 		$1.34 5
37 12644424
WASHER 6.15-15 X 1
IN STOCK 		$1.45 5
38 13274077
SCREW
M5X12
IN STOCK 		$1.76 4
39 14039614
NUT
IN STOCK 		$1.34 4
40 268185
CLAMP 		$1.85 1
41 187713
RETAINING CLIP
IN STOCK 		$5.23 2
42 81874500
BRACKET 		$23.10 1
43 61789700
CLIP
IN STOCK 		$1.60 1
44 68479900
Screw
IN STOCK 		$3.68 1
