REAR DRIVE SHAFT of Lamborghini Lamborghini Aventador LP750 SV Roadster

View All

Lamborghini Aventador LP750 SV Roadster - REAR DRIVE SHAFT

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	N90737804	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N90737804 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	$1.23 MSRP: ~~7.31~~ (83.2% off)	6
002	N01474011	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	N01474011 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	$2.38 MSRP: ~~7.33~~ (67.5% off)	2
003	N10667901	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M10 X 55 IN STOCK	N10667901 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M10 X 55 IN STOCK	$2.99	12
004	470501204H	RH REAR OMOKINETIC DRIVE SHAFT (CENTER LOCK WHEEL -CONTACT YOUR AREA MANAGER)	470501204H RH REAR OMOKINETIC DRIVE SHAFT (CENTER LOCK WHEEL -CONTACT YOUR AREA MANAGER)	$9,151.56	1
004	470501204F	RH REAR OMOKINETIC DRIVE SHAFT (CONTACT YOUR AREA MANAGER)	470501204F RH REAR OMOKINETIC DRIVE SHAFT (CONTACT YOUR AREA MANAGER)	$7,937.18	1
004	470501203H	LH REAR OMOKINETIC DRIVE SHAFT (CONTACT YOUR AREA MANAGER)	470501203H LH REAR OMOKINETIC DRIVE SHAFT (CONTACT YOUR AREA MANAGER)	$9,151.56	1
004	470501203F	LH REAR OMOKINETIC DRIVE SHAFT (CONTACT YOUR AREA MANAGER)	470501203F LH REAR OMOKINETIC DRIVE SHAFT (CONTACT YOUR AREA MANAGER)	$2,128.26	1
005	470505434D	REAR RIGHT HUB CARRIER (UNTIL THE VIN GLA04209 - CONTACT YOUR AREA MANAGER)	470505434D REAR RIGHT HUB CARRIER (UNTIL THE VIN GLA04209 - CONTACT YOUR AREA MANAGER)	$821.25	1
005	470505434E	REAR RIGHT HUB CARRIER (FROM VIN GLA04210 - CONTACT YOUR AREA MANAGER)	470505434E REAR RIGHT HUB CARRIER (FROM VIN GLA04210 - CONTACT YOUR AREA MANAGER)	$1,100.44	1
005	470505433E	REAR LEFT HUB CARRIER (FROM VIN GLA04210 - CONTACT YOUR AREA MANAGER)	470505433E REAR LEFT HUB CARRIER (FROM VIN GLA04210 - CONTACT YOUR AREA MANAGER)	$1,094.20	1
005	470505433D	REAR LEFT HUB CARRIER (UNTIL THE VIN GLA04209 - CONTACT YOUR AREA MANAGER)	470505433D REAR LEFT HUB CARRIER (UNTIL THE VIN GLA04209 - CONTACT YOUR AREA MANAGER)	$1,258.18	1
006	4E0927804F	SPEED SENSOR	4E0927804F SPEED SENSOR	$122.21	1
006	4E0927803F	SPEED SENSOR IN STOCK	4E0927803F SPEED SENSOR IN STOCK	$126.24	1
007	7L0407357B	SPACER	7L0407357B SPACER	$1.94 MSRP: ~~7.14~~ (72.8% off)	6
008	470615611C	LH PROTECTION	470615611C LH PROTECTION	$115.83	1
008	470615612C	RH PROTECTION	470615612C RH PROTECTION	$115.83	1
009	WHT006779	12 POINT SOCKET SHOULDERED NUT SELF-LOCKING	WHT006779 12 POINT SOCKET SHOULDERED NUT SELF-LOCKING	$17.72	2
010	400501226	SPACER RING	400501226 SPACER RING	$46.66	2
011	WHT000237A	TRIPLE SQUARE BOLT M1 2X 1.5 X 45 IN STOCK	WHT000237A TRIPLE SQUARE BOLT M1 2X 1.5 X 45 IN STOCK	$6.93	8
012	N91055501	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91055501 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$2.75 MSRP: ~~7.30~~ (62.3% off)	2
013	470501652B	WHEEL HUB	470501652B WHEEL HUB	$3,236.23	2
014	4E0407625F	DOUBLE (ANGLED) BALL BEARING WITH FLANGE IN STOCK	4E0407625F DOUBLE (ANGLED) BALL BEARING WITH FLANGE IN STOCK	$191.43	2
015	470971930	CABLE TERMINAL	470971930 CABLE TERMINAL	$14.38	2
016	470501652E	WHEEL HUB	470501652E WHEEL HUB	$1,045.58	2
017	WHT007467	SHOULDERED BOLT IN STOCK	WHT007467 SHOULDERED BOLT IN STOCK	$155.87	8
020	470615315	FOLLOWER	470615315 FOLLOWER	$36.50	10
021	N10620901	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	N10620901 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	$2.70 MSRP: ~~7.16~~ (62.3% off)	10
