Oil System Radiator of Lamborghini Lamborghini Gallardo Spyder

View All

Lamborghini Gallardo Spyder - Oil System Radiator

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	400117098A	BRACKET	400117098A BRACKET	$114.67	1
002	N0902324	SCREW M6X10 IN STOCK	N0902324 SCREW M6X10 IN STOCK	$1.88 MSRP: ~~7.25~~ (74.1% off)	1
003	N90847903	Screw M6X15 IN STOCK	N90847903 Screw M6X15 IN STOCK	$1.83	4
004	7L117413C	HOSE	7L117413C HOSE	$927.88	1
005	7L115687C	HOSE	7L115687C HOSE	$1,152.96	1
006	N10451405	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10451405 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$1.52 MSRP: ~~7.22~~ (78.9% off)	4
007	N90265703	NUT M6X7.6	N90265703 NUT M6X7.6	$8.63	2
008	400115339A	HEAT SHIELD	400115339A HEAT SHIELD	$247.59	1
009	400115707	CONNECTOR	400115707 CONNECTOR	$32.08	1
010	7L115664C	PIPE	7L115664C PIPE	$175.70	1
011	N10233401	CLAMP 16.2 X 7 X 0.60	N10233401 CLAMP 16.2 X 7 X 0.60	$3.01	2
013	7L115311D	PLUG IN STOCK	7L115311D PLUG IN STOCK	$237.29	1
014	7L115664C	PIPE	7L115664C PIPE	$175.70	2
016	N90107203	CLAMP 12 X 8.0 X 0.5	N90107203 CLAMP 12 X 8.0 X 0.5	$3.77	2
017	357711798	RUBBER SEAL IN STOCK	357711798 RUBBER SEAL IN STOCK	$3.26	2
018	N10005109	SCREW M8X35	N10005109 SCREW M8X35	$4.31	2
019	7L115373B	OIL TANK	7L115373B OIL TANK	$3,977.43	1
020	400115341B	HEAT SHIELD	400115341B HEAT SHIELD	$129.44	1
021	N10156305	SCREW M6X12	N10156305 SCREW M6X12	$2.18	1
022	7L115333B	RUBBER BUFFER	7L115333B RUBBER BUFFER	$10.83	1
023	N0138485	SEAL RING IN STOCK	N0138485 SEAL RING IN STOCK	$0.86 MSRP: ~~7.29~~ (88.2% off)	1
024	N91155901	SEALING SCREW PLUG M16 X 1.5	N91155901 SEALING SCREW PLUG M16 X 1.5	$13.08	1
025	7L919501A	Water Temperature Sensor IN STOCK	7L919501A Water Temperature Sensor IN STOCK	$338.43	1
026	7L115659G	OIL SUCTION ROSE	7L115659G OIL SUCTION ROSE	$976.64	1
027	7L115689B	PIPE IN STOCK	7L115689B PIPE IN STOCK	$421.69	1
028	N91107101	WASHER	N91107101 WASHER	$4.56	1
029	7L115688B	OILPIPE	7L115688B OILPIPE	$826.57	1
030	400117335	COOLER EXIT CONE	400117335 COOLER EXIT CONE	$1,207.99	1
031	400201365B	GASKET	400201365B GASKET	$17.13	2
032	400117097A	BRACKET	400117097A BRACKET	$467.68	1
033	400317025	LH CONVEYOR	400317025 LH CONVEYOR	$623.65	1
034	7L117015B	OIL COOLER	7L117015B OIL COOLER	$1,328.23	1
035	7L133741	SUPPORT	7L133741 SUPPORT	$13.89	1
036	7L115255	FLANGE	7L115255 FLANGE	$63.03	1
037	WHT000759	STUD BOLT (M6X14)	WHT000759 STUD BOLT (M6X14)	$5.02	2
038	N10129201	O-RING IN STOCK	N10129201 O-RING IN STOCK	$4.78	1
039	1J0711795	SPACER	1J0711795 SPACER	$3.55	2
040	400422095	FAIRLEAD	400422095 FAIRLEAD	$45.78	1
041	7L115333	RUBBER BUFFER	7L115333 RUBBER BUFFER	$21.65	1
042	N90937701	CABLE TIES IN STOCK	N90937701 CABLE TIES IN STOCK	$1.56 MSRP: ~~2.00~~ (22% off)	1
