Suspension Rear

Lamborghini Aventador LP780 Ultimae

Illustration Number: 5050300

Find Your Part

Lamborghini Aventador LP780 Ultimae - SUSPENSION REAR (5050300)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
WHT005396 THREADED PIN $27.75 IN STOCK
Photo Part No Description Price (each) Stock
N10272302 HEXAGON COLLAR NUT SELF-LOCKING $2.41 IN STOCK
Photo Part No Description Price (each) Stock
WHT004898 HEXAGON COLLAR NUT SELF-LOCKING $6.65 IN STOCK
Photo Part No Description Price (each) Stock
WHT002059 BOLT, HEX HEAD WITH SHOULDER (COMBI) $5.72 IN STOCK
Photo Part No Description Price (each) Stock
N10106402 HEXAGON COLLAR NUT SELF-LOCKING $2.53 IN STOCK
Photo Part No Description Price (each) Stock
N91055501 OVAL HEXAGON SOCKET HEAD BOLT $2.76 IN STOCK
Photo Part No Description Price (each) Stock
N10689301 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD $3.39 IN STOCK
Photo Part No Description Price (each) Stock
N10640301 HEX COLLARED BOLT $6.94 IN STOCK
Photo Part No Description Price (each) Stock
WHT005397 THREADED PIN $37.40 To Order
Photo Part No Description Price (each) Stock
WHT002262 ECCENTRIC BOLT $13.97 To Order
WHT004856 ECCENTRIC BOLT $61.50 To Order
Photo Part No Description Price (each) Stock
WHT001676 ECCENTRIC WASHER $1.62 IN STOCK
Photo Part No Description Price (each) Stock
470505311G WISHBONE $4,571.76 To Order
470505312G WISHBONE $4,571.76 To Order
Photo Part No Description Price (each) Stock
470971005A MOUNTING BAR $10.16 To Order
Photo Part No Description Price (each) Stock
470407203E BALANCING PLATE $19.62 To Order
Photo Part No Description Price (each) Stock
470501397E STEERING GEAR $18,618.87 To Order
470501397E STEERING GEAR $18,618.87 To Order
470501398E STEERING GEAR $18,618.87 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
470505323J WISHBONE $2,649.11 To Order
470505324J WISHBONE $2,649.11 To Order
Photo Part No Description Price (each) Stock
470513387B INSULATION STRIP $911.85 To Order
470513387B INSULATION STRIP $911.85 To Order
470513387E INSULATION STRIP $2,116.80 To Order
Photo Part No Description Price (each) Stock
470501429D BRACKET $1,029.57 To Order
Photo Part No Description Price (each) Stock
WHT004995 HEXAGON FLANGE NUT, SELF-LOCKING $5.21 To Order
Photo Part No Description Price (each) Stock
N10434301 SOCKET HEAD BOLT $1.56 To Order
Photo Part No Description Price (each) Stock
N01118312 HEXAGON NUT, SELF-LOCKING $2.08 IN STOCK
Photo Part No Description Price (each) Stock
470941287F ARM $16.11 To Order
470941288H ARM $16.11 To Order
Photo Part No Description Price (each) Stock
470941287G ARM $27.38 To Order
470941288G ARM $27.38 To Order
Photo Part No Description Price (each) Stock
470941307 POSITION SENSOR $112.89 To Order
Photo Part No Description Price (each) Stock
N10714801 OVAL HEXAGON SOCKET HEAD BOLT $1.44 To Order
Photo Part No Description Price (each) Stock
470501470B BRACKET $38.01 To Order
470501473B BRACKET $38.01 To Order
Photo Part No Description Price (each) Stock
WHT003841 FLAT ROUND HEAD BOLT $1.62 IN STOCK
Photo Part No Description Price (each) Stock
470599503 ARM $2,617.80 To Order
470599504 ARM $440.89 To Order
Photo Part No Description Price (each) Stock
470971930 CABLE TERMINAL $14.39 To Order
View All
SUSPENSION REAR of Lamborghini Lamborghini Aventador LP780 Ultimae Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
2 WHT005396
THREADED PIN
M10X1 -25- M10X45
IN STOCK 		$27.75 8
3 N10272302
HEXAGON COLLAR NUT SELF-LOCKING
M10
IN STOCK 		$2.41 (66.2% off) 8
4 WHT004898
HEXAGON COLLAR NUT SELF-LOCKING
M14X1 -5
IN STOCK 		$6.65 2
5 WHT002059
BOLT, HEX HEAD WITH SHOULDER (COMBI)
M12X1 -5X80
IN STOCK 		$5.72 2
6 N10106402
HEXAGON COLLAR NUT SELF-LOCKING
M12X1 -5
IN STOCK 		$2.53 8
8 N91055501
OVAL HEXAGON SOCKET HEAD BOLT
M5X12
IN STOCK 		$2.76 (62.2% off) 10
9 N10689301
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
M8X25
IN STOCK 		$3.39 8
10 N10640301
HEX COLLARED BOLT
M12X1 -5X100
IN STOCK 		$6.94 8
11 WHT005397
THREADED PIN
M10X1 -25- M10X39 		$37.40 8
12 WHT002262
ECCENTRIC BOLT
WITH REAR WHEEL STEERING-M12X1 -5X87 		$13.97 (5.3% off) 2
12 WHT004856
ECCENTRIC BOLT
NO REAR WHEEL STEERING-M12X1 -5X75 		$61.50 2
13 WHT001676
ECCENTRIC WASHER
12 -2X30X5X4
IN STOCK 		$1.62 (77.7% off) 4
14 470505311G
WISHBONE
LEFT LOWER 		$4,571.76 1
14 470505312G
WISHBONE
RIGHT LOWER 		$4,571.76 1
15 470971005A
MOUNTING BAR 		$10.16 1
16 470407203E
BALANCING PLATE
3 MM 		$19.62 4
17 470501397E
STEERING GEAR
UNTIL VIN LA10932 ORDER ALSO RIGHT-LEFT 		$18,618.87 1
17 470501397E
STEERING GEAR
LEFT 		$18,618.87 1
17 470501398E
STEERING GEAR
UNTIL VIN LA10932 ORDER ALSO LEFT-RIGHT 		$18,618.87 1
17 470501398E
STEERING GEAR
RIGHT 		$18,618.87 1
18 470505323J
WISHBONE
LEFT UPPER 		$2,649.11 1
18 470505324J
WISHBONE
RIGHT UPPER 		$2,649.11 1
19 470513387B
INSULATION STRIP
REAR 		$911.85 2
19 470513387B
INSULATION STRIP
NOT FOR SOUTH KOREA-REAR 		$911.85 2
19 470513387E
INSULATION STRIP
ONLY FOR SOUTH KOREA-REAR 		$2,116.80 1
20 470501429D
BRACKET 		$1,029.57 2
21 WHT004995
HEXAGON FLANGE NUT, SELF-LOCKING
M12X1 -5 		$5.21 4
22 N10434301
SOCKET HEAD BOLT
M5X10 		$1.56 (78.6% off) 2
23 N01118312
HEXAGON NUT, SELF-LOCKING
M6
IN STOCK 		$2.08 2
24 470941287F
ARM
LEFT 		$16.11 1
24 470941288H
ARM
RIGHT 		$16.11 1
25 470941287G
ARM
LEFT 		$27.38 1
25 470941288G
ARM
RIGHT 		$27.38 1
26 470941307
POSITION SENSOR 		$112.89 2
27 N10714801
OVAL HEXAGON SOCKET HEAD BOLT
M6X18 		$1.44 10
28 470501470B
BRACKET
RIGHT 		$38.01 1
28 470501473B
BRACKET
LEFT 		$38.01 1
29 WHT003841
FLAT ROUND HEAD BOLT
M6GFX14
IN STOCK 		$1.62 (77.6% off) 4
30 470599503
ARM
LEFT 		$2,617.80 1
30 470599504
ARM
RIGHT 		$440.89 1
31 470971930
CABLE TERMINAL 		$14.39 1
