Name: AIR-CONDITIONING SYSTEM WITH ELECTRONIC REGULATION
Rating: 4.8 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	N0206405	CLAMP	$1.89	To Order

Photo	Part No	Description	Price (each)	Stock
	N0206253	CLAMP	$1.84	To Order

Photo	Part No	Description	Price (each)	Stock
	N10347204	HEXAGON SOCKET HEAD BOLT, SELF-LOCKING	$2.15	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0260749B	SEAL RING	$6.24	To Order

Photo	Part No	Description	Price (each)	Stock
	470260705D	FLANGED PIPE	$646.30	To Order

Photo	Part No	Description	Price (each)	Stock
	470260712C	FLANGED PIPE	$520.30	To Order

Photo	Part No	Description	Price (each)	Stock
	8E0260749C	SEAL RING	$5.31	To Order

Photo	Part No	Description	Price (each)	Stock
	N91032702	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	$1.70	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N91096701	OVAL HEXAGON SOCKET HEAD BOLT	$1.53	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470813452	BRACKET	$25.02	To Order

Photo	Part No	Description	Price (each)	Stock
	443201365B	UNDERLAY	$6.94	To Order

View All

Air-Conditioning System With Electronic Regulation

Lamborghini Aventador LP780 Ultimae Roadster

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	N0206405	CLAMP	N0206405 CLAMP 18X15	$1.89 MSRP: ~~7.07~~ (73.3% off)	1
2	N0206253	CLAMP	N0206253 CLAMP	$1.84 MSRP: ~~7.07~~ (74% off)	1
3	N10347204	HEXAGON SOCKET HEAD BOLT, SELF-LOCKING	N10347204 HEXAGON SOCKET HEAD BOLT, SELF-LOCKING M6X25	$2.15 MSRP: ~~7.26~~ (70.4% off)	1
4	4E0260749B	SEAL RING	4E0260749B SEAL RING 13 -7X2,5	$6.24 MSRP: ~~7.06~~ (11.6% off)	1
5	470260705D	FLANGED PIPE	470260705D FLANGED PIPE	$646.30	1
6	470260712C	FLANGED PIPE	470260712C FLANGED PIPE	$520.30	1
7	8E0260749C	SEAL RING	8E0260749C SEAL RING 16 -2X2,5	$5.31 MSRP: ~~7.09~~ (25.1% off)	1
8	N91032702	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N91032702 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD M6X20 IN STOCK	$1.70	1
9	N91096701	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91096701 OVAL HEXAGON SOCKET HEAD BOLT M6X16 IN STOCK	$1.53	2
11	470813452	BRACKET	470813452 BRACKET	$25.02	2
14	443201365B	UNDERLAY	443201365B UNDERLAY 100X100X6	$6.94	1
